Summary of Contents for Super Tramp King 110
- Page 1 USER GUIDE Adult assembly required Read User Guide before assembling Please keep this guide for further reference Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk...
-
Page 2: Your Warranty
Springs – 10 years structural failure due to rust 12’x’8 Rectangular Bed – 5 years – structural failure due to rot King 110 Frame Pad – 12 months – stitching failure only Net – 12 months – manufacturing defects only Ladder –... -
Page 3: Before You Start
Before You Start Siting Your Trampoline Your trampoline works best and is safest if it is completely level. It is vital that you keep two metres of unobstructed lawn space surrounding the trampoline at all times. The Bouncer trampoline is designed to stand on a lawn or other soft surfaces such as artificial grass and bark. - Page 4 Safe Bouncing Guide Standing Bounce Use the basic “feet to feet” standing bounce to warm up and get the feel of the trampoline. Try to keep the body straight. Your legs should be slightly apart when landing on the bed and together in the air with toes pointed.
- Page 5 Safe Bouncing Guide Pike Jump Start as if doing a standing bounce. At the top of your bounce, bend your body at the hips by raising your legs whilst keeping them straight and together. Arrive at the horizontal position and briefly touch your shins.
- Page 6 King 110 Parts List 1 x Polymesh 4 x Leg 2 x Leg Extensions Bases 74 x 215mm Springs 16 x 165mm Toggle Loops 2 x End 2 x Side 2 x Leg 4 sets of Leg Brace Rails Rails...
-
Page 7: Exploded Diagram
Exploded Diagram Polymesh Leg Brace Leg Brace Leg Extension Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk... -
Page 8: Assembling The Frame
Assembling the Frame STEP Before you begin, lay the frame components out on the ground and note the parts list. The frame sections have been labelled A-F to aid you during the construction process. Please note: square-shaped holes in Hole parts A and D (end rails and leg bases) are off-centre. - Page 9 STEP To begin the frame assembly, start by slotting parts A and B together to form a complete top-frame. You may notice that the end rails are slightly misaligned; this is necessary to add tension to the frame. Note that the small holes in these frame sections must face upwards.
- Page 10 STEP The final phase of frame construction involves fixing part E to the assembled frame. You will need the nuts and bolts provided to complete this. Part E (leg braces) should connect to parts B (end rail) and C (leg base). When attaching the first leg brace, make sure that you bolt the leg brace to the leg base first, and then followed by the end rail.
- Page 11 STEP Begin attaching the springs by fitting a total of eight springs between the bed and the frame. You should do this at each corner so that the bed is left hanging loosely. STEP Proceed to fit the remaining springs starting in the order shown below and continuing in the same pattern.
- Page 12 Frame Pads STEP STEP Begin by laying each frame pad section in Now, turn each frame pad upside down the correct place on top of the frame. to reveal the eyelets. Side Pad Eyelets on underside of Frame Side Pad STEP Start threading the black elasticated end of the toggle loops through the Toggle...
- Page 13 STEP Once all toggle loops have been looped though, turn the frame pads over. Both the springs and framework should now be covered. STEP Proceed to feed each short pad in to the corner pocket of each long pad. STEP Once done, begin to fix the frame pads in to place by looping the toggle loops around the frame and then secure by pulling the black toggle through the elastic.
- Page 14 CONGRATULATIONS! Your is now assembled and ready for use. is assembled and ready for use. Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk...
-
Page 15: Useful Information
Trampoline Care and Maintenance General Useful Information Your Super Tramp trampoline has been designed to A stretched or dead spring can be identified live outdoors all year round and will generally where there is visible light through the coils of require very little maintenance. - Page 16 Thank you for purchasing a Super Tramp Trampoline We hope you found this guide helpful. Visit our website for our full range of trampolines, spare parts and accessories www.supertramp.co.uk Follow Us On Social Media! @supertrampuk @supertramptrampolines Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk...
