COPPER TUBE TOOL
STAINLESS FLEXIBLE TUBE TOOL
OPERATION MANUAL
ORIGINAL INSTRUCTIONS
RF20S
- Be sure to hand this operation manual to the user.
- To ensure safe and efficient use, read the manual thoroughly
before using the product.
- Be sure to keep the manual where the operator can refer to
it whenever necessary.
Date of purchase:
Distributor:
Be sure to read this
Operation Manual before
using the product.
- Note -
Year
RT20S
Month
Advertisement
Table of Contents
Troubleshooting
Related Manuals for REX RF20S
Summary of Contents for REX RF20S
- Page 1 COPPER TUBE TOOL STAINLESS FLEXIBLE TUBE TOOL OPERATION MANUAL ORIGINAL INSTRUCTIONS RT20S RF20S Be sure to read this Operation Manual before using the product. - Note - - Be sure to hand this operation manual to the user. - To ensure safe and efficient use, read the manual thoroughly before using the product.
-
Page 2: Table Of Contents
Safety Considerations on pages 2 - 4 and Precautions on pages 5 - 7. To avoid accident and injury, never use for any purposes other than those described in this manual. Should you need further advice, contact your distributor or REX Industries Co., Ltd. CONTENTS General Safety Warnings for Power Tools............. 1... -
Page 3: General Safety Warnings For Power Tools
General Safety Warnings for Power Tools WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference! The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. -
Page 4: Safety Considerations
General Safety Warnings for Power Tools WARNING - Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to jam and are easier to control. - Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. - Page 5 Safety Considerations WARNING 6. In the following cases, turn the product OFF and pull the plug out of the power supply socket. - When the product is not in use or parts are changed, repaired, cleaned or inspected. - When accessories are changed. - When hazards are expected (including electric power failure).
- Page 6 If oil or grease remains on the product, it may slip and cause injury. - Periodically inspect the power supply cord and plug. If damaged, ask the store where you bought them or a REX distributor for repairs. If you leave them as is, you may get an electric shock, or a short circuit may cause a fire.
-
Page 7: Precautions For Using Rf20S/Rt20S
Precautions for using the charger/battery WARNING 1. The charger is for exclusive use with REX original products only! - When charging the battery, use the exclusive battery charger only and none other. Never use the charger for any other rechargeable tool or battery. - Page 8 - If either the charger or battery unit does not function properly, do not disassemble to attempt a repair yourself. Always return to the store where you bought them or to a REX distributor for repair. 15. Do not short circuit the battery! - The battery has a very low internal resistance.
- Page 9 Precautions for using the charger/battery WARNING 18. If any abnormality arises, stop charging at once! - If you notice any abnormality such as overheating or an unusual smell, stop charging immediately and send the unit for repair. 19. Take care when storing the charger! - Always store where the ambient temperature is under 40ºC, and out of the reach of children.
-
Page 10: Main Parts, Specifications For Rf20S
Main Parts, Specifications for RF20S Main Parts Flaring cone Ventilation hole Flaring tool Power cord Green lamp Charger FWD/REV Battery lamp switch mounting socket Trigger Strap Lithium-ion Hex key Carrying case battery Clamp with liner Hex socket button head screw... -
Page 11: Main Parts, Specifications For Rt20S
Main Parts, Specifications for RT20S Main Parts Flanging cone Ventilation hole Flanging tool Power cord Green lamp Charger FWD/REV Battery lamp switch mounting socket Trigger Strap Lithium-ion battery Hex key Carrying case Clamp (with liner) Hex socket button head screw (M4 x 8) Latch Clamp liner... -
Page 12: Standard Accessories, Use
Hex key (Diameter: 2.5 mm) 210 × 145 × 2 Operation Manual Table 6 - RF20S: Flaring copper tube. Flanging flexible stainless steel tube. (requires flanging tool set 424980 sold separately; refer to Page 23, Fig. 43). - RT20S: Flanging flexible stainless steel tube. -
Page 13: Operation Guide
Operation Guide (For RF20S/RT20S) Getting Ready: Main unit Charging the battery 1. Remove the battery from the main unit by pressing the latch on the battery. (Fig. 3) CAUTION Latch - Hold the main unit firmly and remove the battery. -
Page 14: Cutting And Scraping The Tube
Operation Guide (For RF20S/RT20S) CAUTION Main unit - Ensure the battery is attached the correct way round. - Charge in a place where the temperature is within the chargeable range of 10°C to 40°C. Latch If you charge outside this range, it may degrade the performance and life of the battery and may even cause a leakage or generate excessive heat. -
Page 15: Clamping The Tube
Operation Guide (Flaring copper tube) CAUTION - If you feed the blade too quickly, the tube may be Proper cut end. Deformed cut ends. deformed and the tube cannot be flared properly. The cut end inner The cut end inner diameter is the (Fig. - Page 16 Operation Guide (Flaring copper tube) 3. Check that the tube is placed correctly and then Set the tube in the clamp so that the stopper plate clamp it. (Figs. 13-14) does not move that easily. CAUTION Stopper plate - To confirm that the stopper plate is in perfect contact with the tube, try to raise the stopper plate slightly with your finger.
