Summary of Contents for Honda Grom125 2015

  • Page 1: Table Of Contents

    Contents Motorcycle Safety P. 2 Operation Guide P. 16 Maintenance P. 33 Troubleshooting P. 73 Information P. 88 Specifications P. 109 Index P. 113...
  • Page 2 Honda dealer knows your motorcycle Honda motorcycle. Your selection of a best. If you have the required mechanical Honda makes you part of a worldwide family “know-how” and tools, you can purchase an of satisfied customers who appreciate official Honda Service Manual to help you Honda’s reputation for building quality into...
  • Page 3 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this motorcycle safely is You WILL be KILLED or SERIOUSLY an important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 4: Motorcycle Safety

    Motorcycle Safety This section contains important information for safe riding of your motorcycle. Please read this section carefully. Safety Guidelines .........P. 3 Safety Labels ..........P. 7 Safety Precautions ........P. 9 Riding Precautions ........P. 10 Accessories & Modifications......P. 14 Loading ............P. 15...

  • Page 5: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
  • Page 6 Safety Guidelines We recommend that all riders take a certified Make Yourself Easy to See course approved by the Motorcycle Safety Make yourself more visible, especially at night, Foundation (MSF). New riders should start with by wearing bright reflective clothing, the basic course, and even experienced riders positioning yourself so other drivers can see will find the advanced course beneficial.
  • Page 7 Safety Guidelines check the tightness of critical nuts and bolts, Keep Your Honda in Safe Condition and check the handlebar, control levers, brakes, It’s important to keep your motorcycle properly and wheels. Ride slowly and cautiously. maintained and in safe riding condition.
  • Page 8 Safety Guidelines Carbon Monoxide Hazard WARNING Exhaust contains poisonous carbon monoxide, Carbon monoxide gas is toxic. a colorless, odorless gas. Breathing carbon Breathing it can cause monoxide can cause loss of consciousness and unconsciousness and even kill you. may lead to death. Avoid any areas or activities that If you run the engine in confined or even partly enclosed area, the air you breathe could contain...

  • Page 9: Safety Labels

    Safety Labels Safety Labels hazards that could cause serious injury. Read these labels carefully and don’t remove them. Safety and information labels on your If a label comes off or becomes hard to read, motorcycle provide important safety contact your dealer for a replacement. information and may warn you of potential continued...
  • Page 10 Safety Labels...

  • Page 11: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection. Ride cautiously and keep your hands on the ● handlebar and feet on the footpegs. Look for a DOT (Department of Keep passenger’s hands on the seat strap or Transportation) certification label on any helmet ●...

  • Page 12: Riding Precautions

    Riding Precautions ❙ Riding Precautions Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Break-in Period ❙ During the first 300 miles (500 km) of running, Jacket and Pants follow these guidelines to ensure your Protective, highly visible, long-sleeved jacket motorcycle’s future reliability and performance.
  • Page 13 Riding Precautions ❙ Exercise caution on low traction surfaces. Wet or Rainy Conditions ● The tires slip more easily on such surfaces Road surfaces are slippery when wet, and wet and braking distances are longer. brakes further reduce braking efficiency. Avoid continuous braking.
  • Page 14 Riding Precautions ❙ Parking with the Side Stand Parking 1. Stop the engine. Park on a firm, level surface. ● 2. Push the side stand down. If you must park on a slight incline or loose ● 3. Slowly lean the motorcycle to the left until its surface, park so that the motorcycle cannot weight rests on the side stand.
  • Page 15 Riding Precautions Refueling and Fuel Guidelines Follow these guidelines to protect the engine and catalytic converter: Use only unleaded gasoline. ● Use recommended octane number. Using ● lower octane gasoline will result in decreased engine performance. Do not use fuels containing a high ●...

  • Page 16: Accessories & Modifications

    Honda or make modifications to your motorcycle from its Follow all instructions in this owner’s original design.

