Closed user group (CUG) is a call restriction service among the optional services of
X.25. It is mainly used to restrict originating or receiving call capabilities for data
transmission equipment (DTE) users. The users in the same CUG can still call each
other, but users of different CUGs cannot. As a result, this allows you to form a
private data communication subnet on an X.25 public data communication network.
The X.25 CUG service can be configured using these CLI commands:
x25 map protocol protocol-address x121-address x.121-address
closed-user-group group_number
x25 call-facility closed-user-group group-number undo x25 call-facility closed-
user-group
x25 cug-service [ incoming-access ] [ outgoing-access ] [ suppress { all |
preferential } ]
undo x25 cug-service
x25 local-cug cug-number network-cug cug-number [ no-incoming ] [ no-
outgoing ] [ preferential ]
undo x25 local-cug cug-number
display x25 cug

3. BRI 128K Leased Line

BRI stands for Basic Rate Interface, which is the basic ISDN configuration. This
configuration consists of two B-channels that can carry voice or date at a rate of
64Kbps, and one D-channel, which carries call-control information. The current
release supports a 128Kbps leased line by combining the two 64Kbps B-channels into
a single 128Kbps physical channel.
You can use these CLI commands to configure the ISDN 128K leased line:
dialer isdn-leased channel-number
undo dialer isdn-leased channel-number
dialer isdn-leased 128k
undo dialer isdn-leased 128k
isdn link-mode p2p
undo isdn link-mode p2p

4. HWPing

HWPing is a tool used for testing the performance of the protocols operating on a
network. It is an enhancement to the ping function that only allows you to test the
roundtrip delay (time required for a packet to travel from the local end to a specified
destination and return to the local end again). HWPing enhances the ping function by
detecting the state (enabled or disabled) of a DLSW, DHCP, FTP, HTTP, or SNMP
Server, and testing the response time for each type of service.
