Casio EV-500B Service Manual & Parts List page 21

BL PCB
N Item Code No.
Capacitors
C925 2825 0392 TF capacitor
N C927 2813 3213 Ceramic capacitor
Coil
L950 3013 0756 Choke coil
Connectors
CN702 3501 7182 Connector
CN950 3500 7122 Pin ass'y
Transistors
Q950 2253 0287 Chip transistor
Q951 2253 0287 Chip transistor
Resistors
N R720 2609 0371 Carbon film resistor
R950 2609 0266 Carbon film resistor
Switches
SW700 3412 1029 Switch
SW701 3412 1029 Switch
Transformer
N T950 3012 1239 Inverter trans
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
Parts Name
ECQ-V1H154JL
DE0405SL270J2K
RCH-875-101K
52287-0411
53253-0310
2SD965-R
2SD965-R
ERD-S2TJ472A
ERD-S2TJ821A
SKHHAL
SKHHAL
NT-06
— 20 —
Specification Q M
1 20
1 20
1
1 20
1 20
1 10
1 10
1 20
1 20
1 20
1 20
1
FOB Japan
N.R.Yen R
Unit Price
C
C
5 C
C
C
C
C
C
C
C
C
1 C