  • Page 17: Loading

    Loading Loading Carrying extra weight affects your ● motorcycle’s handling, braking and stability. Always ride at a safe speed for the load you are carrying. Avoid carrying an excessive load and keep ● within specified load limits. Maximum weight capacity P.

  • Page 18: Operation Guide

    Basic Operation Flow ❙ Pre-ride Inspection (P39) ❙ Acceleration Carefully inspect your motorcycle to make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. ❙ Shift change (P30) ❙ Starting the Engine (P28) Start and warm the engine. ❙...
  • Page 19 ❙ ❙ Parking (P12) Braking Close the throttle and apply the Park on a firm level surface. front and rear brakes together. Use the stand, and lock the The brake light will indicate that steering. you have applied the brakes. ❙...
  • Page 20 Parts Location Rear brake fluid reservoir (P58) Fuse box (P87) Battery (P53) Front brake fluid reservoir (P58) Throttle grip (P68) Engine oil fill cap/dipstick (P54) Air cleaner (P57) Spark plug (P70) Engine oil drain bolt (P55)
  • Page 21 Clutch lever (P65) Fuel fill cap (P31) Seat (P52) Helmet holder (P32) Crankcase breather (P69) Drive chain (P62) Shift lever (P30) Side stand (P61)
  • Page 22 Instruments button Tachometer red zone button (excessive engine rpm range) Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life.
  • Page 23 Display Check When the ignition switch is turned on, all the mode and digital segments will show, and the tachometer segment progress to maximum scale and then disappear. If any part of these displays does not come on when it should, have your dealer check for problems.
  • Page 24 Instruments (Continued) Odometer [TOTAL] & Tripmeter [TRIP A/B] button switches between odometer & tripmeters. • Odometer: Total distance ridden. • Tripmeter: Distance ridden since tripmeter was reset (press and hold button to reset to 0.0 mile/km). Clock (12-hour display) button button...
  • Page 25 Display Setting 1 Clock setting: You can adjust the following settings. Turn the ignition switch on. • Clock setting Press and hold the buttons • Changing of speed and mileage unit until the hour digits start flashing. If the button was not pressed during the adjustment, and no buttons were pressed for about 30 seconds, the display will Press the...
  • Page 26 2 Changing of speed and mileage Press the button until the desired minute is displayed. unit: Press and hold the button to Press the button to select either advance the minute fast. “mph” and “mile” or “km/h” and “km”. Press the button.
  • Page 27 Indicators PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned on with the engine stop switch in the (Run) position. If it comes on while engine is running: Left turn signal indicator (P75) Right turn signal indicator Neutral indicator...
  • Page 28 Switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to (Off) position (the starter motor will not operate) to stop the engine. Turn signal switch Start button Pressing the switch turns the turn signal off. Horn button Headlight dimmer switch •...
  • Page 29 Ignition Switch Turns electrical system Switches the electrical system on/off, locks the on for starting/riding. steering. Key can be removed when in the OFF or LOCK position. Turns engine off. LOCK Locks steering. ❙ Steering Lock Locking Lock the steering when parking to help Turn the handlebar all the way to the left.
  • Page 30 Starting the Engine Start your engine using the following NOTICE procedure, regardless of whether the engine • If the engine does not start within 5 seconds, turn the is cold or warm. ignition off and wait 10 seconds before trying to start the engine again to recover battery voltage.
  • Page 31 Press the start button with the throttle If the engine does not start: completely closed. Open the throttle fully and press the start If you cannot start the engine, open the button for 5 seconds. throttle slightly (about 1/8 in (3 mm), Repeat the normal starting procedure.
  • Page 32 Shifting Gears ❙ Your motorcycle transmission has 4 forward Recommended Shift Points gears in a one-down, three-up shift pattern. Shifting Up From 1st to 2nd 12 mph (20 km/h) From 2nd to 3rd 19 mph (30 km/h) From 3rd to 4th 25 mph (40 km/h) Shifting Down From 4th to 3rd...
  • Page 33 Refueling Closing the Fuel Fill Cap Fuel fill cap Lower edge After refueling, align the fuel fill cap latch Ignition key of filler neck with the slot in the filler neck. Push the fuel fill cap into the filler neck until it snaps closed and locks.
  • Page 34 Storage Equipment The helmet holder and tool kit (Canada only) are located under the seat. Document bag is located underside of the seat. Tool kit (Canada only) Helmet holder Document WARNING Riding with a helmet attached to the holder can interfere with the rear wheel or suspension and could cause a Use the helmet holder only when parked.

