Table of Contents • Important Safety Information ... 3 SAFETY PRECAUTIONS ... 3 IMPORTANT SAFETY INSTRUCTIONS ... 3 • Supplied Accessories ... 5 • Symbols Used in this Manual ... 5 • Trademark Information ... 5 • Features ... 6 •...
Important Safety Information SAFETY PRECAUTIONS CAUTION: VISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM. AVIS WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning fl...
Page 4
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. WARNING: Changes or modifi cations to this unit not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate the equipment. On Placement •...
Supplied Accessories Remote Control with Batteries (AAA x 2) ... x 1 Owner’s Manual ... x 1 Quick Start Guide ... x 1 Symbols Used in this Manual To specify for which media type each function is, we put the following symbols at the beginning of each item to operate.
Features Blu-ray Disc™ You can enjoy Blu-ray Disc™ which is capable of storing fi ve times more data than a conventional DVD. BD-Java With some Blu-ray Disc™ which support Java applications, you can enjoy the interactive functions such as games or interactive menus.
Identifi cation of Controls Front Panel Disc tray Power indicator Remote sensor OPEN/CLOSE button STOP button Rear Panel AC power cord • Connect to a standard AC outlet to supply power to this unit. • Unplug this cord from the AC outlet to completely turn off the unit.
Identifi cation of Controls Remote Control POWER GOTO Clear HOME MENU MENU BONUS VIEW POP/TOP PLAY SKIP STOP SKIP PAUSE STEP SLOW INFO RETURN NETFLIX RANDOM ANGLE PIC RESOLUTION AUDIO 2nd. SUB 2nd. AUDIO REPEAT SE-R0402 Item Description OPEN/CLOSE Press to open or close the disc tray.
Page 9
Identifi cation of Controls Item Description • In playback mode, press GOTO, then press number buttons to enter a Number title, chapter, track, time or buttons fi le number. • In menu mode, press to enter the parental code password. CLEAR Press to clear an input error.
Identifi cation of Controls Operating with the remote control Point the remote control at the remote sensor and press the buttons. POWER Distance: About 5 m from the front of the remote sensor. Angle: About 30° in each direction of the front of the remote sensor.
Connections Connecting to a digital amplifi er/AV receiver Route the sound from this player to other device to enhance audio output. • Connect a coaxial cable from the COAXIAL DIGITAL jack on this product to the COAXIAL jack on the device. •...
(not included) installed in the USB port. For additional information regarding the access to BD-Live™, see page 21 of the manual. • TOSHIBA does not guarantee 100% compatibility with all USB fl ash drives. CAUTION: If you want to enjoy BD-Live™ bonus content, you should connect a USB fl...
Playback Information on Playback Before you start playing back a disc, read the following information. Playable Discs and Files This unit is compatible to play back the following discs / fi les. To play back a disc / fi le, make sure that it meets the requirements for region codes and color systems as described below.
Playback Structure of Disc Contents The contents of Blu-ray Disc™ / DVD / AVCHD are generally divided into titles. Titles may be further subdivided into chapters. Blu-ray Disc / DVD / AVCHD title 1 title 2 chapter 1 chapter 2 chapter 1 chapter 2 chapter 3...
Playback Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. Playing in fast reverse / forward directions Press during playback. : Fast forward playback : Fast reverse playback Each time you press this button, the fast-forward or fast-reverse speed changes in the following sequence: Fast x 2...
Playback Accessing a Specifi c Location Directly Locating a specifi c title/chapter/time Press GOTO. The Goto menu appears on the TV screen. e.g. GOTO a. Press the GOTO button once: / 4 (Current: 1) Goto Title: : the desired title number : the total title number : the currently playing title number b.
Playback Repeating a Title, Chapter, Track or Specifi c Segment Repeating a title, chapter or track Press REPEAT repeatedly to select the desired repeat mode during playback. e.g. Repeat Off Repeat Title Repeat Chapter Repeat Off Repeat Off Repeat All Repeat Track Repeat Off Repeat Off...
Playback Camera Angle Some BD-video and DVD-video contain scenes which have been shot simultaneously from various angles. During playback, press ANGLE. The selected angle will be displayed on the display bar at the top of the TV screen. Angle 01/03 The fi...
Playback Playing AVCHD/MP3/WMA/JPEG Files You can play AVCHD, MP3, WMA or JPEG fi les that have been recorded on a disc on the Blu-ray Disc™ player. Playing fi les on a data disc When you insert a data disc containing picture, music, or video fi...
Playback Using a USB Flash Drive You can play MP3, WMA or JPEG fi les that have been stored on USB fl ash drives on the Blu-ray Disc™ player. Operating a USB Flash Drive Inserting a USB fl ash drive into the USB port on the back of Blu-ray Disc™...
Customizing the Function Settings You can change the default settings to customize performance to your preference. General Operations 1. Press to select Settings in home menu while in full stop mode, the Settings menu appears. 2. Press button, then use button to select the setting options.
Customizing the Function Settings In order to set the player up for BD-Live Internet Access, perform the following steps: 1. In the main menu of Settings, press button, then use to select BD-Live, then press OK. 2. Press to select “BD-Live Internet Access”, and then press OK.
Customizing the Function Settings Automatic: The 3D Blu-ray disc is played in 3D mode if your product detects a TV which supports it. It is played in 2D mode if your product detects a TV which can not support it. Forced 2D: The 3D Blu-ray disc is played in 2D mode at all times.
Customizing the Function Settings supports. • Stereo (LoRo) — Downmixes the multi-channel audio into two channel stereo. Choose when the Blu-ray Disc™ player is connected to the equipment that does not support virtual surround function such as Dolby Pro Logic. •...
