4000 GALLONS KOI POND PRESSURE BIO AQUARIUM FILTER
ITEM: 71015
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST

Advertisement

Table of Contents
loading

Related Manuals for Xtreme Power 71015

Summary of Contents for Xtreme Power 71015

  • Page 1 4000 GALLONS KOI POND PRESSURE BIO AQUARIUM FILTER ITEM: 71015 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur.

  • Page 3: Grounding Instructions

    GROUNDING INSTRUCTIONS Grounding Instructions: This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an appliance-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes and ordinances.
  • Page 4 FEATURES Keep your fish healthy and let them thrive in a clean and fresh pond! This powerful filter cleans out harmful algae and growth using a UV light purifier. Transform dirty green pond water into a crystal clear oasis, so your fish can live longer and happier for years to come.

  • Page 5: Installation

    INSTALLATION Do not submerge this product in water. The pressure filter should be used in-line, between a pump and a water feature or waterfall. The filter can also be partially buried to help disguise it in your garden. Place the filter on a firm and level base, e.g. on a slab. Please make sure that there is unhindered access to the lid in order to be able to carry out maintenance on the filter.
  • Page 6 INSTALLATION POND SIZE / WITH OR WITHOUT FISH The filter system with integrated UVC must be running permanently, 24 hours a day. The UVC lamp must be replaced after 8,000 hours of operation in order to ensure that the filter UVC continues to operate properly. PRESSURE LOSS DUE TO HEIGHT DIFFERENCE The selection table allows for a maximum height difference of 1m between the surface of the water and the highest point of the filtering system.

  • Page 7: Maintenance And Cleaning

    INSTALLATION STARTING THE PRESSURE FILTER Before each start up, check that the connected hoses, sealing cap and tension ring with safety latch are sitting correctly. The function switch must be set to “Filter”. it is imperative that you read and follow the following guidelines.

  • Page 8: Replacing The Uvc Lamp

    INSTALLATION 9. Clean the lid sealing ring and the edge of the filter box. 10. Push one filter plate with the collar facing upwards, onto the lattice pipe and the cleaning rods. 11. The filter sponges are pushed on from the casing lid, starting with a large blue filter sponge and always alternating with a small yellow filter sponge.

  • Page 9: Please Read The Following Carefully

    PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