  • Page 35: Maintenance

    Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. An optional larger tool kit may be available. Check with your Honda dealer’s parts department. Importance of Maintenance ..... P. 34 Throttle ............P.

  • Page 36: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance WARNING Keeping your motorcycle well-maintained is Improperly maintaining your absolutely essential to your safety and to motorcycle or failing to correct a protect your investment, obtain maximum problem before you ride can cause a performance, avoid breakdowns, and reduce air crash in which you can be seriously pollution.
  • Page 37 Importance of Maintenance For information about the exhaust emission and Maintenance Safety noise emission requirements of the U.S. Always read the maintenance instructions Environmental Protection Agency (EPA), the before you begin each task, and make sure that California Air Resources Board (CARB), and the you have the tools, parts, and skills required.

  • Page 38: Maintenance Schedule

    If you sell the motorcycle, these receipts should be transferred with the Maintenance work should be performed in motorcycle to the new owner. accordance with Honda’s standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. Keep an accurate record of maintenance to help ensure that your motorcycle is properly maintained.
  • Page 39 : Intermediate. We recommend service by your dealer, unless you : Technical. In the interest of safety, have your motorcycle have the necessary tools and are mechanically skilled. serviced by your dealer. Procedures are provided in an official Honda Service Manual 104). continued...
  • Page 40 Maintenance Schedule Frequency Items × 1,000 mi Refer to page × 1,000 km DRIVE CHAIN Every 300 mi (500 km): BRAKE FLUID BRAKE PADS WEAR BRAKE SYSTEM BRAKE LIGHT SWITCH HEADLIGHT AIM CLUTCH SYSTEM SIDE STAND SUSPENSION – NUTS, BOLTS, FASTENERS –...

