Summary of Contents for Adtron 610200094
- Page 1 Adtron Corporation PN: 610200094 ” ” March 2006 Rev. 003...
-
Page 2: Esd Warning
ESD Warning Before handling the I35MB, or any media associated with the I35MB, ensure that you are working in an ESD-safe environment. Notice This manual describes the features of the Adtron I35MB. Adtron reserves the right to modify, amend, or in any way change the contents and/or products described herein, at any time, without notification. -
Page 3: Table Of Contents
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) Attributes S.M.A.R.T Attribute Table S.M.A.R.T Attribute Notes LED Indicators IDLE State – No host access ACTIVE State – Host access I35MB Dimension Drawings Appendix I Sales and Technical Support Standard Warranty Revision Control Rev. 003, PN: 610200094... -
Page 4: Introduction
Host operations continue with a single faulted disk drive or during a rebuild • Full error detection and management without host intervention • Field upgradeable firmware prevents future obsolescence IDE Jumper Options Adtron I35MB Operations Manual LEDs, Buzzer, and Mirror Control buttons Flex Cable Power Connector Rev. 003, PN: 610200094... -
Page 5: Related Documents
Activity LED. Refer to Figure 2 for the location of this jumper. The following figure shows the jumper location on the I35MB: 40-pin connector Figure 2 I35MB Jumper Locations Adtron I35MB Operations Manual IDE jumper options Power connector Rev. 003, PN: 610200094... -
Page 6: Setting Master/Slave And Cable Select
Pins 5 and 6 in Figure 4 are used for a remote-mounted Activity LED. Pin 6 runs through a 120 Ohm resistor to +3.3V. See the I35MB Product Specification for signal descriptions. Adtron I35MB Operations Manual Through 120 ohm on-board resistor Rev. 003, PN: 610200094... -
Page 7: Interface Connectors
Static Sensitive - The I35MB is a static sensitive device. When installing and uninstalling the I35MB, take precautions to ensure that static does not discharge into the I35MB. Adtron I35MB Operations Manual 40-pin connector 4-pin Power connector Rev. 003, PN: 610200094... -
Page 8: Inserting The I35Mb
I35MB in the chassis. See Figure 6 for mounting holes, screw size and maximum depth. 8. Put the cover on the chassis and screw it down. 9. Power on the computer. 6-32 x 3.8mm[. 1 50"] MAX. DEPTH Figure 6 Mounting Holes Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 9: Removing The I35Mb
Any operating system chosen that is compatible with IDE devices will be acceptable for use with the I35MB. The method of installing a specific operating system can vary, so consult the operating system documentation for instructions. Rev. 003, PN: 610200094... -
Page 10: I35Mb Leds And Mirror Control Buttons
Orange flashing – Soft fault Green solid – Power on Orange solid – Hard fault Orange flashing – Soft fault Function Audible alarm indicates error. Push button to turn off. Controls Bank 0 mirroring Controls Bank 1 mirroring Rev. 003, PN: 610200094... -
Page 11: Mirror Control Button Functions
Bank Access LED Feedback LED flashes slow (1/sec) LED flashes medium (2/sec) LED flashes fast (4/sec) LED solid on LED off Adtron I35MB Operations Manual Function Power up or down bank Mirror Rebuild No Operation Reserved No Operation Rev. 003, PN: 610200094... -
Page 12: Bank Hard Faults
Refer to Rebuilding a Bank on page 13. At this time, one of two actions is required: • Rebuild the faulted drive • Replace and rebuild the faulted drive Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 13: Turning The Buzzer Off
2. If accessible from the front cover, pop the faceplate off the bay with the I35MB inserted. Push the Buzzer Reset button (S4) on the I35MB to turn off audible alarm, if applicable. Adtron I35MB Operations Manual Rev. 003, PN: 610200094... - Page 14 Not doing so will cause irreversible damage. If IDE Connector during any of the actions listed, Bank 0 the flex cable becomes damaged or unusable, please contact Adtron Technical Support. Rev. 003, PN: 610200094...
