Package contents ... 8 System requirements ... 8 Quick Tour ... 9 Setting up the TOSHIBA Mobile LCD Monitor ... 10 Using the convertible protective case ... 10 Store the USB Y cable ... 11 Installing the driver ... 11 Connecting the LCD monitor to your computer ...
Safety icons This guide contains safety instructions that must be observed to avoid potential hazards that could result in personal injuries, damage to your equipment, or loss of data. These safety cautions have been classified according to the seriousness of the risk, and icons highlight these instructions as follows: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Safety Instructions Always read the safety instructions carefully: Do not disassemble, modify, tamper with or repair the product ❖ Do not attempt to disassemble, modify, tamper with or repair the product. Disassembly, modification, tampering or repairing the product could cause fire or electric shock, possibly resulting in serious injury.
Page 5
Never place the product in locations with excess heat ❖ Never place the product where it will be exposed to excess heat, such as in direct sunlight, in an unventilated vehicle, or near a heater. This may result in a system failure, malfunction, loss of data or damage to the product.
Consult the dealer or an experienced radio/TV technician for help. Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment. TOSHIBA declares that this product conforms to the following Standards:...
Alliance at www.eiae.org. Copyright This guide is copyrighted by Toshiba Corporation with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.
❖ CD (User’s Manual [this document], driver, and warranty information) ❖ Quick Start Card If any items are missing or damaged, contact Toshiba support. For contact information, please see “If you need further assistance” on page 17. This product is covered by a One (1) Year Standard Limited Warranty.
Quick Tour This section identifies the various components of the TOSHIBA Mobile LCD Monitor. For a description of each component, please refer to the illustration and table below: Brightness (down) Power button Mini USB port Component Mini USB port Power button...
Component Brightness control (up) DC-IN 19V jack Setting up the TOSHIBA Mobile LCD Monitor Using the convertible protective case A convertible protective case is attached to the LCD monitor to help protect it during transport or storage. A convenient cable management system stores the USB Y cable when not in use.
Store the USB Y cable To pack and store the provided USB Y cable: Unplug the USB cable from the computer and monitor and place the cable across the spine of the convertible protective case. (Sample Illustration) Storing the USB Y cable Roll up the flap until the hook-and-loop fasteners catch and secure the cable within the fabric enclosure.
Connecting the LCD monitor to your computer Connect the small end of the provided USB Y cable to the Mini USB port on the left side of the monitor. (Sample Illustration) Connecting the LCD monitor Connect the other end of the USB Y cable to one of your computer’s USB ports.
Page 13
USB hub. 2. Operate the LCD monitor in a horizontal position and on a hard, flat surface only. After connecting the LCD monitor to your computer, the Toshiba Mobile LCD Monitor icon ( Windows...
For Microsoft Press the Windows modes as shown below. ® For Microsoft Right-click the “TOSHIBA Mobile LCD Monitor” icon in the system tray of your Windows settings. Adjusting the brightness Press the Brightness Up/Down buttons to adjust the brightness level of the monitor display. Brightness levels may also vary depending on the power source used.
BIOS, hardware driver or operating system updates. ❖ The for your TOSHIBA computer only controls the internal video controller of your computer. ❖ The TOSHIBA Mobile LCD Monitor utilizes an advanced video graphics controller to display the video.
❖ This product is unable to enter full screen DOS mode when using the Mobile LCD monitor. ❖ To play DVDs, use the Media Player included with your operating system. Do not use the TOSHIBA DVD Player to play DVDs on the Mobile LCD Monitor. Troubleshooting This section provides tips for correcting problems, should any occur.
If you need further assistance If you have followed the recommendations in this section and are still having problems, you may need additional technical assistance. Toshiba Support Web sites United States pcsupport.toshiba.com Toshiba Customer Support Centers United States Calling from within the United States: (888) 592-0944...
Specifications This section summarizes the TOSHIBA Mobile LCD Monitor technical specifications*. LCD monitor Monitor Type 14.0” LCD Contrast Ratio 400:1 (Typ.) Power input AC adaptor (AC adaptor sold separately.) 100-240V AC Voltage Frequency 50-60 Hz This voltage requirement only applies to the optional AC adaptor.
Physical specifications Dimensions (W x H x D) Approximately 340.5 x 239.5 x 15.5mm (13.4 x 9.4 x 0.6 in) Net Weight Approximately 795g (1.75 lbs) Environmental considerations Operating Temperature 5° to 35° C (41° to 95° F) Storage Temperature -20°...
Page 20
3 instructions 4 setting up monitor 10 specifications environmental considerations 19 monitor 18 operational features 18 physical specifications 19 power input 18 power input, AC adaptor 18 Toshiba Customer Support Centers 17 Toshiba Support Web sites 17 troubleshooting 16...
Page 21
Monitor Móvil LCD de TOSHIBA Manual del usuario...
Page 22
Contenido de la caja... 8 Requisitos del sistema... 8 Referencia rápida ... 9 Instalación del Monitor Móvil LCD de TOSHIBA ... 10 Uso de la cubierta de protección convertible... 10 Almacenamiento del cable USB Y ... 11 Instalación del controlador... 11 Conexión del monitor LCD a la computadora ...
Íconos de seguridad Esta guía contiene instrucciones de seguridad que deben seguirse a fin de evitar posibles peligros que pueden tener como consecuencia lesiones personales, daños al equipo o pérdida de datos. Son advertencias de seguridad que están clasificadas de acuerdo con la gravedad del peligro y están representadas por íconos que distinguen cada instrucción como se muestra abajo: P E L I G R O Este ícono indica la presencia de una situación inminentemente...