  • Page 41: Maintenance Fundamentals

    Maintenance Fundamentals Cargo is secured properly. Pre-ride Inspection ● To ensure safety, it is your responsibility to Check the following items after you get on perform a pre-ride inspection and make sure your motorcycle: that any problem you find is corrected. A pre- Throttle action moves smoothly without ●...
  • Page 42 Maintenance Fundamentals Periodic Checks You should also perform other periodic maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently. Also, check the odometer reading against the Maintenance Schedule and perform all maintenance that is due.
  • Page 43 Maintenance Fundamentals Replacing Parts WARNING Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your motorcycle unsafe and cause a crash in which you can be seriously When ordering colored components, specify hurt or killed.
  • Page 44 Maintenance Fundamentals Electrolyte splashes into your mouth: ● Battery Rinse mouth thoroughly with water, and Your motorcycle has a maintenance-free type do not swallow. battery. You do not have to check the battery WARNING electrolyte level or add distilled water. Clean the battery terminals if they become dirty or The battery gives off explosive corroded.
  • Page 45 30 days using a charger designed specifically for 3. If the terminals are heavily corroded, clean your Honda, which can be purchased from your the terminals with a wire brush or sandpaper. dealer. Read the information that came with Wear safety glasses.
  • Page 46 Bump starting is also not recommended. NOTICE Installing non-Honda electrical accessories can overload NOTICE the electrical system, discharging the battery and possibly Replacing a fuse with one that has a higher rating greatly damaging the system.
  • Page 47 P. 110 higher oils, excluding oils marked as “Energy Conserving” or “Resource Conserving” on the If you use non-Honda engine oil, check the label circular API service symbol. to make sure that the oil satisfies all of the following standards:...
  • Page 48 Wipe up spills immediately and wash thoroughly. pins, or kinks, have the chain inspected by your Recommended brake fluid: dealer. Honda DOT 3 or DOT 4 Brake Fluid or Also inspect the engine sprocket and rear wheel equivalent sprocket. If either has worn or damaged teeth, have the sprocket replaced by your dealer.
  • Page 49 Use a dry cloth with high flash-point solvent. Use a soft brush if the chain is dirty. After cleaning, wipe dry and lubricate with the recommended lubricant. Recommended lubricant: Pro Honda HP Chain Lube or equivalent...
  • Page 50 Maintenance Fundamentals Air Cleaner Tires (Inspecting/Replacing) ❙ Checking the Air Pressure This motorcycle is equipped with a viscous type air cleaner element which cannot be cleaned Visually inspect your tires and use an air with compressed air or otherwise without pressure gauge to measure the air pressure at degrading its performance.
  • Page 51 Maintenance Fundamentals ❙ ❙ Inspecting for Damage Inspecting Tread Depth Inspect the tires for Inspect the tread wear indicators. If they cuts, slits, or cracks become visible, replace the tires immediately. that exposes fabric or cords, or nails or other foreign objects embedded in the side of the tire or the tread.
  • Page 52 Maintenance Fundamentals Do not install a tube inside a tubeless tire on ● WARNING this motorcycle. Excessive heat build-up can cause the tube to burst. Riding on tires that are excessively Use only tubeless tires on this motorcycle. ● worn or improperly inflated can cause The rims are designed for tubeless tires, and a crash in which you can be seriously during hard acceleration or braking, a tube-...
  • Page 53 Maintenance Fundamentals ❙ Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group of The service life of your tires is dependent on numbers and letters located on the sidewall of many factors, including, but not limited to, the tire.

  • Page 54: Removing & Installing Body Components

    Removing & Installing Body Components ❙ Seat Removal 1. Insert the ignition key into the seat lock. 2. Turn it clockwise, then pull the seat up Prongs and back. Seat ❙ Installation 1. Insert the prongs into the stays on the frame.

  • Page 55: Battery

    Removing & Installing Body Components Battery Battery 2. Remove the battery holder by removing the bolt. 3. Disconnect the negative terminal from Positive the battery. Bolt Battery holder terminal 4. Disconnect the positive terminal from the battery. 5. Remove the battery taking care not to drop the terminal nuts.

  • Page 56: Engine Oil

    Engine Oil Checking the Engine Oil Upper 1. If the engine is cold, idle the engine for 3 level to 5 minutes. 2. Turn the ignition switch off, and wait for 2 to 3 minutes. 3. Remove the oil fill cap/dipstick and wipe it clean.
  • Page 57 Engine Oil Adding Engine Oil Adding Engine Oil NOTICE Overfilling with oil or operating with insufficient oil can If the engine oil is below or near the lower cause damage to your engine. Do not mix different brands level mark, add the recommended engine oil. and grades of oil.
  • Page 58 Engine Oil Changing Engine Oil 4. Place a drain pan under the drain bolt. 6. Install a new sealing washer onto the 5. Remove the oil fill cap/dipstick, drain drain bolt. Tighten the drain bolt. bolt, and sealing washer to drain the oil. Torque: 18 lbf·ft (24 N·m, 2.4 kgf·m).

  • Page 59: Air Cleaner

    Air Cleaner Changing Air Cleaner Element Screws Use a new Honda Genuine air cleaner element or an equivalent specified for your motorcycle. NOTICE Using the wrong air cleaner element may cause premature engine wear or performance problems. 1. Remove the air cleaner case cover by Screws removing the screws.

