John Shearer CONNOR SHEA 8000 Series Operator's Manual / Parts Catalogue

Pasture drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

SOWING THE SEEDS OF YOUR SUCCESS
Eff. Date
CSN AUSTRALIA
SHARE ST
KILKENNY, S.A. 5009
SERIES 8000
PASTURE DRILL
OPERATOR'S MANUAL
PARTS CATALOGUE
Serial No.
(JOHN SHEARER LTD)
Phone ....................... +61 8 8268 9555
Fax (Spare Parts)......... +61 8 8268 1103
Email..........spares@johnshearer.com.au
Part No. 8000PB
ACN 007 871 472

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONNOR SHEA 8000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for John Shearer CONNOR SHEA 8000 Series

Summary of Contents for John Shearer CONNOR SHEA 8000 Series

  • Page 1 PASTURE DRILL OPERATOR’S MANUAL PARTS CATALOGUE Eff. Date Serial No. Part No. 8000PB CSN AUSTRALIA (JOHN SHEARER LTD) ACN 007 871 472 SHARE ST Phone ………………..… +61 8 8268 9555 KILKENNY, S.A. 5009 Fax (Spare Parts)……... +61 8 8268 1103 Email…….…spares@johnshearer.com.au...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARRANTY CARD / PRE-DELIVERY CHECK LIST SUGGESTED OWNERS SERVICE PARTS…………………………………………………………… 1 INTRODUCTION………………………………………………………………………………………… 2 ORDERING SERVICE PARTS…………………………………………………………………………. 2 ACCEPTING DELIVERY………………………………………………………………………………. 3 STANDARD MACHINE SPECIFICATIONS…………………………………………………………. 3 SAFETY FIRST………………………………………………………………………………………….. 4 ASSEMBLY INSTRUCTIONS…………………………………………………………………………. 5 OPERATING INSTRUCTIONS………………………………………………………………………… 5 CALIBRATION………………………………………………………………………………………….. 7 SOWING CHART……………………………………………………………………………………….. 8 GATE SETTING………………………………………………………………………………………….
  • Page 3 IMPORTANT:- TO ENSURE YOUR CLIENTS ARE COVERED UNDER WARRANTY YOU MUST FILL OUT THIS What John Shearer machines do you currently have on your property? PORTION OF THE CARD AND RETURN WITHIN 7 DAYS TO JOHN SHEARER LIMITED P.O. BOX 32, WELLAND, S.A. 5007 Serial No.
  • Page 5 John Shearer Dealer. WARRANTY P O L IC Y JOHN SHEARER LIMITED (JSL) warrants to purchaser that in normal use if any part of goods manufactured by JSL is proved to be defective material such part will be replaced or repaired by...
  • Page 6 PRE-DELIVERY CHECK 1. On delivery of the 8000 SERIES DRILL ensure there are no shortages. 2. Check implement equipment, to ensure as ordered. 3. Check for trans-shipping damage. 4. Refer to pages 10 and 11, for lubrication and routine check points. 5.

  • Page 7: Suggested Owners Service Parts

    SUGGESTED OWNER’S SERVICE PARTS: This is a listing of suggested Service Parts that the owner of a Series 8000 Pasture Drill should keep, to avoid unnecessary delays during sowing. Part No. Description 13833 Bush 18350 Eye Bolt 22108 Spring 22180 18071 Bearing 23727...

  • Page 8: Introduction

    INTRODUCTION: This manual was developed specifically for the machine you have purchased, the Series 8000 Pasture Drill. The information within is for your assistance in preparing, adjusting, operating and servicing your machine. Major points for safe operation are detailed under safety in this manual.

  • Page 9: Accepting Delivery

    ACCEPTING DELIVERY: Carefully check your Pasture Drill for damage that may have occurred during transportation. Report any damage and lodge a claim for repairs with the transport company concerned before accepting delivery. STANDARD MACHINE SPECIFICATIONS: Series 8000 Pasture Drill Model 8013 8016 8019...

  • Page 10: Safety First

    SAFETY FIRST: Before you attempt to operate this equipment, read and understand the following Safety information: Accidents are inevitably the result of carelessness. Avoid injury to yourself and others by adopting the following safety rules and recommendations, and by being safety conscious at all times.

