Purpose
The document is aimed to illustrate the procedure of stand assembly for 700 series
scanners.
Scope
This document is applicable to SG7XX, SG7XXBT, LG7XX, LG7XXBT, IG7XX and
IG7XXBT series scanners.
Components
Each component of the stand is illustrated as following.
HOLDER
SUPPOR
BOLT
Document No: TSSOP121024-1
Document Name: 700 Series Assemble Stand
700 Series Assemble Stand
NECK
BASE
Version: V1.0
Data: 2012/10/24
Technical Support Department
Advertisement
Table of Contents
Related Manuals for Champtek Scantech ID 700 Series
Summary of Contents for Champtek Scantech ID 700 Series
- Page 1 700 Series Assemble Stand Purpose The document is aimed to illustrate the procedure of stand assembly for 700 series scanners. Scope This document is applicable to SG7XX, SG7XXBT, LG7XX, LG7XXBT, IG7XX and IG7XXBT series scanners. Components Each component of the stand is illustrated as following. HOLDER NECK SUPPOR...
- Page 2 Procedure Please follow the procedure below to assemble stand. Insert the NECK on the top of SUPPORT. Insert and secure the BOLT in the screw hole. nsert the SUPPORT on the BASE. Turn the SUPPORT clockwise about 45° until locked on the BASE Document No: TSSOP121024-1 Version: V1.0 Data: 2012/10/24...
- Page 3 Attach the HOLDER on the NECK. Finish assembly. Document No: TSSOP121024-1 Version: V1.0 Data: 2012/10/24 Technical Support Department Document Name: 700 Series Assemble Stand...