  • Page 60: Brakes

    Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LWR or LOWER level mark or the 1. Place your motorcycle in an upright brake lever and pedal freeplay becomes position on a firm, level surface. excessive, inspect the brake pads for wear.
  • Page 61 Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front Check the condition of the brake pad wear Brake pads indicators. The pads need to be replaced if a brake pad is worn to the indicator. Inspect the brake pads from below Front the brake caliper.
  • Page 62 Brakes Adjusting the Brake Light Switch Adjusting the Brake Light Switch Check the operation of the brake light switch. Hold the brake light switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 63: Side Stand

    Side Stand Checking the Side Stand 3. Sit on the motorcycle, put the transmission in Neutral, and raise the side stand. 4. Start the engine, pull the clutch lever in, and shift the transmission into gear. 5. Lower the side stand all the way. The engine should stop as you lower the side stand.

  • Page 64: Drive Chain

    Drive Chain Inspecting the Drive Chain 3. Check the slack in the lower half of the drive chain midway between the Slack sprockets. Check the drive chain slack at several points Drive chain slack: along the chain. If the slack is not constant at 1 3/16 to 1 9/16 in (30 to 40 mm) all points, some links may be kinked and Do not ride your motorcycle if the slack...
  • Page 65 Drive Chain Adjusting the Drive Chain Slack 5. Inspect the sprockets. P. 46 Rear axle nut 6. Clean and lubricate the drive chain. Rear edge of adjusting P. 47 Adjusting nut slot Adjusting the Drive Chain Slack Adjusting the chain requires special tools. Chain Have the drive chain slack adjusted by your adjuster...
  • Page 66 Drive Chain Adjusting the Drive Chain Slack 5. Turn both adjusting nuts an equal number 8. Tighten the drive chain adjusting nuts of turns until the correct drive chain slack is lightly, then hold the adjusting nuts and obtained. Turn the adjusting nuts tighten the lock nuts.

  • Page 67: Clutch

    Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary have it replaced by your ❙ Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.
  • Page 68 Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Upper lock nut Freeplay Rubber dust cover ❙ Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. 1. Pull back the rubber dust cover. – 2. Loosen the upper lock nut. 3.
  • Page 69 Clutch Adjusting the Clutch Lever Freeplay 1. Loosen the upper lock nut and turn the Lower lock nut upper clutch cable adjuster all the way in (to provide maximum freeplay). Tighten the upper lock nut. 2. Loosen the lower lock nut. 3.

  • Page 70: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the motorcycle inspected by your dealer.

  • Page 71: Crankcase Breather

    Crankcase Breather Cleaning the Crankcase Breather 1. Place a drain pan under the crankcase breather tube. 2. Remove the crankcase breather tube and drain deposits. 3. Reinstall the crankcase breather tube. Crankcase breather tube...

  • Page 72: Spark Plug

    Spark Plug Checking Spark Plug Spark plug cap For the recommended spark plug, see “Specifications.” P. 110 Use only the recommended type of spark plug in the recommended heat range. NOTICE Using spark plug with an improper heat range can cause engine damage.
  • Page 73 Spark Plug Checking Spark Plug 5. Check the spark plug gap using a wire- 8. Tighten the spark plug: type feeler gauge. If the old plug is good: ● If adjustment is necessary, bend the 1/8 turn after it seats side electrode carefully.

  • Page 74: Other Adjustments

    Other Adjustments Adjusting the Headlight Aim You can adjust vertical aim of the headlight for proper alignment. To move the headlight case, loosen the bolt. Tighten the bolt after adjustment. Obey local laws and regulations. Raise Bolt Lower...

  • Page 75: Troubleshooting

    Troubleshooting Engine Will Not Start .........P. 74 Warning Indicators On or Flashing ...P. 75 PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) ....P. 75 Other Warning Indications ......P. 76 Fuel Gauge Failure Indication.....P. 76 Tire Puncture ..........P. 77 Electrical Trouble........P. 83 Battery Goes Dead ........P.

  • Page 76: Engine Will Not Start

    Engine Will Not Start ❙ ❙ Starter Motor Operates But Engine Starter Motor Does Not Operate Does Not Start Check the following items: Check the following items: Make sure engine stop switch is in ● Check the correct engine starting (Run) position P.

  • Page 77: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your motorcycle inspected by your dealer as soon as possible.

