- Page 1 KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Assembly instructions Tripods KERN SFE-A01 / A02 / A03 Version 2.0 04/2014 Example SFE-A02 SFE-A01/A02/A03-IA-e-1420...
- Page 2 KERN SFE-A01 /A02 / A03 Version 2.0 04/2014 Assembly instructions Tripod Contents Technical data ......................2 Scope of delivery ..................... 3 Assembly ........................3 Assemble the tripod to the balance .................. 3 Assemble the display unit to the tripod ................4...
-
Page 3: Scope Of Delivery
2 Scope of delivery 1. Tripod 2. Support screw 3. 4 screws (large) with securing disks and washers for assembly to a balance 4. 4 screws (small) with nuts for assembly of the display unit 3 Assembly 3.1 Assemble the tripod to the balance Attach the tripod to the platform acc. - Page 4 3.2 Assemble the display unit to the tripod Screw tight the display unit to the tripod using the 4 small screws and the nuts according to the illustration. Fix the cable using cable ties in a way that it does not disturb the weighing process.
