Specifications; Connectors; Power Supply; Performance - 3Com SuperStack 3 4300 Datasheet

3 C O M S U P E R S TA C K
®

Specifications

Ordering Information

3 S W I T C H 4 3 0 0 D ATA S H E E T
®

Connectors

48 autonegotiating 10BASE-T/100BASE-TX ports
configured as Auto MDIX
2 module slots accommodating media modules
All fiber module connectors are MT-RJ.
Advanced Redundant Power System Type 2A
connector
RS232 console port

Performance

17 Gbps switching capacity
Up to 13 million packets per second
8,000 MAC addresses supported

Reliability

MTBF@40C: 141,000 hours

Environmental Requirements

Operating temperature: 0° to 40°C (32° to 104°F)
Storage Temperature: -40° to +70°C (-40° to +158°F)
Operating Humidity: 10% to 90% relative
humidity noncondensing
Standards: EN 60068 (IEC 68)
Safety Agency Certifications
UL 1950, EN 60950, CSA 22.2
No. 950, IEC 60950
Emissions: EN 55022 Class A, FCC Part 15
Subpart B Class A, ICES-003
Class A, VCCI Class A, AS/NZS
3548 Class A, CNS 13438 Class A
Immunity: EN 55024
Heat Dissipation: 90W max (307BTU/hr maximum)
SuperStack 3 Switch 4300 48-port 10/100 Managed
Switch
Optional Modules and Accessories for the
SuperStack 3 Switch 4300
SuperStack 3 Switch 4300 100BASE-FX Single port
Module
SuperStack 3 Switch 4300 100BASE-FX Dual port
Module
SuperStack 3 Switch 4300 1000BASE-T Single port
Module
SuperStack 3 Switch 4300 1000BASE-T Dual port
Module
*Based on current comparable competitor solutions. For example, the current published list price for
TM
the Cisco Catalyst
two 24 port units are stacked together to make a 48 port stack) is $6,380; compared to $2,995 for the
3Com SuperStack 3 Switch 4300.
3Com Corporation, Corporate Headquarters, 5400 Bayfront Plaza, P.O. Box 58145, Santa Clara, CA 95052-8145
To learn more about 3Com solutions, visit www.3com.com. 3Com Corporation is publicly traded on Nasdaq under the
symbol COMS.
Copyright © 2002 3Com Corporation. All rights reserved. 3Com, the 3Com logo, and SuperStack are registered
trademarks of 3Com Corporation. All other company and product names may be trademarks of their respective
companies. While every effort is made to ensure the information given is accurate, 3Com does not accept liability for
any errors or mistakes which may arise. All specifications are subject to change without notice.
3C17100
3C17111
3C17112
3C17121
3C17122
®
3548 XL is $4,995; and the price of the Nortel Networks
Dimensions
Height: 65mm (2.6 in or 1.5U)
Width: 440mm (17.3in)
Depth: 300mm (12in)
Weight: 5.3Kg (12lb)

Power Supply

AC Line Frequency 50/60 Hz
Input Voltage Options 100-240 VAC
Current Rating 2A maximum
SNMP Standards
SNMP Protocol (RFC 1157)
MIB-II (RFC 1213)
Bridge MIB (RFC 1493)
RMON MIB II (RFC 2021)
Remote Monitoring MIB (RFC 1757)
Interface MIB (2233)

Management

Web interface management
Command line interface management
SNMP Management
3Com Network Supervisor (trial copy provided on
accompanying CD)
SuperStack 3 Switch 4300 1000BASE-SX Single
port Module
SuperStack 3 Switch 4300 1000BASE-SX Dual port
Module
SuperStack 3 Switch 4300 1000BASE-LX Single
port Module
SuperStack 3 Advanced Redundant Power System
SuperStack 3 Advanced RPS Type 2A module
TM
BayStack
3C17131
3C17132
3C17141
3C16071B
3C16074A
®
450 (when
400678-005 10/02