  • Page 78: Other Warning Indications

    Other Warning Indication Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.

  • Page 79: Tire Puncture

    Tire Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. We recommend you have this type of service Riding your motorcycle with a performed by your dealer. temporary tire repair can be risky. If After an emergency repair, always have the the temporary repair fails, you can tire inspected/replaced by your dealer.
  • Page 80 Tire Puncture Removing Wheels ❙ Front Wheel 3. Support your motorcycle securely and raise the front wheel off the ground Removal using a maintenance stand or a hoist. 1. Park on a firm, level surface. 4. Remove the front axle shaft, front wheel 2.
  • Page 81 Tire Puncture Removing Wheels Installation 4. After installing the wheel, apply the 1. Attach the side collars to the wheel. brake lever several times, then check if 2. Position the wheel between the fork legs the wheel rotates freely. Recheck the and insert the front axle shaft from the wheel if the brake drags or if the wheel right side, through the right fork leg and...
  • Page 82 Tire Puncture Removing Wheels ❙ Rear Wheel 4. Remove the drive chain from the rear wheel sprocket by pushing the rear Removal wheel forward. 1. Support your motorcycle securely and raise the rear wheel off the ground using a maintenance stand or a hoist. Drive chain 2.
  • Page 83 Tire Puncture Removing Wheels 5. Remove the rear axle shaft, side collars NOTICE and rear wheel. When installing the brake caliper into position, carefully Support the brake caliper assembly so fit the brake disc between the pads to avoid scratching that it doesn’t hang from the brake them.
  • Page 84 Tire Puncture Removing Wheels 3. Adjust the drive chain. P. 63 4. Install and tighten the rear axle nut. Torque: 44 lbf·ft (59 N·m, 6.0 kgf·m). 5. After installing the wheel, apply the brake pedal several times, then recheck that the wheel rotates freely.

  • Page 85: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the motorcycle Turn the ignition switch to the OFF or LOCK before charging.
  • Page 86 Electrical Trouble Burned-out Light Bulb ❙ Headlight Bulb 2. Pull off the connector without turning. 3. Remove the dust cover. 4. Press the pin down and pull out the bulb Bolts without turning it. 5. Install a new bulb and parts in the reverse order of removal.
  • Page 87 Electrical Trouble Burned-out Light Bulb ❙ ❙ Brake/Tail Light Front/Rear Turn Signal Bulb 1. Remove the screw. 2. Remove the turn signal lens. Brake/Tail light 3. Slightly press the bulb and turn it counterclockwise. Turn signal lens The brake and tail light uses several LEDs. Bulb If there is a LED which is not turned on, see your dealer for servicing.
  • Page 88 Electrical Trouble Burned-out Light Bulb ❙ License Plate Light Bulb 1. Remove the screws. 2. Remove the license plate light cover. 3. Pull out the bulb without turning. License plate light cover Screws Bulb 4. Install a new bulb and parts in the reverse order of removal.

  • Page 89: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Fuse box covers Before handling fuses, see “Inspecting and Replacing Fuses.” P. 44 ❙ Fuse Box Fuses 1. Remove the seat. P. 52 2. Open the fuse box covers. 3. Pull out the fuses one by one to check for a blown fuse.

  • Page 90: Information

    Information Keys.............P. 89 Honda Contacts ........P. 106 Instruments, Controls, & Other Features ..P. 90 Reporting Safety Defects....P. 108 Caring for Your Motorcycle.......P. 91 Storing Your Motorcycle ......P. 93 Transporting Your Motorcycle ....P. 94 You & the Environment ......P. 95 Vehicle Identification Number ....P.

  • Page 91: Keys

    Keys Keys Ignition key Be sure to record the key number provided with the original keys. Store the spare key and recorded key number in a safe location. To make a duplicate, take the spare key or the key number to your dealer. If you lose all keys and the key number, the ignition switch assembly will probably have to be removed by your dealer to determine the key...

