- Page 1 KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Assembly instructions Tripod KERN SFB-A01 Version 1.0 11/2012 SFB-A01-IA-e-1210...
- Page 2 Scope of delivery ..................... 3 Assembly ........................3 Assemble the tripod to the balance .................. 3 Assemble the display unit to the tripod ................4 Tripod SFB-A01 only suitable for the following SFB-models: SFB 60K2XLM SFB 100K2L SFB 100K2LM SFB 100K2XL...
- Page 3 3.1 Assemble the tripod to the balance Attach the tripod to the platform acc. to illustration using the 4 screws [1], securing disks and washers. (Ensure that the cable is not damaged nor squeezed.) Screw-out support screw [2] till it is safely fixed. SFB-A01-IA-e-1210...
- Page 4 Use the screw of the adapter to fix the display unit on the tripod. Fix the cable using cable ties in a way that it does not disturb the weighing process. SFB-A01-IA-e-1210...
