- Page 1 User Manual for the UV Radiation Sensors types UV3pA, B and AB UV3-UM-1.1 Delta-T Devices Ltd...
- Page 2 Copyright All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Delta-T Devices Ltd. Under the law, copying includes translation into another language. Copyright © 2000, 2003 Delta-T Devices Limited.
-
Page 3: Table Of Contents
Contents Introduction Summary of Features Scope of This Manual Installation Unpacking Description of Equipment Mounting the Sensor UV3p Sensor Connections Outline Specs Sensor Wiring Power Requirements Cable Data Requirements UV3p Logger Connections DL2e Logger UV3p Wiring Schematic for DL2e DL3000 Logger Other Loggers Specifications Spectral Response... - Page 4 Troubleshooting Technical Support Problems Appendices UV Measurement Techniques Environmental Monitoring Note (UV-AN 1.1) Measurements from different light sources Glossary Introduction UV3 User Manual 1.1...
-
Page 5: Introduction
This manual contains the specifications and performance of the UV3pA, B and AB sensors, and describes their installation with Delta-T data loggers. You may also need to refer to the appropriate Delta-T logger User Manual or On-line Help. UV3 User Manual 1.1... -
Page 6: Installation
The parts supplied may include: • UV3pA, B or AB sensor with cable fitted • Levelling mount or other mounting bracket Cable lengths, other than the standard 5m, that are pre-ordered will normally be fitted in unbroken lengths. -
Page 7: Mounting The Sensor
Cosine Diffuser Filter Glasses 25mm Photodiode Amplifier 23mm 43mm 50mm Mounting the Sensor M4 mounting screws are provided for the two tapped holes in the base of each sensor. The mounting holes are at 43 mm spacing. Warning! Do not use the central hole for mounting the sensor. It is provided only for factory calibration purposes. -
Page 8: Uv3P Sensor Connections
Parameter Value Output 1 mV per W.m of radiation in the relevant wave band Peak λ Type Waveband FWHM* UV3pA UV A 373 ±2 nm 31 ±2 nm UV3pB UV B 313 ±2 nm 26 ±2 nm UV3pAB UV AB 360 ±5 nm... -
Page 9: Cable
Cable Up to 100m of cable can be fitted at time of ordering. The UV signal voltage output is not sensitive to the cable length within this limit. Data Requirements Typical common usage: UV irradiance output Sample every minute. Average every hour or half-hour. UV3 User Manual 1.1 UV3p Sensor Connections... -
Page 10: Uv3P Logger Connections
UV3p Logger Connections DL2e Logger Use with LAC1 This diagram shows the wiring connections for the LAC1 analogue input card. For use with other cards, please refer to the DL2e Logger User Manual UV3p Wiring Schematic for DL2e – 1 + –... - Page 11 UV3p sensors. If you have an earlier release of the LS2e software, you can download the latest version from the Delta-T web site. All that remains is to choose suitable sampling and logging intervals (see data requirements) in your logging configuration.
-
Page 12: Dl3000 Logger
UV3p sensors. Then select suitable sampling and logging intervals (see data requirements). Please consult Delta-T Technical Support if you need further assistance. Other Loggers Any logger with a sensitive differential mV input range (e.g. 0 – 50 mV), and a facility for powering up sensors, can be used for the UV3p range of sensors. -
Page 13: Specifications
Specifications Spectral Response Figure 1 UV3pA Relative Spectral Response Wavelength (nm) Figure 2 UV3pB Relative Spectral Response Wavelength (nm) UV3 User Manual 1.1 Specifications... -
Page 14: Cosine Response
Figure 3 UV3pAB Relative Spectral Response Wavelength (nm) Cosine Response Figure 4 30° True Cosine UV3p Detector 60° Specifications UV3 User Manual 1.1... -
Page 15: Uv3P Specification Table
UV3p Specification Table Parameter Notes High quality photodiodes: Photodiode Si (A, B); GaAsP (AB) Sensitivity 1 mV per W.m of radiation in the respective waveband Wavebands A: 373 ±2nm peak; 31 ±2nm bandwidth FWHM B: 313 ±2nm peak; 26 ±2nm bandwidth AB: 360 ±5nm peak;... -
Page 16: Amplifier Characteristics
This error is in addition to any error contributed by the photodiode. Certification CE Conformity Delta-T Devices Ltd holds a CE Declaration of Conformity issued by the manufacturer. The manufacturer certifies that Ultra-violet detectors with integral amplifiers model numbers UV3pA, UV3pB and UV3pAB comply with European directive EMC (89/36/EEC) for Radiated Emissions, Conducted Emissions, Radiated Immunity and Fast Transients. - Page 17 Laboratory (NPL Certificate No. 120R11/921011/D18) and the National Bureau of Standards within the limitations of the NPL’s and the NBS’s calibration services, or have been derived from known values of physical contacts. MODEL: UV3pA SERIAL NUMBER: 6252/UV3pA-112 CERTIFICATE NUMBER: 7438/2 DATE ISSUED: 22 June 2000 VALID:...
-
Page 18: Maintenance
Recalibration The calibration certificate validity period is 12 months. Annual recalibration is essential. Return the sensor to Delta-T. Contact your agent (or Delta-T direct) in advance for prices and despatch instructions before returning the unit. Storage Observe the storage temperature limitations (see Specifications). -
Page 19: Warranty And Service
Delta-T shall not be liable to the buyer by reason of any delay or failure to perform our obligations in relation to the goods and/or services, if the delay or failure was due to any cause beyond the Delta-T’s reasonable... -
Page 20: Service And Spares
No goods or equipment should be returned to Delta-T without first obtaining the agreement of Delta-T or our agent. On receipt at Delta-T, the goods will be inspected and the user informed of the likely cost and delay. We normally expect to complete repairs within a few working days of receiving the equipment. -
Page 21: Problems
Small negative readings in zero Amplifier offset drift with temperature (e.g. UV light conditions overnight). Ignore. UV light calibration appears See appendices for the proper interpretation incorrect of readings. Check validity of calibration certificate. Return to Delta-T for recalibration. UV3 User Manual 1.1 Troubleshooting... -
Page 22: Appendices
UV light may vary. Please contact Delta-T if you need further guidance. Environmental Monitoring Note (UV-AN 1.1) Ozone depletion in the stratosphere caused by CFCs and other chemicals has raised the monitoring of solar ultraviolet radiation (UVR) to a new level of importance in environmental research. -
Page 23: Measurements From Different Light Sources
UV sensor. Glossary Terms and Units These terms apply to solar radiation measured with the Delta-T range of energy sensors (types ES2, UV3p, GS1, GS2, TSL) and the PAR Quantum Sensor type QS2. Cosine Corrected Refers to a sensor that is designed to have a cosine response. - Page 24 Cosine Response A sensor with a true cosine response gives an output that is proportional to the cosine of the angle of incidence of the ray of light. The angle of incidence is the angle between a perpendicular to the sensor surface and the ray of light.