Instrucciones de seguridad Siempre lea cuidadosamente las instrucciones de seguridad: No desarme, modifique, altere o repare el producto A D V E R T E N C I A ❖ No intente desarmar, modificar, alterar o reparar el producto. Desarmar, modificar, alterar o reparar el producto podría provocar un incendio o un choque eléctrico, que podría ocasionar lesiones graves.
Page 25
Nunca coloque el producto en sitios en los que haya calor excesivo ❖ Nunca coloque el producto en lugares en los que podría quedar expuesto a calor excesivo, como por ejemplo, a la luz directa del sol, en un vehículo sin ventilación o cerca de un calefactor. Esto podría provocar fallas en el sistema, mal funcionamiento, pérdida de datos o daños al producto.
Los cambios o las modificaciones realizados a este equipo, que no estén aprobados expresamente por TOSHIBA o por terceros autorizados por TOSHIBA, pueden invalidar el derecho del usuario a utilizar el equipo. TOSHIBA declara que este producto cumple con las siguientes normas: Declaración de conformidad CE...
Page 27
Derechos de autor Los derechos de autor de este manual son propiedad de Toshiba Corporation, quien se reserva todos los derechos. De acuerdo con las leyes de derechos de autor, este manual no puede reproducirse en forma alguna sin el permiso previo y por escrito de Toshiba.
❖ Guía de inicio rápido En caso de que falte o esté dañado algún artículo póngase en contacto con la asistencia al cliente de Toshiba. Para la información de contacto por favor consulte “Si necesita ayuda adicional” en la página 17.
Referencia rápida En esta sección se identifican los distintos componentes del Monitor Móvil LCD de TOSHIBA. Para una descripción de cada componente consulte a continuación la ilustración y la tabla: Brillo (abajo) Botón de encendido Mini puerto USB Componente Mini puerto USB Botón de...
Control del brillo (arriba) Enchufe CC (DC-IN) 19V Instalación del Monitor Móvil LCD de TOSHIBA Uso de la cubierta de protección convertible La cubierta de protección convertible que está sujetada al monitor LCD sirve para protegerlo durante el transporte o el almacenamiento.
Almacenamiento del cable USB Y Para empacar y almacenar el cable USB Y que se suministra: Desconecte el cable USB de la computadora y el monitor y colóquelo a lo largo del lomo de la cubierta de protección convertible. (Ilustración de muestra ) Cómo almacenar el cable USB Y Enrolle la aleta hasta que los sujetadores del cierre de gancho y aro agarren el cable y lo aseguren dentro de la cubierta de tela.
Conexión del monitor LCD a la computadora Conecte el extremo pequeño del cable USB Y que se suministra en el mini puerto USB ubicado en el lado izquierdo del monitor. (Ilustración de muestra) Cómo conectar el monitor LCD Conecte el otro extremo del cable USB Y a uno de los puertos USB de la computadora.
Page 33
2. Sólo utilice el monitor LCD en posición horizontal y sobre un superficie plan y firme. N O T A Después de conectar el monitor LCD a la computadora, aparece el ícono del Monitor Móvil LCD de Toshiba ( sistema del escritorio de Windows desconectar el monitor. Ilustración A Ilustración B...
Presione la tecla Windows modos como se muestra a continuación. Para Microsoft Haga clic con el botón secundario en el ícono del “Monitor Móvil LCD de TOSHIBA” en la bandeja del sistema del escritorio de ® Windows para configurar los parámetros de visualización.
❖ La función de las teclas electrónica del Manual del usuario de las computadoras TOSHIBA, sólo administra el controlador de video interno de la computadora. ❖ Para la visualización de video, el Monitor Móvil LCD de TOSHIBA utiliza un controlador de gráficas de video...
Toshiba cuando se le presente un problema que no pueda resolver. Antes de llamar a Toshiba, por favor lea todos los consejos para la solución de problemas que se dan en este manual y en el Manual del usuario de la computadora.
Si ha seguido las recomendaciones contenidas en esta sección y no ha conseguido resolver los problemas, puede que sea necesario solicitar asistencia técnica adicional. Sitios web de asistencia técnica de Toshiba Estados Unidos pcsupport.toshiba.com Centros de asistencia al cliente de Toshiba...
Especificaciones Esta sección resume las especificaciones técnicas del Monitor Móvil LCD de Toshiba*. Monitor LCD Tipo de monitor LCD de 14.0 pulgadas Relación de contraste 400:1 (Típ.) Fuente de alimentación Adaptador de CA (Adaptador de CA vendido por separado). 100-240 V CA...
Especificaciones físicas Dimensiones (Anc. x Aproximadamente 340,5 x 239,5 x 15,5 mm (13,4 x 9,4 x 0,6 pulgadas) Alt. x Prof.) Peso neto Aproximadamente 795 g (1,75 lb) Consideraciones medioambientales Temperatura de 5° a 35° C (41° a 95° F) funcionamiento Temperatura de -20°...
Page 40
Índice botón botón de encendido control del brillo (abajo) control del brillo (arriba) brillo ajuste Características Centros de asistencia al cliente de Toshiba configuración monitor contenidos de la caja cubierta de protección convertible monitor especificaciones consideraciones ambientales especificaciones físicas fuente de alimentación fuente de alimentación, adaptador...