  • Page 92: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Tripmeter Other Features The tripmeter returns to 0.0 when the read-out exceeds 9,999.9. Ignition Switch Document Bag The headlight is always on when the ignition switch is ON. Leaving the ignition switch ON The owner’s manual, registration, and with the engine stopped will drain the battery.

  • Page 93: Caring For Your Motorcycle

    Frequent cleaning and polishing is important to 3. Thoroughly rinse your motorcycle with plenty ensure the long life of your Honda. A clean of clean water and dry with a soft, clean motorcycle makes it easier to spot potential cloth.
  • Page 94 Caring for Your Motorcycle ❙ Washing Precautions Do not direct water near the headlight: ● Follow these guidelines when washing: Any condensation inside the headlight Do not use high-pressure washers: should dissipate after a few minutes of ● High-pressure water cleaners can damage running the engine.

  • Page 95: Storing Your Motorcycle

    Storing Your Motorcycle Panels NOTICE Even though the exhaust is made of stainless steel, it can Follow these guidelines to prevent scratches become stained. Remove all marks and blemishes as soon and blemishes: as they are noticed. Wash gently using a soft sponge and plenty ●...

  • Page 96: Transporting Your Motorcycle

    Never try to tow your motorcycle with a Maintenance Schedule. wheel or wheels on the ground. NOTICE For more information about storage, Towing your motorcycle can cause serious damage to the refer to the Honda Winter Storage Guide, transmission. available from your dealer.

  • Page 97: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a motorcycle can be containers and take them to a recycling center. enjoyable, but you must do your part to protect Call your local or state office of public works or the environment.

  • Page 98: Vehicle Identification Number

    Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your motorcycle and are required in order to register your motorcycle. They may also be required when ordering replacement parts. The VIN is stamped on the right side of the steering head and also appears on the Safety Certification Label attached to the under side of the frame.

  • Page 99: Emission Control Systems

    Emission Control Systems Emission Control Systems Your motorcycle engine emits combustion byproducts, including carbon monoxide (CO), oxides of nitrogen (NOx), and hydrocarbons (HC). Gasoline evaporation also emits hydrocarbons. Controlling the production of NOx, CO, and HC is important for the environment.
  • Page 100 Compliance with the terms of the Distributor’s Noise Emission Requirements Warranties for Honda Motorcycle Emission The EPA requires that motorcycles built after Control Systems is necessary in order to January 1, 1983 comply with applicable noise...
  • Page 101 Emission Control Systems ❙ Catalytic Converters Exhaust Emission Control System The exhaust system contains one or more The exhaust emission control system includes catalytic converters. Catalytic converters use a the following components that should not need catalyst to convert most of the harmful exhaust adjustment, although periodic inspection by gas compounds into harmless compounds.
  • Page 102 Emission Control Systems Crankcase Emissions Control System Noise Emission Control System ❙ TAMPERING WITH THE NOISE CONTROL The engine is equipped with a closed crankcase system to prevent discharging crankcase SYSTEM IS PROHIBITED: emissions into the atmosphere. U.S. federal law prohibits, and Canadian Blow-by gas is returned to the combustion provincial laws may prohibit, the following acts chamber through the air cleaner and the intake...
  • Page 103 Emission Control Systems ❙ AMONG THOSE ACTS PRESUMED TO Problems Affecting Motorcycle Exhaust CONSTITUTE TAMPERING ARE THE Emissions FOLLOWING ACTS: Have your motorcycle inspected and repaired by Removal of, or puncturing the muffler, ● your dealer if you experience any of the baffles, header pipes or any other component following symptoms: which conducts exhaust gases.

  • Page 104: Catalytic Converter

    A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine’s motorcycle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.

  • Page 105: Oxygenated Fuels

    Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.

  • Page 106: Authorized Manuals

    However, if you possess The Service Manual used by your authorized the proper tools, observe the safety standards, dealer is available from your Honda dealer or and are mechanically capable, you should find Helm, Inc. them easy to use.