-
Page 15: Resetting Mirroring Indicators
2. Cycle the I35MB power to the ON state (for 5 seconds or more), then the OFF state. 3. Insert media into desired banks. 4. Cycle power ON. 5. Once powered ON, all subsequent writes will be mirrored. Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 16: Rebuilding A Bank
Any media inserted into a bank that is smaller than the original capacity can not be used for mirroring. Rebuild attempts to a smaller media will not start. The LEDs will indicate a mirror fault condition. Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 17: Aborting A Button Press
Aborting a button press If the bank button is pressed for longer than 20 seconds, no operation is performed. This is provided as an opportunity to abort a button press. Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 18: Using The I35Mb Rail Kit
Important: Should a drive be replaced and a new drive assembled with the original I35MB Rail Kit, a new chassis ground protection material will be required. For example, Adtron suggests Kapton tape. (# 5) to the rear edge of the drive. Figure 11 I35MB Rail Kit Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 19: Self-Monitoring, Analysis And Reporting Technology) Attributes
Attribute #126: Soft Fault – Bank 0: Attribute identifies the Bank 0 media that has experienced a soft fault. Attribute #127: Soft Fault – Bank 1: Attribute identifies the Bank 1 media has experienced a soft fault. Rev. 003, PN: 610200094... -
Page 20: S.m.a.r.t Attribute Table
64-bit field showing which <200: some faulted media 200: all mirrors 64-bit field showing which media <200: some faulted 200: all mirrors 64-bit field showing which media <200: some faulted Reserved for future use Raw Data Threshold Rev. 003, PN: 610200094... -
Page 21: S.m.a.r.t Attribute Notes
The DMA error counter is reset to zero with any hard reset. Table 4 S.M.A.R.T. Attribute Notes Adtron I35MB Operations Manual Value (8 bits) (eight, 8-bit bytes) Degrees C (Note 194) Unsigned integer Raw Data Threshold Rev. 003, PN: 610200094... -
Page 22: Led Indicators
Replace drive and rebuild (Hard fault). Button released, processing Replace drive and rebuild. Must perform rebuild Button released, processing. May take 6 hours or more. Immediately resume normal operations. Bank read fault Replace drive and rebuild. Rev. 003, PN: 610200094... -
Page 23: Active State - Host Access
Button pushed while on- line. Button released, processing request. Button released, processing. Replace drive and rebuild. Must perform rebuild. Button released, processing. May take 6 hours or more. Immediately resume normal operations. Bank read fault. Replace drive and rebuild. Rev. 003, PN: 610200094... -
Page 24: I35Mb Dimension Drawings
Adtron I35MB Operations Manual I35MB Dimension Drawings 25.3 .997 101.6 4.000 Figure 11 I35MB Rev. 003, PN: 610200094... -
Page 25: Appendix I
Rail Retention Screw (M3 x 5) One (1) Rail – Left One (1) Rail – Right One (1) Drive Assembly Retention Screw (M2. 5x9) Two (2) Chassis Ground Protection Barrier Table 7 Parts Supplied Adtron I35MB Operations Manual Rev. 003, PN: 610200094... -
Page 26: Sales And Technical Support
Europe - Sales Tel: +41-56-496-5640 Fax: +41-56-496-5648 Email: eurosales@adtron.com Nordic - Sales Tel: +45-4557-0754 Fax: +45-4557-0753 Email: nordic@adtron.com Germany – Sales Tel: +49-821-589-9914 Fax: +49-821-589-7190 Email: deutsche@adtron.com Europe – Technical Support Tel: +45-4557-0754 Fax: +45-4557-0753 Email: eurotech@adtron.com Rev. 003, PN: 610200094... -
Page 27: Rev. 003, Pn
Revision Control Author Date Sections Apr 2005 Aug 2005 Connector Mar 2006 SMART, Rail Kit Adtron I35MB Operations Manual Description Original 8-pin change to the connector Adding SMART attributes/ and information. Rail Kit guide. Rev. 003, PN: 610200094...