  • Page 11: Assembly Instructions

    ASSEMBLY INSTRUCTIONS: Generally the series 8000 Pasture Drill will be supplied in a condition where very little assembly is required. 1. Remove any components from within the hopper. Also remove any packing from around the machine. 2. Fit convoluted seeding hoses between the hopper and seeding boots. (hoses packed in hopper) 3.
  • Page 12 Setting the Coulters: • Coulters should be adjusted so that they are approximately 25mm lower than the blade points. This can be achieved by loosening the large, square headed setscrews and raising or lowering the Coulter Carrying Bar. This is made easier by using the turnbuckle.

  • Page 13: Calibration

    Initial Inspection: In order for the Series 8000 Pasture Drill to perform correctly and accurately, it must be set up properly. The seeder units have been checked at the factory, prior to dispatch, however before taking the unit in field, follow these steps to ensure proper operation. CALIBRATION: Seed –...

  • Page 14: Sowing Chart

    SOWING CHART Series 8000 Pasture Drill Page 8...

  • Page 15: Gate Setting

    Seeding Rate Check for Machine with Jockey Wheel on Ground Wheel:- For accuracy, it is desirable to catch the output from a number of seeding units in a plastic bag and weigh the amount of seed dispensed after pulling the machine over a known area. This is achieved by the following procedure: 1.

  • Page 16: Cleaning

    CLEANING: Remove the bulk of seed / fertilizer by hand. To remove the remainder of the seed / fertilizer, move the adjustment levers at the front of the hopper to clean out position. Before carrying out the above operation a suitably sized tarpaulin or hessian may be laid on the ground and the machine towed onto it to catch any material released.

  • Page 17: Tyre Pressures

    TYRE PRESSURES: 195 / 70 R15 Light Truck Tyres Max: 450 kPa (65 psi) 275 kPa (40 psi) 325 kPa (47 psi) 350 kPa (51 psi) 400 kPa (58 psi) The minimum tyre pressure is dependant on the weight of the implement. If the weight increases (due to additional equipment) the tyre pressure may need to be increased to suit.

  • Page 18: Service History

    SERVICE HISTORY DATE PART No. COMMENT NOTES Series 8000 Pasture Drill Page 12...
  • Page 19 ILLUSTRATED PARTS SECTION Series 8000 Pasture Drill Page 13...
  • Page 20 Series 8000 Pasture Drill Page 14...

  • Page 21: Mainframe And Axle

    MAINFRAME AND AXLE Ref. Part No. Description Qty. 801-010 Main Frame………………………………………. 802-010 Main Frame………………………………………. 803-010 Main Frame………………………………………. 804-010 Main Frame………………………………………. 42290 Rockshaft W/A – 801…………………………….. 42291 Rockshaft W/A – 802…………………………….. 42292 Rockshaft W/A – 803…………………………….. 42293 Rockshaft W/A – 804…………………………….. 36954 Seal, Triple Lip (No wear ring)…….……..…….
  • Page 22 Series 8000 Pasture Drill Page 16...
  • Page 23 MAINFRAME AND AXLE (CONT’D) Ref. Part No. Description Qty. 801-061 Walkway Grating…………………...……………. 29006 Walkway Grating…………………...……………. 803-061 Walkway Grating…………………..……………. 804-061 Walkway Grating………………...………………. 942-652 Bolt Cup Hd M8 x 90…………………………… 989-337 Anchorage Clip…………………………………. 961-603 Flat Washer ∅8…………………………………. 936-603 Nut Nyloc M8…………………………………... 945-664 Setscrew M10 x 20………………………………...
  • Page 24 Series 8000 Pasture Drill Page 18...

  • Page 25: Hydraulic Coulter Bar & Mainframe

    HYDRAULIC COULTER BAR & MAINFRAME Ref. Part No. Description Qty. 42537 HCB Mainframe………………………………..… 42536 HCB Mainframe………………………………….. 42535 HCB Mainframe………………………………….. 42402 HCB Mainframe………………………………….. 42540 Coulter Bar – Hydraulic…………………………. 42541 Coulter Bar – Hydraulic…………………………. 42320 Coulter Bar – Hydraulic…………………………. 42408 Coulter Bar – Hydraulic…………………………. 22889 Lynch Pin………………………………………..
  • Page 26 Series 8000 Pasture Drill Page 20...

