Summary of Contents for Home Essentials RIGA SG797
- Page 1 DESCRIPTION: Assembly SG797 RIGA Instruction 5 + 5 WIDE CHEST FLOOR AREA 2.0 M x 2.0 M 2.0 hr 2 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE APPROXIMATE ASSEMBLY TIME Ø8 REQUIRED ASSEMBLY TOOLS FOR WALL STRAP ATTACHMENT ONLY ASSEMBLED DIMENSIONS 400 mm 1/18 RIGA 49...
-
Page 2: Parts List
DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST NO PART LIST PARTS LIST (1) LOWER TOP PANEL (2) PLINTH (3) LEFT SIDE PANEL (4) RIGHT SIDE PANEL (5) VERTICAL DIVIDER (6) UPPER TOP PANEL (7) BACK PANEL 340x832mm (8L) LEFT BACK PANEL 304x832mm (8R) MIDDLE BACK PANEL 304x832mm... -
Page 3: Hardware List
DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES ATTACH TO DRAWER ATTACH TO CARCASS 10x Left / 10x Right 8x28mm L=350mm CAM BOLT GLUE DOWEL CAM LOCK BAG 1 ROLLER RUNNER BAG 1 BAG 1 BAG 1... - Page 4 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES M4x22mm 3,0x13mm 3,0x20mm L=128mm SCREW HANDLE SCREW SCREW METAL PLATE PLASTIC SUPPORT BAG 2 BAG 1 BAG 1 BAG 3 BAG 3 BAG 1 L=338mm DRAWER BOTTOM SUPPORT...
- Page 5 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST Top Tips before you start! Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
- Page 6 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES. TO SECURE PANELS, PRESS PANELS TOGETHER ALIGNING TURN CAM LOCKS 1/2 TURN CLOCKWISE.
- Page 7 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST ASSEMBLY INSTRUCTION FOR DRAWER SLIDE A&B 350mm SPECIAL TIPS FOR DRAWER SLIDE A FRONT BACK SECOND HOLE SECOND HOLE LAST SECOND HOLE 3,5x13mm ATTENTION ! Make sure second hole of drawer slide A is put on first front hole of panel.
- Page 8 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 8/18 RIGA 49...
- Page 9 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 5x Left / 5x Right LEFT RIGHT 9/18 RIGA 49...
- Page 10 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 5x Left / 5x Right LEFT RIGHT 10/18 RIGA 49...
- Page 11 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 1/2 TURN CLOCKWISE. 11/18 RIGA 49...
- Page 12 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 1/2 TURN CLOCKWISE. 8x 8x 12/18 RIGA 49...
- Page 13 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST DO THIS STEP FIVE TIMES (5x) 1/2 TURN CLOCKWISE. 13/18 RIGA 49...
-
Page 14: Assembly Instruction
DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST DO THIS STEP FIVE TIMES (5x) L=128mm 5x Left / 5x Right 14/18 RIGA 49... - Page 15 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST DO THIS STEP FIVE TIMES (5x) 1/2 TURN CLOCKWISE. 15/18 RIGA 49...
- Page 16 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST DO THIS STEP FIVE TIMES (5x) L=128mm 5x L / 5x R 3,0x13mm 16/18 RIGA 49...
- Page 17 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST STEP STEP Wall fixings are not supplied with this product as different wall materials require different types of fixing devices( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to.
- Page 18 DESCRIPTION: Assembly RIGA Instruction 5 + 5 WIDE CHEST 18/18 RIGA 49...
