- Page 2 Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Abetechs GmbH (Grundig Security) reserves the right to change the contents of this document without prior notice. Design and specifications are subject to change without prior notice.
- Page 3 use of this product, even if our company has been advised of the possibility of such damages. Regarding to products with internet access, the use of the product shall be wholly at your own risks. Our company shall not take any responsibilities for abnormal operation, privacy leakage or other damages resulting from cyber-attack, hacker attack, virus inspection, or other internet security risks;...
- Page 4 The appearance of the products, functions and firmware or software upgrade may differ from this manual. GRUNDIG reserves the right to perform needed changes without prior notice. Safety Instructions Make sure that you only use the power adapter that is specified in the specifications sheet of the product.
- Page 5 Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way. If the product starts to smell or smoke comes out of the device, immediately stop using the product and disconnect it from the power supply to prevent fire or electric shocks.
- Page 6 If the product is classified by any IP class, never touch the product cover directly with your fingers, because the acidic sweat of the fingers may damage the surface coating of the product cover. To clean the inside and outside of the product cover, use a soft and dry cloth. In any case, do not use alkaline detergents.
-
Page 7: Table Of Contents
Table of Contents 1 Function ..................7 2 Appearance and Display Introduction ..........8 3 Technical Data ................. 9 4 General..................10 4.1 Mounting ..............10 4.2 Operation ..............10 4.3 Maintenance ..............11... -
Page 8: Function
1 Function The product is specially designed for calibrating body temperature detection thermal device and thermal inspection device in various sizes. Excellent temperature uniformity, accuracy, and stability of calibration. Adopts intelligent temperature controller and has high temperature control accuracy. -
Page 9: Appearance And Display Introduction
2 Appearance and Display Introduction Device Appearance Measuring Control Temperature Panel （PV） Setting Temperature (SV) Temperature Controller... -
Page 10: Technical Data
3 Technical Data Parameter Value Temperature Range Adjustable: environment temperature +5 °C (9 °F), up to 50°C (122 °F) Effective Radiating Area Ф 70 mm (2.76”) Temperature 0.1 °C (0.18 °F) Resolution Temperature Accuracy ± 0.1 °C (0.18 °F) Temperature Stability ±... -
Page 11: General
4 General 4.1 Mounting Check the power supply. The working voltage should be 100 VAC-240 VAC, 35 W. Check if the desk is horizontal. Mount the device on the desk or a tripod in front of the thermal camera firmly. The distance to the camera is depending on the camera model. -
Page 12: Maintenance
4.3 Maintenance The black body should be managed and maintained by professional person and maintenance and usage should be recorded. DO NOT use the device in an environment with oil or chemical air. To ensure the temperature accuracy, place the device firmly in the environment with stable temperature. - Page 13 UG-GD-HW-BPBB0550G-2020-04-09-V4-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY grundig-security.com...