  • Page 107: Warranty Coverage And Service

    Coverage Your warranty coverage is not voided if you Your new Honda is covered by the following perform your own maintenance. However, warranties: failures that occur due directly to improper Motorcycle Limited Warranty ●...

  • Page 108: Honda Contacts

    Honda dealer. Make an appointment for an American Honda Motor Co., Inc. inspection and diagnosis. You will be asked to If you wish to contact Honda directly to authorize that inspection, and your dealer will comment on your experiences with your return the results of the inspection.
  • Page 109 Dealer name and address ● Your Honda dealer can also supply information We will likely ask your Honda dealer to respond, about, riding events, and information about safety training available in your local area, and or possibly acknowledge your comments directly.

  • Page 110: Usa Reporting Safety Defects

    Highway Traffic Safety Administration Washington, DC 20590. (NHTSA) in addition to notifying You can also obtain other information American Honda Motor Co., Inc. about motor vehicle safety from: http://www.safercar.gov If NHTSA receives similar complaints, it may open an investigation, and if it finds...

  • Page 111: Specifications

    Specifications Specifications ■ Main Components Displacement 7.62 cu-in (125 cm Type JC61 Bore x stroke 2.06 x 2.28 in (52.4 x 57.9 mm) Compression Overall length 69.3 in (1,760 mm) 9.3:1 ratio Overall width 29.7 in (755 mm) Unleaded gasoline Overall height 39.8 in (1,010 mm) Fuel...
  • Page 112 Rear 130/70-12 56L Recommended SAE 10W-30, JASO T 903 standard MA, Pro Tire type Bias-ply, tubeless engine oil Honda GN4 4-stroke oil (USA & Canada) or Front VEE RUBBER V119C Recommended Honda 4-stroke oil, or an equivalent Tires Rear VEE RUBBER V119C...
  • Page 113 Specifications ■ Torque Specifications Recommended drive chain Pro Honda HP Chain Lube or equivalent Engine oil drain bolt 18 lbf·ft (24 N·m, 2.4 kgf·m) lubricant Air cleaner element screw 0.8 lbf·ft (1.1 N·m, 0.1 kgf·m) Drive chain slack 1 3/16 to 1 9/16 in (30 to 40 mm) Air cleaner case cover screw 0.8 lbf·ft (1.1 N·m, 0.1 kgf·m)
  • Page 114 Information Record Engine No. Color Label & Code Owner’s Name Address City/State Phone Dealer’s Name Address City/State Phone Service Manager...

  • Page 115: Index

    Index Index Accessories..........14 Caring for Your Motorcycle...... 91 Air Cleaner ..........57 Clock............22 Authorized Manuals ....... 104 Clutch System ..........65 Color Label..........41 Crankcase Breather ........69 Basic Operation Flow........ 16 Battery ..........42, 53 Brake Light Switch ........60 Digital Clock Adjustment......
  • Page 116 Loading Guidelines........15 Headlight Aim ........... 72 Headlight Dimmer Switch......26 Helmet Holder ........... 32 Maintenance High Beam Indicator ......... 25 Fundamentals ...........39 Honda Contacts ........106 Importance ..........34 Horn Button..........26 Safety ............35 Schedule...........36 Maximum Weight Limit ......15 Modifications ..........14...
  • Page 117 Neutral Indicator........25 Recommended Fuel ............31 Oil ............45 Odometer ..........22, 90 Refueling ........... 31 Removal Engine ..........45, 54 Battery ............. 53 Other Warning Indication ......76 Seat............52 Oxygenated Fuels ........103 Repair Kit ........... 77 Reporting Safety Defects (U.S.) ....
  • Page 118 Stopping Engine........90 Storage Warning Indicators On ......75 Equipment..........32 Warranty Coverage and Service .....105 Owner’s Manual......... 32, 90 Washing Your Motorcycle......91 Tool kit (Canada only)....... 32 Weight Limit ........15, 109 Storing Your Motorcycle......93 Wheels Switches ............. 26 Front removal ...........78 Rear removal..........80 Tachometer..........