  • Page 27: Hitch And Optional Drawbar

    HITCH AND OPTIONAL DRAWBAR Ref. Part No. Description Qty. 800-015 Pin 28 x 90mm……………………………………. 989-180 Grip Clip 5mm………………………………….. 24208 Draw Bar………………………………………….. 24196 Trimming Screw………………………………….. 989-017 Grease Nipple 1/8” BSP………………………… 24199 Screw LH Thread for Trimming Screw………… 24200 Screw RH Thread for Trimming Screw………… 931-009 Nut Hex 1”...
  • Page 28 Series 8000 Pasture Drill Page 22...

  • Page 29: Drive Wheel And Pressure Arm

    DRIVE WHEEL AND PRESSURE ARM Ref. Part No. Description Qty. 800-030 Box support R.H.………………………………... 18859 Bolt Hex M12 x 35……………………………. 962-006 Spring Washer ∅1/2”………………….……… 931-605 Nut Hex M12...………………………………... 800-040 Pressure Arm……………………………………. 952-650 Setscrew M12 x 100…………………………... 931-605 Nut Hex M12………………………………….. 945-721 Bolt Hex M16 x 90…………………………….
  • Page 30 Series 8000 Pasture Drill Page 24...
  • Page 31 DRIVE WHEEL AND PRESSURE ARM (CONT’D) Ref. Part No. Description Qty. 802-035 Lid…………………………………………………. 803-035 Lid…………………………………………………. 804-035 Lid…………………………………………………. 800-070 Hinge Bracket L.H.………………………………. 800-071 Hinge Bracket R.H.………………………………. 945-620 Bolt Hex M8 x 25………………………………. 936-603 Nut Nyloc M8…………………………………... 800-074 Hinge Bolt Plate………………………………….. 945-606 Bolt Hex M6 x 50……………………………….
  • Page 32 Series 8000 Pasture Drill Page 26...

  • Page 33: Drive Controls And Torque Limiters

    DRIVE CONTROLS AND TORQUE LIMITERS Ref. Part No. Description Qty. 800-120 Controls Assy……………………………………... 800-115 Control Case…………………………………… 800-127 Scale L.H. ……...………………………………. 800-128 Scale R.H. ……………………………………… 800-125 Adjusting Rod…………………………………. 931-604 Nut Hex M10………………………………… 986-642 Roll Pin ∅3 x 16……………………………... 800-131 Adjusting Block L.H. …………………………. 800-130 Adjusting Block R.H.
  • Page 34 Series 8000 Pasture Drill Page 28...
  • Page 35 DRIVE CONTROLS AND TORQUE LIMITERS (CONT’D) Ref. Part No. Description Qty. 942-641 Bolt Cup Hd M8 x 20…………………………... 936-603 Nut Nyloc M8…………………………………... 800-050 Drive Crankshaft…………………………………. 941-638 Bolt Hex M10 x 40……………………………... 961-604 Flat Washer ∅10……………………………….. 936-604 Nut Nyloc M10…………………………………. 800-095 Actuator Lever……………………………………...
  • Page 36 Series 8000 Pasture Drill Page 30...

  • Page 37: Roller Clutch Box

    ROLLER CLUTCH BOX Ref. Part No. Description Qty. 800-078 Housing – Blind……………………………..……. 800-079 Housing – Thru Bore…………………………….. 945-621 Bolt Hex M8 x 30 Gr 8.8……………………….. 931-603 Nut M8………………………………………….. 962-603 Spring washer ∅8………………………………. 981-050 Seal………………………………………………… 924-029 Bush – Shorelube………………………..……….. 800-099 Input Shaft……………………………..…………. 800-089 Rocker Arm……………………………………….
  • Page 38 Series 8000 Pasture Drill Page 32...

  • Page 39: Distribution Mechanism

    DISTRIBUTION MECHANISM Ref. Part No. Description Qty. 801-045 Metering Adjustment Shaft………………… 802-045 Metering Adjustment Shaft………………… 803-045 Metering Adjustment Shaft………………… 804-045 Metering Adjustment Shaft………………… 801-044F Metering Shaft………………………………. Metering Shaft………………………………. 802-044F Metering Shaft………………………………. 803-044F 804-044F Metering Shaft………………………………. 18422 Bush…………………………………………... 18848 Bearing……………………………………….. 18596 Grease Nipple ¼”...
  • Page 40 Series 8000 Pasture Drill Page 34...
  • Page 41 DISTRIBUTION MECHANISM (CONT’D) Ref. Part No. Description Qty. 21755 Rubber Strip……………………………………… 39720 Retainer Strip…………………………………….. GB7G Gutter Bolt/Nut 5/8” x ¼”…………………………. 18424 Blank-off Cover (optional extra)………………… 18435 Pegged Roller……………………………………... 6000-350 Metering Gate……………………………………. 18597 Button……………………………………………... 39948 Cup………………………………………………… 989-932 Cup, Double (optional)……...………….………….. 36940 Viewing Panel……………………………………..
  • Page 42 Series 8000 Pasture Drill Page 36...

