Hardware
Fa x 12 + 1 spare
M6 x 18L Bolt
Ff x 4
Nut
Harrington padded sling double glider
ASSEMBLY INSTRUCTIONS
SP-I-139NDG-BK & SP-I-139NDG-BN
Fb x 4
M6 x 25L Bolt
Fg x 4
Plastic Washer
Fc x 2
M6 x 30L Bolt
Fh x 1
Open Hex Wrench
1
Fe x 26
Fd x 5
Metal Washer
M6 x 50L Bolt
Fi x 1
Allen Wrench
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Numark Harrington SP-I-139NDG-BK
Summary of Contents for Numark Harrington SP-I-139NDG-BK
- Page 1 Harrington padded sling double glider ASSEMBLY INSTRUCTIONS SP-I-139NDG-BK & SP-I-139NDG-BN Questions, problems, missing parts with this product? Please contact us at www.numarkcustomerservice.com Hardware Fe x 26 Fd x 5 Fa x 12 + 1 spare Fb x 4 Fc x 2 Metal Washer M6 x 25L Bolt M6 x 50L Bolt...
- Page 2 Parts Left Arm Right Arm Seat Back Base Leg Base Leg Connector Assembly instruction Fa x 4 M6 x 18L Bolt Fc x 2 M6 x 30L Bolt Fe x 6 Metal Washer Don’t tighten completely. Repeat procedure for the other arm.
- Page 3 Assembly instruction Fb x 4 M6 x 25L Bolt Fd x 1 M6 x 50L Bolt Fe x 4 Metal Washer Don’t tighten completely. Repeat procedure for the other side. Fa x 8 M6 x 18L Bolt Fe x 8 Metal Washer Note: the arrow should be towards downside when assembly.
- Page 4 Assembly instruction Fd x 4 M6 x 50L Bolt Fe x 8 Metal Washer Ff x 4 Fg x 4 Plastic Washer Don’t tighten completely. Repeat procedure for the other side. Securely tighten all bolts. Now your glider is ready for use.
