A.J.Antunes SS-400TT User Manual

A.J. Antunes & Co.
We exist to make our customers successful.
Place this manual in the Toaster section
of your Equipment Manual.
Manufactured exclusively for
McDONALD'S ®
BY
A.J. ANTUNES & CO.
180 KEHOE BLVD.
CAROL STREAM, ILLINOIS 60188, U.S.A.
PHONE: 1-630-784-1000
TOLL FREE: 1-877-392-7854
FAX: 1-630-784-1650
www.ajantunes.com
Owner Information .....................................................2
General ......................................................................2
Warranty Information .................................................2
Service/Technical Assistance ...................................2
Specifications .............................................................3
Dimensions ................................................................3
Electrical Ratings and Plug Configuration .................3
Important Safety Information ....................................4
Installation ...................................................................5
Unpacking ..................................................................5
Equipment Setup .......................................................6
Installing the Surface Steamer ..................................6
The Antunes Food Service Equipment Division of A.J. Antunes & Co. provides the following limited warranty to the original purchaser of all McDonald's Equipment.
All components are warranted against defects in the material and workmanship for a period of two (2) years from date of original installation.
If any part becomes defective during period of this Warranty, Antunes Food Service will pay negotiated straight time labor costs to an Authorized Service Agent to
replace the part, plus travel expenses up to 50 miles/80 km, 1 hour each way (100 miles/160 km, 2 hours round trip).
WARRANTY EXCLUSIONS
• The cost of Installation.
• Equipment that has been damaged due to shipment. Purchaser should
make damage claim directly upon carrier.
• Alteration, misuse, abuse.
• Improper storage or handling.
• Improper maintenance.
• Failure to follow proper Installation instructions, including electrical connec-
tion.
• Improper or unauthorized repairs.
Antunes Food Service reserves the right to make changes in design or add improvements on any products. The right is always reserved to modify Equipment
because of factors beyond our control and government regulation. Changes to Equipment do not constitute a warranty charge.
This warranty is exclusive and is in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or fitness for a particular pur-
pose, each of which is expressly disclaimed. The remedies described above are exclusive, and in no event shall A.J. Antunes & Co. or any of its Divisions be liable
for special consequential or incidental damages for the breach or delay in the performance of this warranty.
This manual is for the exclusive use of licensees and employees of McDonald's Systems, Inc.
P/N 1011073 Rev. H 12/13
McDonald's
SURFACE STEAMER
MODEL SS-400TT
Manufacturing Number 9100906
A.J. Antunes & Co.
SS-200 & SS-400
Scan with mobile device or enter URL
for product and service information.
http://tiny.cc/ajaprodSS

TABLE OF CONTENTS

LIMITED WARRANTY
© McDonald's Corporation All Rights Reserved
SURFACE STEAMER SS-400TT
Connecting a Water Pressure Regulator ...................6
Operating Instructions ...............................................7
Programming ..............................................................8
Programming the Surface Steamer ...........................8
Factory Resets ..........................................................8
Generator Temperature .............................................8
Maintenance ................................................................9
Daily Cleaning ...........................................................9
Quarterly Cleaning (or as needed) ..........................10
Troubleshooting ....................................................... 11
Replacement Parts ...................................................14
Wiring Diagrams .......................................................17
Notes..........................................................................18
• Scheduled Maintenance procedures as outlined in your MRC Card.
• This Warranty does not cover Consumable items.
• Water pressure problems or contamination problems such as foreign material
in water lines or inside solenoid valves due to an incoming water source.
• Overtime or Holiday charges.
• Mileage over 50 miles/80 km (100 miles/160 km round-trip), or travel time
over two (2) hours.
• Freight, foreign, excise, municipal or other sales or use taxes.
• Consequential damages such as loss of profit, loss of time, the cost of repair-
ing or replacing other property which is damaged, or any other incidental
damage of any kind.
1
A.J. Antunes & Co.
