EDU-500
The Crestron
EDU-500 Student Collaboration Workstation provides all the hardware required to build a collaboration
®
solution for an educational setting.
C A
T 5
N
e
L A
U S
H D
M I
T T
- 1
1
QUICKSTART DOC. 8271A (2050999)
Student Collaboration Workstation
D i
s p
l a y
H D
M I
T T
- 1
U S
0 0
B
T T
- 1
H D
0 0
M I
U S
B
U S
B
B
H D
M I
0 0
T T
- 1
0 0
www.crestron.com
03.18
Specifications subject to
change without notice.
1
Preparation

Verify Contents

Check the table below for the system's package contents before starting installation. The following items are
included:
QUANTITY
ITEM
1
CBL-CAT5E-7, Ethernet LAN Cable, 7 feet (2.13 m)
4
CBL-HD-6, HDMI Interface Cable, 6 feet (1.83 m)
1
CBL-HD-20, HDMI Interface Cable, 20 feet (6.10 m)
1
HD-WP-4K-401-C, 4K Multi-Window Video Processor with
HDBaseT
®
& HDMI
®
Outputs
4
TT-100-B-T, Crestron Connect It™ Cable Caddy w/120V Outlet,
No Cables, Black Textured

Additional Requirements

The following items are also required to build a student collaboration workstation.
A video display (not included) must be connected to the HD-WP-4K-401-C.
Source devices (not included) may be connected to the TT-100-devices.
888.273.7876
201.767.3400
PART NUMBER
6509924
6503565
6503567
6507977
6506815