-
Page 17: Flaring
Operation Guide (Flaring copper tube) (3) Flaring 1. Attach the clamp, with the tube in it, to the flaring Recesses Recesses Notch tool. (Figs. 19-20) (Protrusion) *Attach the clamp to the flaring tool by aligning the joints on the clamp with the recesses in the flaring tool, and then turn the flaring tool in the direction of the arrow until you hear a click. -
Page 18: Removing The Tube
Operation Guide (Flaring copper tube) 3. Press and hold down REV on the FWD/REV switch. - The flare cone will be retracted while rotating in reverse. The amount you pull the trigger affects the rotation speed, but you should pull the trigger back all the way. -
Page 19: Cutting Flexible Tube
Operation Guide (Flanging) Operation Guide (Flanging) (1) Cutting flexible tubes (Figs. 25, 26) Set the cutter wheel Cutter 1. Rotate the grip anticlockwise and retract the cutter blade to in the centre of the wheel recess of the tube. fit the flexible tube to be cut. Flexible tube Roller 2. -
Page 20: Flanging
Operation Guide (Flanging) (3) Flanging (Figs. 29-31) Attach the clamp 1. Attach the clamp, with the tube in it, to the flanging Tube tool. (Figs. 29-31) *Attach the clamp to the flanging tool by aligning the joints on the clamp with the recesses in the flanging tool, and then turn the flanging tool in the direction of the arrow until you hear a click. -
Page 21: Replacing The Flaring Or Flanging Cone
Operation Guide (Replacing the flaring or flanging cone) The RF20S flaring tool can be used to flange flexible tube by attaching special (optional) accessories. The RT20S flanging tool can also be used to flare copper tube by attaching special (optional) accessories. -
Page 22: Maintenance And Care
This product is produced with great precision; therefore, should it fail to operate normally, do not disassemble or repair it by yourself; contact your distributor or REX INDUSTRIES CO., LTD. If you do not find any problem or remedy in Troubleshooting in this manual, or parts are required or if you have any questions, please contact us at your earliest convenience. -
Page 23: Before Asking For Repairs Or Servicing
Before Asking for Repairs or Servicing If an abnormality occurs with the product, check the following and then contact your distributor or REX INDUSTRIES CO., LTD. CAUTION - If there is no description of, or instructions regarding, the problem in question in the following table, never try to disassemble or repair the product by yourself. -
Page 24: Troubleshooting (Rt20S)
The internal mechanism of the Ask for inspection or repairs. flanging tool is damaged. (Refer to page 20.) Table 10 Troubleshooting (RF20S / RT20S) Problem Cause Remedy The flaring/flanging tool does not The battery has run out. -
Page 25: Optional Accessories For Rf20S
6) Flanging tool set (Fig. 43) 6) Flanging tool set Part No. 424980 *By using the tool sets, the RF20S can be used as a flanging tool. These sets are used for flanging stainless flexible tubes for water supply, respectively. -
Page 26: Optional Accessories For Rt20S
Optional Accessories for RT20S *Optional accessories are also sold separately as below. 1) Clamp 1) Clamp for flanging (Fig. 45) Part No. 424975 Used when flanging stainless flexible tube. Liners and cones for flanging stainless flexible tube are required. Fig. 45 *When flaring copper tube with the RT20S, separate 2) Liners clamps, liners and cones for flaring copper tube are... - Page 27 MEMO...
- Page 28 Observe national regulations on environmentally compatible disposal and on the recycling of disused machines, packaging and accessories. Battery packs must not be disposed of with regular waste. Return faulty or used battery packs to your Rex distributor! Do not allow battery packs to come into contact with water!
