MT-XGT(RS485)
Technical Support Manual
© Copyright Reserved Autonics Co., Ltd.
iii

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT-XGT and is the answer not in the manual?

Questions and answers

Related Manuals for Autonics MT-XGT

Summary of Contents for Autonics MT-XGT

  • Page 1 MT-XGT(RS485) Technical Support Manual © Copyright Reserved Autonics Co., Ltd.
  • Page 2 © Copyright Reserved Autonics Co., Ltd.

  • Page 3: Preface

    Preface Preface Thank you very much for selecting Autonics products. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.

  • Page 4: Technical Support Manual Guide

    (www.autonics.com) to download a copy.  The manual's content may vary depending on changes to the product's software and other unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through our homepage. ...

  • Page 5: Technical Support Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.

  • Page 6: Safety Precautions

     Do not use water or oil-based detergent when cleaning the unit. Use dry cloth to clean the unit. Failure to follow these instructions may result in electric shock or fire. © Copyright Reserved Autonics Co., Ltd.
  • Page 7 Keep dust and wire residue from flowing into the unit. Failure may result in fire or product malfunction.  Check the polarity of the measurement input contact before wiring the unit. Failure to follow this instruction may result in fire or explosion. © Copyright Reserved Autonics Co., Ltd.
  • Page 8 Safety Precautions © Copyright Reserved Autonics Co., Ltd.

  • Page 9: Table Of Contents

    Table of Contents ......................9 System ....................... 11 Version ........................ 11 Connections ......................11 Communication cable connection ............... 11 Communication Setting ................13 MT4W Setting ..................... 13 XGB Setting ......................14 Operation Check ..................23 © Copyright Reserved Autonics Co., Ltd.
  • Page 10 Table of Contents © Copyright Reserved Autonics Co., Ltd.

  • Page 11: System

    Connections RS-485 XGK-CPUE MT4W MT4W MT4W MT4W (XGl-CH2A) Communication cable connection MT4W Cable connection PLC (XGT – XGL-CH2A) RX - RS – 485 (-) RX + TX - RS – 485 (+) TX + © Copyright Reserved Autonics Co., Ltd.
  • Page 12 1 System © Copyright Reserved Autonics Co., Ltd.

  • Page 13: Communication Setting

    * Hold the MODE key for over 3 sec in any parameter group, it returns to RUN mode. * If any key is not entered for 60 sec in each parameter, it returns to RUN mode. * Only for RS485 communication output model is available. © Copyright Reserved Autonics Co., Ltd.

  • Page 14: Xgb Setting

    2 Communication Setting XGB Setting 1st Run XG5000, and select [Project] – [New Project] on menu. Enter project name and select CPU Series and type. © Copyright Reserved Autonics Co., Ltd.
  • Page 15 2 Communication Setting 2nd After executing, enter the below contents at XG5000. * This communication program is only for test. Before using it at field, review and test the program fully. © Copyright Reserved Autonics Co., Ltd.
  • Page 16 USB. After connecting completed, select [Online] – [Change Mode] – [Stop]. Connection Type settings Type Depth Local 4th At [Online] – [I/O Information], click ‘I/O Sync’. When I/O syncronizing is completed, it is set same as the used module. © Copyright Reserved Autonics Co., Ltd.
  • Page 17 6th [Standard Settings-Cnet] dialog box appears. At standard settings, set as below. Item Setting Note Communication RS-485 Fixed type Standard Communication 9600 User setting speed Settings Channel 2 Terminating User setting Disable resisters User setting Station No. Operation Channel 2 Use P2P mode © Copyright Reserved Autonics Co., Ltd.
  • Page 18 2 Communication Setting 7th At advanced settings, set as below. Item Channel 2 Data bit Advanced Stop bit settings Parity bit NONE 8th Double-click ‘P2P Channel’ and select ‘Modbus RTU client’ of ‘Use P2P’. Click ‘OK’. © Copyright Reserved Autonics Co., Ltd.
  • Page 19 2 Communication Setting 9th Double-click ‘P2P Channel’ to select Modbus RTU client at Use P2P and click ‘OK’. © Copyright Reserved Autonics Co., Ltd.
  • Page 20 0.0→0001H, 0→ 0000H ㆍ Scale 0.000→0103H, 0.00→0102H 0.0→ 0101H, 0→0100H Transmits max. display value 30003(0002) High peak value among the measurement display values. Transmits min. display value 30004(0004) Low peak value among the measurement display values. © Copyright Reserved Autonics Co., Ltd.
  • Page 21 0x30000 D00000 N00021 Address 2 0x30000 D00004 N00062 Address 3 0x30000 D00008 N00103 Address 4 0x30000 D00012 N00144 11th At [Online] – [Connection Settings], select connection type. Select [Online] – [Write] to execute download. © Copyright Reserved Autonics Co., Ltd.
  • Page 22 2 Communication Setting © Copyright Reserved Autonics Co., Ltd.

  • Page 23: Operation Check

    3 Operation Check Operation Check © Copyright Reserved Autonics Co., Ltd.
  • Page 24 3 Operation Check © Copyright Reserved Autonics Co., Ltd.
