Single Pedestal Desk
Assembly Instructions
021 xx 7667
- Please keep for future reference
Dimensions
Width - 90.0cm
Depth - 44.0cm
Height - 70.0cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 30.05.17
Advertisement
Related Manuals for Home Essentials Norton XK089MH
Summary of Contents for Home Essentials Norton XK089MH
- Page 1 Single Pedestal Desk Assembly Instructions 021 xx 7667 - Please keep for future reference Dimensions Width - 90.0cm Depth - 44.0cm Height - 70.0cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 622xx7002 Left drawer side (30x10cm) 0856 Top Panel (90.0x44.0cm) 623xx7002 Right drawer side (30x10cm) 624xx7003 Drawer back 0860 (27.6x10cm) Door (43.8x30.5cm) 0858 0857 Right End Panel...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 0856 9677 0857 9676 0860 0859 9669 9675 0858 8546 624xx7003 622xx7002 4883 623xx7002 9387 Drawer... - Page 6 Assembly Instructions Step 1 Fitting dowels to top panel. Insert 6 metal dowels into the top panel 0856 Note: Tighten metal dowels up fully against the panel. Do not over tighten. 0856 Step 2 Fitting cams to the plinth, back rail and bottom panels.
- Page 7 Assembly Instructions Step 3 Fitting cams , dowels and shelf studs to the lh end & divider panels. Insert 2 metal cams 4 metal dowels 2 shelf studs into left 0857 end panel Insert 2 metal cams 0857 4 metal dowels annd 2 shelf studs into left...
- Page 8 Assembly Instructions Step 5 Fitting hingeplates to left end. Insert 2 hinge plates into the left end panel 0857 0857 Step 6 Now, turn the divider panel over. Fittings in reverse side. We suggest using the cardboard packaging to place under this panel to prevent 0859 damage to your floor.
- Page 9 Assembly Instructions Step 7 Step 8 Correct Attach hinges to the door Insert hinges Incorrect into holes, ensure the hinge is straight (90 degree angle). 0860 Before securing the hinges , we recommend Bradawl you pre - mark the doors using a bradawl.
- Page 10 Assembly Instructions Step 9 Fitting dowels to the drawer front. Insert 2 metal dowels into the the drawer 9387 fronts 9387 Repeat on the remaining drawer fronts. Step 10 Assemble the drawer Right hand side Insert small cams 622xx7002 into left 623xx7002 and right 623xx7002...
- Page 11 Assembly Instructions Step 10 Continued Sit drawer bottom 4883 into groove on Foil surface facing upwards. drawer front 9387 Plain chipboard surface to underside. 4883 Ensure foil on the drawer bottom is facing upwards. 9387 : Locate the metal dowels (already inserted) in the drawer front into the small cams in the left and right hand drawer sides.
- Page 12 Assembly Instructions Step 11 Connect the plinth and 9675 bottom panels to the lh end panel. 0857 Connect the cams in the 8546 plinth panel bottom panel 9675 the metal dowels in the 0857 lh end panel Ensure that finished edges are facing the floor.
- Page 13 Assembly Instructions Step 14 Connect the rh end to the back rail Connect the cams in the 9669 back rail panel the metal dowels in the 9669 0858 rh end panel Turn the cam 180 degrees to lock. 0858 Step 15 Connect the top panel the end and divider panels.
- Page 14 Assembly Instructions Step 14 Step 16 Squaring up the unit. DIAG 2 DIAG 1 DIAG 3 IMPORTANT! Ensure a tape measure is used to square unit up. Before securing the back it is necessary to square up the unit. You can do this by measuring between XX - XX and YY - YY ensuring these are the...
- Page 15 Assembly Instructions Step 18 Fit the drawer. For this step we recommend you follow the helpful hints below. Locating shelf onto shelf supports. 2nd Hole Sit the shelf on top of the shelf supports Step 19 Fit the drawer helpful hints. PULL SLIDING PART OF DRAWER RUNNERS LOCATE DRAWER ONTO RUNNERS OUT SO THEY ARE FULLY EXTENDED.
- Page 16 Assembly Instructions Step 20 Hanging door With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. See Diagrams 1, 2 and 3. Tighten screw shown to lock hinges in position. See ‘Hinge adjustment’ page if the doors need adjusting.
- Page 17 Assembly Instructions Step 21 Step 21 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. Step 22 To move doors left or right: loosen or...
- Page 18 Assembly Instructions Step 22 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
- Page 19 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
- Page 20 Notes;...
