- Page 1 TBS-1X TBS-2X Taco Bell Steamer TBS-1X & TBS-2X owner’s manual Manufacturing Numbers: 9100400, 9100402, 9100410 & 9100412 www.ajantunes.com P/N 1010698 Rev. I 03/12...
-
Page 2: Table Of Contents
Table of contents General Service/Technical aSSiSTance The Taco Bell Steamer produces steam using General ..........2 plain tap water for quick heating and recon- Warranty Information ......2 If you experience any problems with the stituting of food items. Simple push-button Service/Technical Assistance .... -
Page 3: Important Safety Information
imporTanT SafeTy WarninGS informaTion • Do not use a sanitizing solution or Be advised of the following warnings when operating and performing maintenance on abrasive materials. The use of these Use the following guidelines for safe opera- may cause damage to the stainless this unit. -
Page 4: Specifications
SpecificaTionS Width Depth Height Model No. 14.15” 9.7” 13.4” TBS-1X (359 mm) (246 mm) (340 mm) 25.75” 9.7” 13.4” TBS-2X (654 mm) (246 mm) (340 mm) Model No. Volts Watts amps Hertz plug Description TBS-1X 9100410 TBS-2X 3300 15.9 50/60 9100400 (per side) 6-20P Non-Locking... -
Page 5: Unpacking
UnpackinG Liner 1. Remove unit and all packing materials from shipping carton. 2. The box should contain the following • Taco Bell Steamer Guard • Handle & Handle Guard (Qty. 2 for TBS-2X) Handle • Water Quick Disconnect Kit (Qty. 2 for TBS-2X) • Water Measuring &... -
Page 6: Installation
inSTallaTion TBS-1X Top Cover calibration A Water Measuring and Calibration Kit is sup- TBS-2X generator plied with your unit and consists of: Cover • Two 24” Tubes • One Measuring Cup Diffuser CauTIoN This procedure exposes hot surfaces. Use extreme care when performing procedure as Figure 3. -
Page 7: Operating Instructions
operaTinG inSTrUcTionS NoTE: Steam generator must be cali- POWER power Switch brated before initial use. See the section titled Calibration in the Installation sec- tion of this manual. 1. Turn the power on and allow the unit to preheat for approximately 20-30 min- utes (Figure 6). -
Page 8: Daily Cleaning
Daily cleaninG monThly mainTenance WarNINg Turn the power off, unplug the power cord, 1. Turn the power off, unplug the power Your steamer utilizes an open steam and allow the unit to cool down before cord(s), and allow the unit to cool Generator. - Page 9 calibration 6. Use a brass or stainless steel wire NoTE: If the Calibration Kit is missing, use brush and small scraper to loosen and the Calibration Chart (Figure 11) to figure A Water Measuring and Calibration Kit is sup- remove excessive deposits from the the approximate volume.
-
Page 10: Troubleshooting
TroUBleShooTinG WarNINg To avoid possible personal injury and/or damage to the unit, inspection, test, and repair of electrical equipment should be performed by qualified service personnel. The unit should be unplugged when servicing, except when electrical tests are required. Use extreme care during electrical circuit tests. - Page 11 TroUBleShooTinG (continued) problem possible Cause Corrective action Unit only leaks water when Solenoid Valve is leaking due to debris Disassemble the Solenoid Valve and clean out the plunger. powered off. trapped within its plunger and seat. Reassemble and test. If the a leak is still present, replace the Solenoid Valve.
-
Page 12: Replacement Parts
replacemenT parTS Former TBS-2X Momentary Switch NOTE: Use item # 14 for all replacements of this part. noTe: This Exploded View displays the TBS-2X. The TBS-1X is virtually the same except with half the components. Refer to the next page for a Parts List that details the types of parts used in each unit as well as the number of parts used in that unit. -
Page 13: Replacement Parts - Tbs-1X & Tbs-2X
replacemenT parTS – TBS-1X & TBS-2X item Part Description Qty. item Part Description Qty. tbs-1X tbs-2X tbs-1X tbs-2X 0011229 Top Cover Assy. 0021133 Chimney 0011198 Top Cover Assy. 0021136 Chimney 7000150 Calibration Kit 0700554 Wire Set (not shown) 2100250 Guard, Knob, Top Cover 7000136 Terminal Block Kit (Includes #38, 50, &... - Page 14 replacemenT parTS – TBS-1X & TBS-2X (continued) oPtional Water Pressure reGulator Kit (P/n 7000314) general: This kit protects your equipment from any foreign debris in the water line that could get into the food, damage the unit’s solenoid (causing the unit to leak or flood) and also prevents excessive and/or fluctuation water pressure from interfering with the equipment’s proper and consistent operation.
-
Page 15: Wiring Diagram
WirinG DiaGram POWER NOTE: ALL WIRES TO BE 14 GA. TFE-200°C CORD UNLESS OTHERWISE SPECIFIED: (COLOR WIRE)= 14 GA. AWM-105°C {COLOR WIRE}= 18 GA. TFE-200°C <COLOR WIRE>= 18 GA. AWM-105°C CONTROL [COLOR WIRE]= 22 GA. TFE-200°C BOARD TERMINAL BLOCK GRN/YEL [ BLK ] [ WHT ] SOLENOID... -
Page 16: Notes
limiTeD WarranTy Equipment manufactured by Roundup Food Equipment Division of A.J. Antunes & Co. has been constructed of the finest materi- als available and manufactured to high quality standards. These units are warranted to be free from electrical and mechanical defects for a period of one (1) year from date of purchase under normal use and service, and when installed in accordance with manufacturer’s recommendations.
