C60 Lympstone
Owner's Handbook

Advertisement

loading

Related Manuals for Christopher Ward C60 Lympstone

Summary of Contents for Christopher Ward C60 Lympstone

  • Page 1 C60 Lympstone Owner’s Handbook...
  • Page 2 Time on your side Time on your side Your Christopher Ward watch has been designed in Britain and engineered in Switzerland by highly talented craftspeople. This ensures not only accurate and precise timekeeping, but also brings a real pride of ownership that only watches of the highest quality standards can hope to deliver.
  • Page 4 Built for the most testing of conditions, the dial is constructed in ultra-tough, ultra-light forged carbon – a material made from All these qualities mean the C60 Lympstone will be your trusty chopped carbon fibres infused with resin (there are around 500,000 companion wherever, and however, you go.

  • Page 6: Display And Control Buttons

    How to operate your C60 Lympstone Display and control buttons Compass Your C60 Lympstone has a maximum power reserve of 38 hours Setting Crown Minute Hand when fully wound. To re-power the watch after a period of non-use, Hour Hand simply wind the crown for approximately 20 revolutions.
  • Page 7 Features • Swiss made • High Definition Royal Marines crest laser- • Christopher Ward logo at 12 o’clock engraved on screw down backplate • 26 jewel self-winding mechanical • Forged carbon dial chronometer • Screw-down dual crowns stamped with • Rotating inner-compass bezel twin-flag motif •...
  • Page 8 Technical Information Sellita SW200 COSC Calibre Stainless steel (gun metal coating) Case Diameter 42mm 13.8mm Height 49.3mm Lug to lug 103g Weight 60 ATM (600 metres) Water resistance 28,800 per hour (4Hz) Vibrations +6/-4 seconds per day Timing tolerance 22mm Strap width...

  • Page 9: Setting The Time

    2 for winding in power. Wind in a clockwise direction to re-power recommended to pass beyond the desired minute and to set the the watch. Your C60 Lympstone has a maximum power reserve of hand backwards. 38 hours when fully wound. Normal wearing will allow the rotor to start re-powering the watch over time after putting on your wrist.
  • Page 10 1. Crown screw-down position 2. Manual winding 3. Time setting Unscrew and then pull...
  • Page 11 How to operate your C60 Lympstone Diving with your watch PLEASE NOTE: If using the bezel for a dive and let’s say the recognised maximum “no-stop time” is 55 minutes, then in this example (shown right) It is always useful and best practice to make a note on a dive slate the time at the surface immediately before the dive is 10.10am.
  • Page 12 Bezel marker No decompression limit Start of dive...
  • Page 13 How to operate your C60 Lympstone How to use the solar compass Example: If it’s 10 o’clock in the morning, point the hour hand at the sun. Then rotate the ‘S’ until it reaches 11 o’clock (ie: halfway between the hour hand and the 12 o’clock index). You can now The watch is fitted with a solar compass on the inner bezel.
  • Page 14 A. Northern hemisphere B. Southern hemisphere...

  • Page 15: Straps And Bracelets

    Using the quick-release pins on your strap/bracelet How to operate your C60 Lympstone Straps and bracelets 1. Locate the quick-release pin (or pins) 2. To reattach your strap (C) or bracelet (D), on your strap (A) or bracelet (B). pull the pin(s) inwards, and align the Pull the pin(s) inwards to detach.
  • Page 16 How to use the micro adjustment on your bracelet How to use the micro adjustment on your bracelet 1. Press buttons to release. 2. Pull open the clasp. 3. There are five micro adjustment positions, which allows for a maximum extension of 8.4mm.

  • Page 17: Water Resistance

    How to operate your C60 Lympstone Water resistance Although your watch has been through vigorous static pressure For these reasons, the water resistance rating of your watch (as testing, it is worth remembering that there are many variables that shown) should only ever be considered a guideline and we strongly can affect the water resistance of your watch.
  • Page 18 1 ATM (10 metres) 15 ATM (150 metres) 100 ATM (1000 metres) Safe to wear your watch while Safe to use while snorkelling in Professional deep sea diving washing your hands with tap water open water 3 ATM (30 metres) 30 ATM (300 metres) Washing your car and/or general Ideal for experienced divers and...
  • Page 19 60 Day Free Returns Our success depends on you being completely happy with your new Christopher Ward watch. You have up to 60 days from despatch to Your watch is constructed from the finest components and return your watch, with free shipping, and receive a replacement or materials available including one of Switzerland’s finest mechanical...
  • Page 20 Servicing and Repairs - the Christopher Ward way… repair. If you have not had your watch serviced at the recommended Our innovative approach to service and repair means that having interval, we will not cover the cost of the repair under warranty, your watch attended to doesn’t mean months of waiting followed...
  • Page 21 – listening to feedback which helps us actually a refurbished chicken shed!), Christopher Ward has won continually improve as we grow. As the owner of a Christopher Ward a worldwide following and can justifiably claim to manufacture watch, if you ever need to get hold of us we are at your service.
  • Page 22 Head office 1 Park Street, Maidenhead, Berkshire SL6 1SL United Kingdom Customer support UK and EU Tel: +44 (0)1628 763040 US Tel: +1 (877) 380 2288 ROW Tel: +1 (877) 380 2288 customerservices@christopherward.co.uk technical@christopherward.co.uk christopherward.com...
