Vehicle Square Rail with External Trolley -
with Magnetic Grabber
®
vSR X
Thank you for buying this Plymovent product.
Before you put this system into operation
please read this product manual carefully, and
follow the instructions.
This manual is intended to be used as a work
of reference for an authorized professional to
safely install, use, maintain and service the
Plymovent VSRX system.
This manual should be handed over and kept
by the service department after the
installation.
User manual
www.plymovent.com
Advertisement
Table of Contents
Related Manuals for Plymovent VSRX
Summary of Contents for Plymovent VSRX
- Page 1 Vehicle Square Rail with External Trolley - with Magnetic Grabber ® vSR X Thank you for buying this Plymovent product. Before you put this system into operation please read this product manual carefully, and follow the instructions. This manual is intended to be used as a work...
- Page 2 EN - ORIGINAL INSTRUCTION All rights reserved. The information given in this document has been collected for the general convenience of our clients. It has been based on general data pertaining to construction material properties and working methods known to us at the time of issue of the document and is therefore subject at anytime to change or amendment, and the right to change or amend is hereby expressly reserved.
-
Page 3: Table Of Contents
Safety Disconnect Handle ................18 Tailpipe Modification Options ................18 User and Maintenance Instructions ................20 Operating the Magnetic Grabber ..............20 ® Inspection and Maintenance ................20 Cleaning and FAQ ......................21 Hose package ....................21 Other Components ..................21 VSRX-Rail and Suspensions ................21 Disposal ........................21 Spare Parts ......................22... -
Page 4: General Precautions
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Plymovent be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 5: Preface
Product combinations working in an area over 6.5 feet (2 m). VSRX can be used in back in and drive through applications with Never install the product in front of entries, exits or passage multiple vehicles inline. Systems are available from 20 ft to 120 ways that are used by fire and emergency service personnel. -
Page 6: Use
Tools ATTENTION! These tools are needed to install this Plymovent System: Stay alert and pay attention during the installation. - cordless drill Do not use the product when you are under the - cordless impact driver influence of drugs or alcohol. -
Page 7: Area Of Use
AREA OF USE ATTENTION The VSRX system is used in fire and emergency service stations, The VSRX system is designed to operate under where there are multiple vehicles parked behind an exit door standard vehicle performance conditions. DPF waiting for an emergency call. -
Page 8: Delivery
DELIVERY All of the VSRX models are built from the following standard Adjustable mounting kit (vertical) components. The two brackets are similar. They can also be used if the roof is angled and they can be mounted in both directions. - Page 9 Shock Absorber - Hose diameter is either 4 in (100 mm) or 5 in. (125 mm) The hydraulic shock absorber is inserted into bottom of the VSRX - Magnetic Grabber 3 in. (75 mm), 4 in. (100 mm) 5 in. (125 End Cap on the entry door side, and secured with two hex nuts that are included.
-
Page 10: Installation
INSTALLATION Mounting instructions - Determine the installation height of the rail (measured from the bottom of the rail) (1). - Determine the recommended distance from the end stop to the door in the Installation Table (2). - Determine the recommended balancer locking cable (BLC) length in the Installation Table (3). -
Page 11: Back-In Measurements
Measure the distance between the door and the exhaust pipe (3). This is the required minimum length of the VSRX rail. Check before installation that this is the minimum required length of the VSRX in back-in application. -
Page 12: Drive-Through Measurements
Drive-Through Measurements Please determine the position of: WARNING Tailpipe PRODUCT MAY CONTAIN SHARP EDGES Entrance door. Use care when servicing unit. Exit door. Failure to do so could result in minor personal injury. Distance between Entrance door / Exit door. a. -
Page 13: Vsrx-Rail Location
End View 6. Distance to exit door a. The VSRX-Rail (1) is mounted at a height (4) between 12 ft (3,7 m) and 14 ft (4,3 m) over the floor on the side in which the tailpipe (2) is located. -
Page 14: Assemble The Legs And Rail
Note: Longer braces can be made out of ¾ in. (19 mm) EMT conduit and attached to the leg using a Plymovent 8130-1011 leg/brace mounting kit. You should have at least one long brace running front to back. -
Page 15: Mount The Rubber Seal
3. Tool no. 0000102158 a. Turn the rail profile with the opening upwards. The rubber lip seal can be easily installed with the Plymovent VSR Lip Tool before hanging the rail from the support legs; or you can install the lip after the rail is hung from the support legs. -
Page 16: Assemble And Hang The Hose And Grabber
Assemble and Hang the Hose and Grabber WARNING 1. Upper Hose PRODUCT MAY CONTAIN SHARP EDGES 2. Metal Saddle Use care when servicing unit. Failure to do so could 3. Balancer result in minor personal injury. 4. Mid Hose 5. Lower Hose Assembly (Safety Disconnect Handle) 6. -
Page 17: Install The Pc-500 Pressure Switch
4.10 Install the PC-500 Pressure Switch ATTENTION Please refer to Wireless Manual (article #100716) for Please ensure that the position of the tailpipe installation. connector meets EN 1846-2, which indicates the minimal distance from tailpipe connector to the road surface (differs per type of vehicle). MODIFYING THE TAILPIPE e. -
Page 18: Check The Balancer Tension
As an example, the image on the next page shows the Plymovent tailpipe support bracket being used with a 3rd party tailpipe reducer pack. This ensures a support a correct and sturdy installation of the Magnetic Grabber connector. - Page 19 This product can be used in combination with the Magnetic Grabber tailpipe bends as well as direct onto the Magnetic Grabber tailpipe connector. The tailpipe reducer pack allows a wide range of exhaust pipes to connect to the Plymovent system. TAILPIPE REDUCER New Art.
-
Page 20: User And Maintenance Instructions
3 feet (1 m) obstructions that can prevent the magnets from positioning under and / or around the VSRX system and /or between the themselves on the product. vehicle and the entry / exit door when the vehicle exits the building. -
Page 21: Cleaning And Faq
The service and maintenance department of installation. Plymovent consists of well trained personnel who can offer you a service and maintenance contract which ensures your system Dismantling must be done contrary to the installation will function for many years to come, and protects your instructions. -
Page 22: Spare Parts
SPARE PARTS See Separate SDCH manual See Separate Balancer manual Page 22 of 24 MAN_MAG_VSRX_290518_LETTER_EN... - Page 23 VSRX-70 VSRX-75 VSRX-80 VSRX-85 VSRX-90 VSRX-100 VSRX-120 Note: Because all Plymovent hose systems are custom configured, please consult your authorized distributor/installer for the proper part needed for your system. New Art. #: Old Art. #: Description Note Multiple Numbers MG Upper Hose (various sizes are available) Consult your authorized Plymovent distributor.
- Page 24 050718/VSRX www.plymovent.com...
