www.marchetti.eu
MOBILE ACCESS TOWER
O L Y M P O
Instructions for use
and maintenance
The products identified in this handbook have
been manufactured by MARCHETTI s.r.l. With
QUALITY SYSTEM MANAGEMENT, certified by
Tuv Italia, in accordance with ISO 9001
Instructions Manual EN 1298 – IM – it x en
Mobile access towers must only be used for finishing, maintenance and similar works. This
instructions manual contains important instructions on use, maintenance and safety of the
mobile access tower; the operator must be completely aware of them before use. Strictly
complying with this manual means working in compliance with the provisions of the current
standard on health and safety in the workplace Leg. Decree. 09.04.2008 no. 81.
MARCHETTI S.r.l.
Via Piemonte, 22
06062 Città della Pieve - Perugia - Italy
Tel. + 39 0578 20348 - Fax + 39 0578 226488
European standard EN 1004
CUSTOMER ASSISTANCE DOCUMENT
N. 120 REV. 2 DATED 08/01/2018
info@marchetti.eu
www.marchetti.eu
Code 11115
Advertisement
Table of Contents
Related Manuals for Marchetti OLYMPO
Summary of Contents for Marchetti OLYMPO
- Page 1 O L Y M P O Instructions for use and maintenance The products identified in this handbook have been manufactured by MARCHETTI s.r.l. With QUALITY SYSTEM MANAGEMENT, certified by CUSTOMER ASSISTANCE DOCUMENT Tuv Italia, in accordance with ISO 9001 N. 120 REV. 2 DATED 08/01/2018 Code 11115 Instructions Manual EN 1298 –...
- Page 2 ATTENTION: • Read and understand this manual in its entirety. • Follow the instructions as indicated. • Before any installation, verify the integrity of each individual component. Do not use damaged or not whole components The mobile access tower is made according to the standards.
-
Page 3: Table Of Contents
Table of elements composing the configurations A1 - A2 - A3 pag. 7 To create configurations with final tower H=0.85 m (A1T-A2T-A3T) pag. 7 simply add the following elements “OLYMPO” TOWER DESIGN pag. 8 CONFIGURATIONS UNI EN 1004 pag. 9 ASSEMBLY AND DISMANTLING pag. -
Page 4: Reference Standards
“Consumers’ Code”. 2. DESIGNATION, CLASS, CAPACITY OLYMPO working tower EN 1004 – 3 – 5 / 5 XXCD manufactured in compliance with Leg. Decree 81/08 and Technical Standard UNI EN 1004; Class of loads distributed uniformly equal to “3” (2.0 KN/m2);... -
Page 5: Declaration Of Conformity
MARCHETTI s.r.l. with headquarters in Città della Pieve (Pg) - Via Piemonte, 22: DECLARES - that the mobile tower called OLYMPO was manufactured in compliance with Leg. Decree 09.04.2008 no. 81 and in particular the Technical Standard EN 1004 (July 2005)) - that it is manufactured in compliance with the prototype which has surpassed rigidity testing, pursuant to Appendix “A”... -
Page 6: General Information
4 GENERAL INFORMATION 4.1 Access to work platform Access to the work platform can only take place inside the tower using one of the following methods: - vertical rung ladder, composed of uprights on the side frames of the structure - inclined rung ladder, internal - inclined step ladder, internal. -
Page 7: Identification
5 IDENTIFICATION UNI EN 1004 - Class “3” (2.00 KN/m Overall permitted load 200 kg Maximum number of surfaces loaded simultaneously Table of elements composing the configurations A1 - A2 - A3 Code Component Elements Weight CONFIGURATIONS 21335 Tower 21329 Support frame 5,00 21327 Horizontal bar 0,55... -
Page 8: Olympo" Tower Design
“OLYMPO” TOWER DESIGN FINAL TOWER GUARDRAIL WORK PLATFORM TOWER BASE... - Page 9 CONFIGURATIONS EN 1004 H Tower = 2,00 H Tower = 3,70 H Tower = 5,40 H Working = 0,80 H Working = 2,40 H Working = 4,10 H Tower = 2,90 H Tower = 4,60 H Tower = 6,20 H Working = 1,60 H Working = 3,30 H Working = 5,00...
-
Page 10: Assembly And Dismantling
6 ASSEMBLY AND DISMANTLING 6.1 General information For assembly and dismantling of the mobile access towers, at least 2 people are necessary and it is indispensable they are familiar with the assembly and use instructions; b) based on the height which must be reached, choose to set up one of the configurations outlined on page 7. - Page 11 Continue the assembly operations by coupling the ends of the connecting battens and the diagonal bars to the pins on the frames . Position the flat elements of the scaffolding on the fourth rung from the bottom of the first two side frames; firstly, position the 2 long toeboards parallel to the treadable surface, then the 2 short toeboards, fitting them in the respective compartments in...
- Page 12 Continue assembly of the upper tower with insertion of the ends of the battens and the diagonal bars to the pins on the frames. If the mobile access towers being set up should have a work platform placed at a height over 2 metres, at this point, you have to assemble the 4 stabilizer braces.
-
Page 13: Dismantling Instructions
To continue assembly of the tower, at this point, at least one of the operators responsible for assembly should wear a safety harness and climb on the next work platform from inside the tower through the specific trapdoor; gradually, as the assembly operations proceed of the tower, you should take care to position the scaffolding in such a position to guarantee the operator present at a height moves in an... -
Page 14: Use
8.2 Use It is not permitted to increase the height of the scaffolding using ladders, crates or other devices; b) it is compulsory to access the work platform from inside the tower, according to one of the three possibilities planned. -
Page 15: Instructions For Use And Maintenance
Legislative Decree 09.04.2008 no. 81 www.marchetti.eu CERTIFICATED EN ISO 9001 MOBILE ACCESS TOWER O L Y M P O Instructions for use and maintenance (This Instruction Manual must consulted in conjunction with the EN 1298-IM-it x en Instruction Manual for the... -
Page 16: General Information
10 GENERAL INFORMATION 10.1 Configurations table according to Leg. Decree 81/08 H. max H. max Tower Final No min No Braces Base Wall Tower Level 1,68 Tower Levels H< 7m Sect anchorage Every 2 9,60 m 8,30 m n° 5 n°... -
Page 17: Access To Work Platform
10.2 Access to work platform It is compulsory to access the work platform inside the tower, the uprights on the side support frames composing the access ladder. People responsible for using the mobile access tower must use a fall-proof device connected to the safety harness that limits free falling to no more than 0.70 metres. -
Page 18: Six-Monthly Service
SIX-MONTHLY SERVICE Mobile access tower Mod. Service of Numerical verification of components Cleaning of components Integrity of components Absence of oxidised areas Integrity of welding Lubrication of tightening screws Lubrication of pins and sleeves Efficiency of wheels and braking devices...