  • Page 43: Coil Tyne Assembly

    COIL TYNE ASSEMBLY Ref. Part No. Description Qty. 23698/1 Coil Tyne RH Front w/- Cast B/Boot…………… 23699/1 Coil Tyne RH Rear w/- Cast B/Boot…………….. 23700/1 Coil Tyne LH Front w/- Cast B/Boot……………. 23701/1 Coil Tyne LH Rear w/- Cast B/Boot…………….. 23675 Coil Tyne RH……………………………………...
  • Page 44 Series 8000 Pasture Drill Page 38...

  • Page 45: Coulter Assembly

    COULTER ASSEMBLY Ref. Part No. Description Qty. 801-020 Coulter Carrier Bar……………………………… 802-020 Coulter Carrier Bar……………………………… 803-020 Coulter Carrier Bar……………………………… 804-020 Coulter Carrier Bar……………………………… 880-401 Clamp Bolt………………………………………... 880-405 Coulter Bracket…………………………………... 961-608 Flat Washer ∅16………………………………... 931-606 Nut Hex M16…………………………………… 880-410 Coulter Carrying Bracket (Double)…………….. 880-420 Coulter Carrying Bracket (Single)………………...
  • Page 46 Series 8000 Pasture Drill Page 40...

  • Page 47: Machine Identification

    MACHINE IDENTIFICATION Ref. Part No. Description Qty. Key 924 Transfer – Logo + Connor Shea (White – Later Models) Key 248 Transfer – Logo + Connor Shea (Red – Early Models) Key 254 Transfer – Sowing Chart…………………………... Key 038 Transfer – Sling Here……………………………… 410-111 Transfer –...

  • Page 48: Seeder Cup Position

    SEEDER CUP POSITION Series 8000 Pasture Drill Page 42...
  • Page 49 OPTIONAL PARTS SECTION Series 8000 Pasture Drill Page 43...
  • Page 50 Series 8000 Pasture Drill Page 44...

  • Page 51: Hydraulic Coulter Bar Add-On Kit

    HYDRAULIC COULTER BAR - ADD ON KIT Ref. Part No. Description Qty. 22889 Lynch Pin………………………………………….. 27018 Clevis Pin – Ram…………………………………... 28575 U-Bolt M12………………………………………... 29833 Pin – Ram ∅25 x 134……………………………… 42321 Arm, Suspension – Assembly……………………. 42322 Lug, Suspension – Assembly…………………….. 42323 Carrier Arm………………………………………...

  • Page 52: Index

    INDEX 24109…………………... 42534…………………... 11364…………………... 24199…………………... 42535…………………... 11951…………………... 24200…………………... 42536…………………... 11952…………………... 24208…………………... 42537…………………... 13407…………………... 24432…………………... 42540…………………... 13833…………………... 23, 39 24507…………………... 42541…………………... 141-052………………... 27018…………………... 19, 45 42578…………………… 15248J1………………... 19, 45 27019…………………... 42583…………………... 15953J1………………... 27409…………………... 42596…………………... 15968J1………………... 27464…………………... 42598…………………... 16161J1………………... 27600…………………... 42600…………………... 16848J1………………... 28100N………………….
  • Page 53 800-110………………... 804-070……………….. 945-721……………….. 800-115………………... 880-401……………….. 945-723……………….. 800-120………………... 880-405……………….. 945-745……………….. 800-125………………... 880-410……………….. 945-747……………….. 800-127………………... 880-415……………….. 945-808……………….. 15, 21 800-128………………... 880-420……………….. 952-623……………….. 800-131………………... 952-650……………….. 800-130………………... 954-409……………….. 800-134………………... 921-033……………….. 954-601……………….. 800-137………………... 923-001……………….. 954-664……………….. 800-138………………... 923-022……………….. 961-002……………….. 800-144………………... 923-635……………….. 961-006……………….. 800-145………………... 923-648……………….. 961-603……………….. 17,31,33 800-147………………...
