- Page 1 User’s Manual MJ-80...
- Page 2 Version 1.0 01/2019 All rights reserved. Copyright © …. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form, by any means (electronic, photocopying, recording, or otherwise) without the prior written permission of the publisher. Copyright protection claimed includes all forms and matters of copyrightable material and information allowed by statutory or judicial law or hereafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as screen displays, menus, etc.
-
Page 3: Table Of Contents
Barcode Scanner .............................. 15 GPS ..................................15 Product Care ..............................17 Temperature & Humidity ........................... 17 General Use - Operating temperature ........................17 Transportation and Storage ........................... 17 Transporting the MJ-80 Device .......................... 17 Safety ................................. 18 9. Trouble shooting ................................. 20... - Page 4 Appendix A Technical Specifications .......................... 21 Appendix B Compliance Information ......................... 22 B1 FCC Statement .............................. 22 Part 15B Equipment ............................... 22 FCC RF Radiation Exposure Statement: ......................... 23 B2 CE Statement ..............................23 B3 Directives and Standards ..........................23...
-
Page 5: Introduction
In this manual we use three (3) levels of Advisements as follows: TheNotesymbolisusedfornotifyingtheuserofsomethingimportantorofsomethingthatneedsspecialattention. TheCautionsymbolisusedtoinformofsomethingthatcouldcauseharmto,ormalfunctionof,theequipment. TheWarningsymbolisusedtoinformofsomethinginwhichthereisaconceivableriskofharmtotheuserifthe Warning isignored. Symbols andMarkings This section provides information about the symbols that are used on the MJ-80, its accessories, or packaging. Symbol or Markings Description Power On/Off Indicator Disposeofinaccordancewithyourcountry'srequirements. CEistheabbreviationoftheEuropeanCommunitiesandthis marktellscustomsofficialsintheEuropeanUnionthatthe productcomplieswithoneormoreoftheECDirectives. -
Page 6: Exploring Your Device
2. Exploring Your Device Package Contents In addition to the primary tablet unit, your product carton should contain all of the below items. MJ-80 Tablet PC Packing Contents AC Adapter Packing Lists, etc.. Documents Please inspect all items. If any items are missing or appear damaged, please inform your dealer immediately. -
Page 7: Device Layout
3. Device Layout Front, Top and Bottom View Item Component Description Power Button Turn power On/Off – Hold 10s to Reset Volume + Button Increases the audio volume Volume - Button Decreases the audio volume Barcode Scanner Optically Scans 1D or 2D Barcodes, if Equipped (Optional) Front Camera Records Photos/Video... -
Page 8: Left-Side View
Left-side View Item Components Description Function Key 1 Programmable – Can be used for special functions Function Key 2 Programmable – Can be used for special functions USB 3.0 Connect any external USB device or storage volume. HDMI Connect a secondary display via HDMI Audio Connect headphones, speakers, or another external audio device... -
Page 9: Rear View
Rear View Position Components Description Speaker Sends out Audio Rear Camera Records Photos/Video... -
Page 10: Managing Device Power
Optional Docking Station You can also charge the MJ-80 tablet using an optional, available Docking Station. The Docking Station has DC input and USB ports, which connect to the tablet via the docking connector when the tablet is docked. The docking connecter is shown in the layout view (Position 6) in chapter 2. The Docking... -
Page 11: Power Supply And Battery
Power is supplied to the MJ-80 tablet by one, internal, rechargeable battery. The Android OS will provide warnings to recharge your device at certain power levels as battery power drops. If the MJ-80 device exhausts available battery power, it will shut down automatically until a charger is connected or it is placed in a docking station connected to an AC power source. -
Page 12: Checking The Charging Level
Checking the charging Level To check the battery charge level of the MJ-80, use the battery monitor within android system. Power LED Indicators ThePowerLEDwillonlylightwhentheACadapterispluggedin or the device is on the charging dock. Green — Fully charged Blue — Charging 5. -
Page 13: Using The Barcode Scanner (Option)
Using the Barcode Scanner (Optional) This device may include an optional internal Barcode Scanner module. This is an optical input device used to capture and read information contained in a barcode. Most common 1D and 2D barcode formats can be read. The location of the reader is shown in the product layout in Chapter 2 (Position 4). Press the physical scan button (see Position 7 or 8 in chapter 2, page 8) on the tablet to activate the scanner) Any single barcode placed within the scanner field of view will be read. -
Page 14: Econtroller App And Its Applications
6. eController App and its Applications The eController App is designed to quickly check if device modules are working properly. It tests the following modules: 1. Fingerprint Reader 2. Barcode Scanner 3. GPS 4. Assign function to programmable buttons F1 and F2 Many of the above the modules are optional items. -
Page 15: Fingerprint Scanner
Fingerprint scanner When activated, the user may place a fingertip on the scanner, and the scanner will read the print and display it in the indicated area of the screen, until removed. The fingerprintscannerwill operate continuously once this test is selected until exited. To preserve battery and enable all tablet functions, please exit the test when complete. - Page 16 In the graphic below, please see the following elements: GPS signal bar chart, showing the signal strength for each satellite detected, as well as the accuracy and status of the GNSS network. Satellite positions in the sky, shown on a rotating compass. Your current location on the earth shown as text and on a world map.
-
Page 17: Product Care
7. Product Care Temperature & Humidity General Use - Operating temperature The MJ-80 is best kept in dry conditions at room temperature. The recommended range for temperature and the humidity value for the device is as follows: Operation Temperature: 0-45℃ (32 ℉ to 113 ℉) ... -
Page 18: Safety
Power Supply and Batteries The MJ-80 device contains one rechargeable battery. All rechargeable batteries degrade over time. Thus, the possible usage times for the MJ-80 after a full charge can become shorter over time than when the device was new. - Page 19 Temperature Due to use in direct sunshine or in any other hot environment the MJ-80 device may have hot surfaces. There is a built-in temperature sensor that monitors the temperature. If the sensor detects high internal temperature, the device will automatically trigger a Shut Down. It may take...
-
Page 20: Trouble Shooting
Electricity The device contains no user serviceable parts. Do not open the case of the MJ-80 Tablet Device. Doing so will void the product warranty and may expose you to electrical hazards. Software Using an antivirus program is strongly recommended. -
Page 21: Appendix A Technical Specifications
Appendix A Technical Specifications Ruggedness IP-65 Waterproof Drop: 4FT drop resistant on 26 corners to plywood (MIL-STD-810G) Shock resistant: MIL-STD-810G, method 516.6, procedure I ESD Protection: 8KV touch, 15KV air Processor Rockchip RK3368 Octa-core Cortex-A53 1.5G G6110 GPU 4K@60fps H.265 HDMI2.0 with HDCP2.2 Android 7.1 Security Trust Zone Technology Support... -
Page 22: Appendix B Compliance Information
Dimension: 227 x 151 x 24 mm Weight: 0.75KG AC adaptor 12V 3A input 110 -240V AC in, standard US plug Option: multi-nation plugs Environmental Operation temperature: 0-45°C Storage Temperature: -20 -- 60 °C Humidity: 10% to 90% ROHS: Compliant Regulatory FCC /IATA/IEC62133/IEC60601-1 Appendix B... -
Page 23: Fcc Rf Radiation Exposure Statement
Member States relating to electromagnetic compatibility and Radio Equipment Directive (RED) 2014/53/EU to meet the regulation of the radio equipment and telecommunications terminal equipment. B3 Directives and Standards The MJ-80 complies with the following directives: Medical Device Regulation (MDR) ...
