- Page 1 EYE System for warping creels Users Guide Document ID: TH-0362-00 Document TH-0362 EYE system for creels Users guide.docx Date: 2020-12-08...
-
Page 2: Table Of Contents
Before starting the machine ..............................23 How to make the 65300 modular cable ..........................23 Notes about the installation ..............................24 This manual ..................................26 Service stations for Eltex EYE systems ..........................26 2 / 26 TH-0362 EYE system for creels Users guide... -
Page 3: System Description And Technical Data
* Under specific circumstances up to 16. Check with Eltex service station. Introduction Eltex EYE-System Eltex EYE system detects the movement of the yarns. At the installation and whenever the quantity of yarns or their positions are changed, a learn command is made. All yarn positions where the yarns are moving will then be active. -
Page 4: Eye System Overview
EYE system overview Optional EYE Analyzer Yarn sensors EYE sensors Modular cables Optional External information screen Operator terminal 24VDC Power supply 4 / 26 TH-0362 EYE system for creels Users guide... -
Page 5: Navigating In The Operator Terminal
Navigating in the operator terminal This manual refers to “pages” in the operator terminal. Page numbers can be found in the upper left corner on each “page”. Explanation of Ramp up Before the machine has reached the normal operating speed, it is possible to start the monitoring of the yarns using special Ramp up parameters. -
Page 6: Sensor Parameters
Sensor parameters: How to check/set the parameters of the sensors: Sensitivity and reaction time must be set correctly. (If different groups have been set up the parameters can be set differently for each group). Sensitivity (Gain) determines how easy the sensor can detect the yarn movement. There are two different reaction times, “False Yarn Filter”... -
Page 7: Service / Fault Finding
Service / Fault finding General for the EYE system Indicator LEDs on the EYE sensors: Common LED Channel LED Description Machine status on sensor on sensor Machine is not Power on, yarn detection Green on operating off, no stop detected. Green flashing Machine is operating Yarn detection on. -
Page 8: The Eye System Stops And Show "False Yarn Position
The EYE system stops and show “False yarn position” · Cleaning the Sensors or the machine with compressed air or using air splicers nearby when the machine is operating can cause this fault indication. · On the Operator Terminal and on the sensors, it is indicated which eyelet position is causing the false yarn movement. -
Page 9: How To Run "Sensor Addr Setup" Command
How to run “Sensor addr setup” command Make sure all sensors are connected to the master control unit. From the main menu, press “Service”. Press “Set sensor addresses”. You will then be asked to enter a The sensors will now be automatically password. -
Page 10: How To Replace A Sensor
Switch the power on. · The software is updated continuously. In most cases the EYE-system will work as before with a newer software in the Operator Terminal. In case of problems contact Eltex. 10 / 26 TH-0362 EYE system for creels Users guide... -
Page 11: Procedure To Do A Standard Installation
Procedure to do a standard installation: Connection example of MCU The system configuration described later in this manual refers to a connection made as this example. The inputs and outputs can however be used in any of the available functions. The system configuration in the Operator Terminal must then in that case be made accordingly. - Page 12 The Master Control Unit (MCU) has 8 inputs and 6 outputs and these are in this example used as follows: Input no Function Output Function 12 / 26 TH-0362 EYE system for creels Users guide...
-
Page 13: Hardware Installation
Hardware installation: 1. Mount the Enclosure 10320 containing the Master Control Unit (MCU) 11710 and Operator Terminal 11797, on a suitable position. 2. Mount the EYE sensors. Be sure that the yarns are touching the ceramic eyelet and are making a small deviation when passing the sensor. -
Page 14: System Configuration In Operator Terminal
System configuration in Operator Terminal: Phrases: Channels = Yarn positions. B Pos = Sensor position in the LIN bus. B Pos 1 is the first sensor. On the following installation procedure there are on each page a “Help” button which will show additional information. - Page 15 In the main menu select “Installation”. User: Service. Password: s, Select “Installation” again. Basic settings Inputs and outputs Press “Wizard start” Which will start the One Operator Terminal can be used for installation. Then after every page press “Next”. several MCU. Not in this case.
- Page 16 How to configurate Inputs and Outputs General preferences for the installation. Configuration of the standard inputs. If DI1 is With this setting a password will be required to used for “Run mode” Enter like this. change sensor parameters. DI7/PI1 can be used for external learn button. You can start with the value on Run mode 5000 = 5 sec.
- Page 17 It is possible to have special “Ramp up” The Learn process is here configured to start by parameter settings during start before the selecting “Learn” on the Operator Terminal (or machine has reached full speed pressing the Learn button if this has been You can start with the value 10 000 = 10 sec.
- Page 18 Setting up Alias It is possible to give a name (Alias) for each yarn/position. This will be displayed on the Operator terminal at any kind of yarn fault. If you wish, you can leave the alias part for now and continue on “Setting up groups” to have the system started up sooner.
- Page 19 Example: . With this setting the yarn positions in With this setting the yarn positions in the left 5th the upper left level will be numbered from level will be numbered from L5-01 to L5-16. L6-01 to L6-16. Do not forget: press “Apply alias” before Please remember: When the Alias has been entering the next section entered, then press “enter”...
- Page 20 Setting up Groups It is possible to divide the yarn positions in With this setting and by pressing “Apply group” all different groups. For example if the yarns has sensors will be connected to group 1. different yarn counts, different parameters can be If 2 groups are selected, the “Range”...
- Page 21 The Left/Right function is normally used when an If one indication lamp is used for all positions on EYE system is installed on creel. If the sensors on the machine, enter “0” on this page. the left side of the creel is connected to LIN bus (The output function for the lamp should be connections1-3 and the sensors on the right side “Alarm”...
- Page 22 Operator Terminal settings Set language, English or Chinese. Select date format. Set default page (in this application 150) and time Set time zone offset. of inactivity (300 sec) before the default page will appear. Page no 160 can also be used. Select rule for Daylight Saving Time.
-
Page 23: Save A Backup Of The Settings
Such a Memory-Card is included with the Manual for the EYE system. It can also be ordered from Eltex, Part No #6738. Insert the SD-Card in the MMC-slot in the Master Control Unit. From main menu: Select “Service” (Log in is necessary). -
Page 24: Notes About The Installation
Notes about the installation 24 / 26 TH-0362 EYE system for creels Users guide... - Page 25 25 / 26 TH-0362 EYE system for creels Users guide...
-
Page 26: This Manual
Email: polsa@infonegocio.com Eltex of Sweden AB • Södra Portgatan 19 • SE-283 50 OSBY • Sweden • Tel. +46 479 53 63 00 Eltex of Sweden AB • Södra Portgatan 19 • SE-283 50 OSBY • Sweden • Tel. +46 479 53 63 00...
