DVD VIDEO RECORDER / VIDEO CASSETTE RECORDER
D-VR610KU
OWNER'S MANUAL
1VMN24593 / E9KGAUD
Owner's Record
The model number and serial number are on the back
of your DVD Recorder. Record these numbers in the spaces
below. Refer to these numbers whenever you
communicate with your Toshiba dealer about this DVD
Recorder.
Model number:
Serial number:
© 2008 Toshiba Corporation
2007/12/19 22:40:41
2007/12/19 22:40:41
