OWNER'S MANUAL
Questions, problems, missing parts with this product? Please contact us
at www.numarkcustomerservice.com
ACCESSORIES
Ka (25 +1 spare)
Short Bolt
Kb (6)
Long Bolt
PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat,
non-abrasive surface. Assembly by two people is recommended.
Estimated Assembly Time: 40 minutes
ITEM
DESCRIPTION
A1
Right Arm
A2
Left Arm
B
Chair Seat
C
Chair Back
F
Seat Cushion
G
Back Cushion
LEXINGTON 4 PC SET
Vendor Item:SC-I-139NSF/4
SKU#:124287455
QUANTITY
2
2
2
2
2
2
1
Kc (31)
Metal Washer
Kd (1)
Allen Wrench
A1
F
G
C
B
A2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Numark LEXINGTON 124287455
Summary of Contents for Numark LEXINGTON 124287455
- Page 1 OWNER’S MANUAL LEXINGTON 4 PC SET Vendor Item:SC-I-139NSF/4 SKU#:124287455 Questions, problems, missing parts with this product? Please contact us at www.numarkcustomerservice.com ACCESSORIES Ka (25 +1 spare) Kc (31) Short Bolt Metal Washer Kb (6) Kd (1) Long Bolt Allen Wrench PARTS Read through all the instructions before beginning assembly.
- Page 2 ASSEMBLY INSTRUCTIONS Ka x 4 Short Bolt Kc x 4 Metal Washer Repeat procedure for the other side. Ka x 2 Short Bolt Kc x 2 Metal Washer Repeat procedure for the other side. Kb x 2 Long Bolt Kc x 2 Metal Washer Repeat procedure for the other side.
- Page 3 ASSEMBLY INSTRUCTIONS Putting cushions onto the chair frame Repeat procedure for the other chair. ITEM DESCRIPTION QUANTITY Right Arm Left Arm Loveseat Seat Loveseat Back Seat Cushion Back Cushion Ka x 4 Short Bolt Kc x 4 Metal Washer Repeat procedure for the other side. Ka x 2 Short Bolt Kc x 2...
- Page 4 ASSEMBLY INSTRUCTIONS Kb x 2 Long Bolt Kc x 2 Metal Washer Repeat procedure for the other side. Ka x 3 Short Bolt Kc x 3 Metal Washer Repeat procedure for the other side. Securely tighten all bolts. Putting cushions onto the loveseat frame ITEM DESCRIPTION QUANTITY...
- Page 5 ASSEMBLY INSTRUCTIONS Ka x 8 Short Bolt (remove from the table top) Kc x 8 Metal Washer (remove from the table top) Repeat procedure for the other side and the other leg. Ka x 2 Short Bolt (remove from the metal leg) Kc x 2 Metal Washer (remove from the metal leg)