Customizing the Function Settings System Setting 1. In the main menu of Settings, press button, then use 2. Press to select an option, and then press OK. 3. Use to select the desired setting, and then press OK to confi rm. 4.
Note: Never turn off the player during a fi rmware update process. Let the fi rmware update process fi nish. Toshiba America Information Systems, Inc. will not be responsible for damage or malfunction caused to the player by an unstable internet connection or consumer negligence...
Using the Connected Applications Some models are equipped with the capability to watch movies over the internet. Watching Movies with BLOCKBUSTER ® This Blu-ray Disc™ Player enables you to use the following services provided by Blockbuster. 1. In Home Menu, press to select Connected.
2. Creating Netfl ix account If you are not a Netfl ix Member: Select “no”. Read the instructions displayed on the TV screen, and visit http://www.netfl ix.com/toshiba from your PC. Sign up to create your account, then select “I’m now a member”.
Using the Connected Applications Listening to Music with Pandora ® Using an existing Pandora account 1. In Home Menu, press to select Connected. 2. Press , then press to highlight Pandora, and then press OK to confi rm. 3. Select “I have a Pandora account” from the option list.
Troubleshooting & Maintenance Troubleshooting If the unit does not perform properly when operated as instructed in this manual, check the unit, consulting the following checklist. Problem No power - Check if the AC cord is properly connected. - Unplug the AC cord once, and wait for 5-10 seconds and then plug it in again.
Troubleshooting & Maintenance Problem The unit cannot read Blu-ray - Dew condensation may form inside the unit. Do not use this unit for at least a Disc™ / DVD/ CD few hours until its inside gets dry. - Wipe the dirt off the disc or replace the disc. Angle does not switch - The angle cannot be switched for Blu-ray Disc™...
Glossary Analog Audio An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square);...
Glossary PCM (Pulse Code Modulation) The most common system of encoding digital audio, found on CD and DAT. Excellent quality that requires a lot of data compared to formats such as Dolby Digital and MPEG audio. For compatibility with digital audio recorders (CD, MD and DAT) and AV amplifi...
Limited Warranty Limited United States Warranty for Digital Audio Video (“DAV”) Product Toshiba America Information Systems, Inc. (“TAIS”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS DAV PRODUCT AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
Page 35
Some features may require additional bandwidth. Third party internet services are not provided by Toshiba, may change or be discontinued at any time and may be subject to third party restrictions. Toshiba makes no representations or warranties about these services, which may require the creation of a user account through a computer with internet access.
Page 36
(“Software”) provided with a Toshiba Blu- ray Disc™ Player, or made available by downloading or otherwise to you by Toshiba in whatever form or media, will constitute your acceptance of these terms, unless separate terms are provided by the software supplier or Toshiba in the documentation accompanying the Toshiba Blu-ray Disc™...
Page 37
EULA are made available for use by the user on the assumption that they are not copyrighted or warranted by TOSHIBA or any third party. These software components are licensed to the user free of charge and therefore not covered by any warranty within the scope of the applicable laws.
Page 38
Open-Source Software Included in the Blu-ray Disc™ Player: Software License (*= source must be distributed on request) A copy of the GPL2.0 license is provided in Appendix K A copy of the LGPL2.1 license is provided in Appendix L *backtrace GPL2 *directfb-extra GPL2...
Page 40
Luxi Font Copyright Luxi fonts copyright (c) 2001 by Bigelow & Holmes Inc. Luxi font instruction code copyright (c) 2001 by URW++ GmbH. All Rights Reserved. Luxi is a registered trademark of Bigelow & Holmes Inc. Permission is hereby granted, free of charge, to any person obtaining a copy of these Fonts and associated documentation fi...
Page 41
in part on the work of the Independent JPEG Group”. (3) Permission for use of this software is granted only if the user accepts full responsibility for any undesirable consequences; the authors accept NO LIABILITY for damages of any kind. These conditions apply to any software derived from or based on the IJG code, not just to the unmodifi...
Page 42
Except as contained in this notice, the name of Daniel Veillard shall not be used in advertising or otherwise to promote the sale, use or other dealings in this Software without prior written authorization from him. Appendix F – zlib Distribution Conditions This software is provided ‘as-is’, without any express or implied warranty.
Page 43
`You’ refers to the licensee, or person using the project, where `using’ is a generic term including compiling the project’s source code as well as linking it to form a `program’ or `executable’. This program is referred to as `a program using the FreeType engine’.
Page 44
OpenSSL License ------------------------ /* ==================================================================== Copyright (c) 1998-2008 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modifi cation, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
Page 45
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Page 46
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs;...
Page 47
3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...
Page 48
of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally. NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW.
Page 49
When a program is linked with a library, whether statically or using a shared library, the combination of the two is legally speaking a combined work, a derivative of the original library. The ordinary General Public License therefore permits such linking only if the entire combination fi ts its criteria of freedom. The Lesser General Public License permits more lax criteria for linking other code with the library.
Page 50
These requirements apply to the modifi ed work as a whole. If identifi able sections of that work are not derived from the Library, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works.
Page 51
in Subsection 6a, above, for a charge no more than the cost of performing this distribution. d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specifi ed materials from the same place. e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy.
Page 52
write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.
Page 53
Appendix N – CinemaNow Third Party Requirements a. gSOAP. The following notice is applicable to the CinemaNow SDK. Company is required to include such notice in the documentation for any Embedded Products it distributes. Part of the software embedded in this product is gSOAP software. Portions created by gSOAP are Copyright (C) 2001-2004 Robert A.
Page 54
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS’’ AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
