Atop IO5202 Series Hardware Installation Manual

Industrial IoT Remote I/O
IO5202 Series
Version 1.0
Updated in May, 2020
P/N : 89900584G

Inside the package you will find the following items:

■ Industrial IoT Remote x 1
■ 3-Pin Lockable terminal block for power x 1
■ 10-Pin I/O terminal blocks x 2
■ 5-Pin Lockable terminal block for Serial port x 1 (-TB models only)
■ Wi-Fi Antenna x 1 (-W models only)
■ Installation Guide with Warranty Card x 1
Never install or work on electrical or cabling during periods of lightning activity.
Never connect or disconnect power when hazardous gases are present.
Warning:Hot Surface Do Not Touch. RESTRICTED ACCESS AREA: The equipment
should only be installed in a Restricted Access Area.
This equipment should be installed indoor and not connect directly with equipment
installed outdoor.
I n d o o r I n d o o r
1. Grounding Screw
2. Terminal for Power 1
3. Frame Ground
2
4. Reset button
3
4
IO5202-TB-W Series Front View IO5202-DB-W Series Front View
1 1
PWR RUN
2 8 2
TX RX
3 3
COM
4 4
WLAN
5 5
6 6
7 7
9
10 11
1. System Power LED 5. Wi-Fi function LED
2. System Run LED 6. 10/100 Ethernet Port 2
3. COM LED-TX 7. 10/100 Ethernet Port 1
4. COM LED- RX 8. Wi-Fi Antenna SMA female connector
1. Proceed then to fix the antennas to the female RP-SMA
connectors deemed to (Fig. 1). You can then choose
whether to plug in the I/O ports at this point or do it later
depending on the actual location of the device or level
of comfort for performing such operation.
2. If you have purchased the wall mount kit, proceed to place
the screws on the back of the device as show in (Fig. 2).
Wall mount Screw spec: M3 * 0.5P
Wall mount Screw specification: M3, screw
Depth: 4mm (Max.); Screws x 4 pcs
3. Once the plate has been firmly put in place, proceed to mount the whole
device as shown in (Fig. 3).Proceed to (Fig. 4) if you want to remove the
device from DIN-Rail.
V+
F.G.
4. Next we can then proceed to connect the device to the LAN (switch or PC,
depending on the case), take care on using the RJ-45 connector; after this we
can then proceed to the device's settings.
5. Although internal grounding has been done inside, in order to
ensure overall maximum performance and protect your device, it
is still strongly advised to ground the device properly; hazardous
ESD can come into contact and damage your equipment. On the
power terminal block, there is a terminal for Frame Ground, you
can choose whether to connect it to the grounding or you may
opt to connect to the grounding screw next to the terminal block
( the one chosen should be connected at all times ) (Fig. 5).
■ The opening to the sides are for the device's heat dissipation
PWR RUN
8
please never obstruct or cover them with any objects or try to
TX RX
COM
insert them through it.
WLAN
LED Color
9
PWR Green
WLAN Green
RUN Green
TX COM Green
9. I/O Port
RX COM Green
10. TB-COM Port
11. DB-COM Port
Power input : 12~48 VDC 0.8A MAX
1
2
State Description
On PWR is connected
Off PWR is disconnected
On Wireless Module is connected to Wifi
Blinking Wireless Module is transmitting/ receiving
Off Wireless Module is not connected
On System is booted up and running
Off System is still booting up or powered off
Blinking COM 1 is transmitting
Off COM 1 is not transmitting
Blinking COM 1 is receiving
Off COM 1 is not receiving
1
2
V+
F.G.
(Fig. 5)
