Summary of Contents for Hubbell Progress Lighting P250017
- Page 1 Ceiling Fan Installation Manual P250017 93099665_B...
- Page 2 Limited Lifetime Warranty Progress Lighting fan motors are warranted to the original purchaser to be free of electrical and/or mechanical defects for so Date Purchas ed long as the original purchaser owns the fan. Pull chain switches, reverse switches, capacitors and metal finishes are warranted to be free from defects in materials or workmanship for a period of 1 year from the date of purchase.
-
Page 3: Table Of Contents
Safety Rules..................................... Unpacking Your Fan ..................................Installing Your Fan ..................................Installing the Metal Light Cover..............................Operating Your Transmitter ................................Care of Your Fan ................................... Troubleshooting .................................... Specifications ....................................Table of Contents... -
Page 4: Safety Rules
1. To reduce the risk of electric shock, insure electricity has been turned off 9. To avoid personal injury or damage to the fan and other items, be at the circuit breaker or fuse box before beginning. cautious when working around or cleaning the fan. 2. -
Page 5: Unpacking Your Fan 2
Unpack your fan and check the contents. You should have the following items: 13. Loose parts bag containing: 1. Fan blades (6) 8. Metal light cover a. Blade attachment hardware (19 screws, 19 fiber washers) Wall transmitter incl. 2 mounting screws and 2. -
Page 6: Installing Your Fan
Tools Required Angled ceiling Phillips screw driver, straight slot screw driver, maximum adjustable wrench, step ladder, and wire cutters. Provide strong support 20 angle Mounting Options If there isn't an existing UL listed mounting box, Ceiling Recessed hanger then read the following instructions. Disconnect outlet box bracket the power by removing fuses or turning off... - Page 7 Step 7. Align the holes at the bottom of the downrod Hanging the Fan with the holes in the collar on top of the motor Ceiling housing (Fig. 7). Carefully insert the hanger pin UL Listed REMEMBER to turn off the power. Follow hanger through the holes in the collar and downrod.
- Page 8 Make the Electric Connections WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. If you feel you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. 1.
- Page 9 Ground conductor Black White Black White Outlet White Black Wall Black Black comtrol Yellow/green ground Wall outlet box Figure 8...
- Page 10 Installing the wall switch Wall outlet box Wall control WARNING: Hook up in "series only". Do not connect the hot and neutral wires of Wall plate the electric circuit to the wall switch - damage to the switch and possible fire could occur.
- Page 11 Step 2. Tighten each screw securely starting with Finishing the Installation the center screw. Make sure the blade is straight. Outlet box Step 1. Tuck connections neatly into ceiling outlet Step 3. Fasten the blade assembly to the motor box. using the motor screws provided.
- Page 12 Blade Balancing WARNING TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE All blades are grouped by weight. Because aluminum Touching HOLDERS WHILE INSTALLING, ceiling very in density, the fan may wobble even though the BALANCING THE BLADES, OR CLEANING THE FAN.
- Page 13 Installing the Mounting Plate Step 1. Remove 1 of the 3 screws from the mounting ring and loosen the other 2 screws. (Do not remove) Step 2. Place the key holes on the mounting plate over the 2 screws previously loosened from the mounting ring, turn mounting plate until it locks in place at the narrow section of the key holes.
-
Page 14: Installing The Metal Light Cover
Before starting installation, CAUTION: disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Position the tabs in the inside of the rim on the metal light cover so they line up with the notches on the inside of the rim on the mounting plate. -
Page 15: Operating Your Transmitter 12
a) Select desired frequency from the transmitter. The Wall Control Button Definitions: (Fig. 16) Installing the battery These six buttons are used to set the fan speed as dip switches can be set to 16 different combinations. follows: (Fig. 17) Install a 12V MN21/A23 battery (included) into the 1 = minimum speed wall control. - Page 16 This receiver provides the following protective function: 1. Lock Rotor Position: The DC motor has a built-in safety against a stalled or locked rotor condition (stalled blade rotation). If there is an obstruction or fault with the motor, the current monitoring function will automatically turn power off to the motor after 30 seconds.
-
Page 17: Care Of Your Fan
Here are some suggestions to help you maintain your 3. You can apply a light coat of furniture polish to the wood blades for additional protection and enhanced beauty. Cover small scratches with a light application 1. Because of the fan's natural movement, some of shoe polish. -
Page 18: Troubleshooting
Problem Solution 1. Check circuit fuses or breakers. Fan will not start. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency. Fan sounds noisy. -
Page 19: Specifications
Volts Fan Size Speed Amps Watts N.W. G.W. C.F. 0.048 1.92 2360.93 3.58' 72" 0.37 26.97 8402.48 High These are approximate measures. They do not include Amps and Wattage used by the light kit. 2019 Progress Lighting, Inc. 701 Millennium Blvd., Greenville, SC 29607 All Rights Reserved Specifications...
