Mr. Beams MB130 Installation Instructions

Spotlight features:

Fully Adjustable: Light can be rotated 360° as well as up and down
Light Coverage: up to 400 sq ft
Durable, Weather Resistant: Tight seals and UV resistant material allow the light
to work in all weather conditions
Remote Control: Control from up to 70 ft away

What is included per light:

• 1 Remote Controlled Spotlight
• Mounting Base
• 3 Screws & 3 Anchors
• 1 Remote Control with Mounting
Bracket + 2 screws
• (1) 3V Coin Battery

Customize your remote settings

Spotlight can be turned on or off by pressing the remote control. Activat-
Remote Control
ing the remote will override the light sensor, and light can be activated at
Activation
any time. Default mode is motion sensor on 30 second auto shut-off.
First activate the light with remote control. Next, hold the ON button
2 Auto Shut-off
down until light blinks. When it blinks 1x, auto shut off is set to 1 hour.
Options
When it blinks 2x, it is set to 4 hours.
First activate the light with remote control. Next, press the Bright
3 Brightness
or Dim button on the remote to adjust the brightness. Brightness
Modes
Options: 60, 90, or 140 lumens.
Motion Sensor
Spotlight will activate when motion is sensed from up to 30 ft away.
Activation Motion sensor only activates in darkness to conserve energy.
Activate light with the remote. Hold the motion sensor button down
until light blinks. When it blinks 2x the motion sensor has been
Disable Motion
disabled. When it blinks 4x, the motion sensor has been enabled.
Light will remember your last brightness setting.

Set up

2. Push down on
1. Remove front
battery door tab to
cover of Spotlight
release. Insert 3 D-Cell
by rotating count-
batteries into Spotlight.
er-clockwise as
Attach battery door by
shown above. Pull
matching the tabs to
face out from cup
the rectangular holes
to reveal battery
and then push down
holder.
on front until door
clicks into place.

Using the remote

1. Open the Remote Control with a small coin
and insert one flat 3V battery (included) as
shown on the inside of the Remote Control.
Smooth side of battery should be facing up.
Tips:
Use only new alkaline D-Cell batteries with 1.5V rating.
•
Do not mix old and new batteries. If batteries are not new, it may cause light to malfunction.
•
Install batteries with polarity in correct position.
•
• Antenna is only connected at one end. It acts as a receptor for the remote.
Battery Caution:
1) Do not mix old and new batteries
2) Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium) or (Nickel Metal
Hydride) batteries
3) Do not dispose of batteries in fire
4)Batteries should be recycled or disposed of as per state and local guidelines
Patent # 8,203,445
Installation Instructions
Customizable Wireless Spotlight with Motion Sensor and
Remote Control
MB130

What you need to install:

• 1 Small Screwdriver
• 3 D-Cell Alkaline Batteries
4. Match arrows 5. Determine location for mount-
then turn clock- ing Spotlight. NOTE: For best
performance, Spotlight should be
wise. Make sure
positioned so motion sensor is on
unit is securely
closed with arrow top and light is on bottom.
pointing at the
6. Remove mounting base by
lock symbol to
turning thumb screw counter-
ensure weather
clockwise.
proof seal is tight.
7. Pull mounting base off stem.
2. Determine
placement for bracket
3. Slide Remote
for remote and attach to
into bracket as
wall using two screws
shown above.
(included) or tape.
Motion &
Light Sensor
LED Light
Indicator
Light
Dim
Bright Motion
Control
Mounting
Bracket
Mounting Base
8. Drive three screws
into the three holes
located on mounting
base.
9. Insert spotlight stem
back into mounting
base pointed in desired
direction and tighten
thumb screw in base.

Syncing your light

1. The remote is paired to work only with
the Spotlight it is packaged with. To sync
additional spotlights to a single remote,
press the exposed black button on the
spotlight next to the battery compartment
for 3 seconds while pressing the ON button
on the remote.
* Visit our website to view installation video.
* 1 year limited warranty. See enclosed card for details.
32333 Aurora Rd. Suite 100 Solon, OH 44139
Knuckle Screw
Mounting Base
Thumb Screw
10. Loosen larger
thumb screw that
connects Spotlight
head to mounting
base and adjust
Spotlight head to
proper direction as
shown above. Tight-
en thumb screw.
877.298.9082
www.mrbeams.com
