- Page 1 Copyright © BEP Marine Limited, All rights reserved 600-GD & 600-GDL 600 SERIES GAS DETECTOR INSTALLATION OPERATING INSTRUCTIONS INST-600-GD-V3 10/10/07...
- Page 2 Copyright © BEP Marine Limited, All rights reserved This page has been deliberately left blank. Page INST-600-GD-V3 10/10/07...
-
Page 3: Table Of Contents
Copyright © BEP Marine Limited, All rights reserved Table of Contents WARRANTY........................ 3 IMPORTANT ....................... 3 CAUTIONS WHEN USING GAS SENSORS ............. 3 FEATURES ........................4 SPECIFICATION ......................4 INTRODUCTION ......................4 FAULT DETECTION....................4 DIMENSIONS ......................5 WIRING DIAGRAM ....................6 10 CONTROL HEAD INSTALLATION................. -
Page 4: Warranty
1 Warranty The warranty of this BEP MARINE LTD product is for Two Years from date of sale to original purchaser. BEP MARINE L assume the cost of removal or refitting of the product, or any other incidental cost that may arise, as the result of defect in workmanship. -
Page 5: Features
7 Fault Detection The nominal alarm point of the 600 series is 20% of the LEL (Lower Explosive Limit) of LPG/CNG in Air. In the event of a the alarm activating, close the manual valve on your gas bottles and open hatches to ventilate the area. All fans and blow ventilate must be ignition-protected types. -
Page 6: Dimensions
Copyright © BEP Marine Limited, All rights reserved 8 Dimensions Page INST-600-GD-V3 10/10/07... -
Page 7: Wiring Diagram
Copyright © BEP Marine Limited, All rights reserved 9 Wiring Diagram Page INST-600-GD-V3 10/10/07... -
Page 8: Control Head Installation
Copyright © BEP Marine Limited, All rights reserved 10 Control Head Installation For ease of operation, the control head should be mounted in a convenient position close to your gas appliances and in a where the control head can be seen and heard easily. The unit can be either surface mounted or recessed into a 2.5mm 11 Sensor Installation ... -
Page 9: Test / Alarm Mute Button
Copyright © BEP Marine Limited, All rights reserved 13 Test / Alarm Mute Button When the ‘TEST’ button is pressed in normal operation mode it will - Turn on the external alarm Turn on the blower Turn off the solenoid ... - Page 10 Copyright © BEP Marine Limited, All rights reserved Page INST-600-GD-V3 10/10/07...
- Page 11 Copyright © BEP Marine Limited, All rights reserved This page has been deliberately left blank. Page 10 INST-600-GD-V3 10/10/07...
- Page 12 Copyright © BEP Marine Limited, All rights reserved BEP MARINE BEP AUTOMOTIVE 13 Tarndale Grove 13 Tarndale Grove Albany, Auckland, N.Z. Albany, Auckland, N.Z. Ph: +64 9 415 7261 Ph: +64 9 415 7261 Fax: +64 9 415 9327 Fax: +64 9 415 9327 www.bepmarine.com...
Need help?
Do you have a question about the 600 Series and is the answer not in the manual?
Questions and answers
Good day from the Netherlands, our 600 GDL probably has a malfunction. The voltage for the gas solenoid drops to 4,4 volts and this is not enough to keep the valve open. Is this a technical malfunction? What should the correct voltage be? Can this drop from 12 volt to 4,4 volt be bypassed so the valve remains open? Thanks for your reply
Yes, a voltage drop from 12 volts to 4.4 volts on the BEP Marine 600 Series GDL is a technical malfunction. The 600-GDL is designed for 12V DC systems and requires 10–15V DC to operate correctly. The solenoid valve should receive 12.5 volts and must draw no more than 800mA to stay open.
