Traceable 3460 Instructions

TRACEABLE

SPECIFICATIONS

Cat. No.
Maximum Allowed PSI
PSI Range
PSI Resolution
mbar Range
mbar Resolution
bar Range
bar Resolution
cm/H O Range
2
cm/H O Resolution
2
inch/H O Range
2
inch/H O Resolution
2
feet/H O Range
2
feet/H O Resolution
2
mm/Hg Range
mm/Hg Resolution
inch/Hg Range
inch/Hg Resolution
kg/cm 2 Range
kg/cm Resolution
2
oz/inch 2 Range
oz/inch 2 Resolution
kPa Range
kPa Resolution
Display: / ", 4- digit LCD.
1
2
Accuracy: ±0.3% of full scale at ±25
Size/Weight: 2 /
3
Response time: 0.5 seconds
32-122
Operating Temp Range:
Features: Memory feature,
Backlight display,
RS-232 capability.

CONTROL BUTTONS

Powers unit off and on
REC Record mode
HOLD "Freeze" the pressure reading on the display
DIF -

Differential mode

UNIT Cycle meter through pressure units of measurement
Backlight function

OPERATION

On / Off / Auto Power Off
Press the button to turn the meter on. The meter will shut off
automatically approximately 20 minutes after every power on.
The "auto power off" function can be disabled for recording or
operating over longer periods of time by pressing POWER and
HOLD buttons simultaneously before power on. An "n" will
appear in the middle of the screen at which time the HOLD button
can be released, and then the power button. The "auto power
off" mode has now been disabled.
MANOMETER/PRESSURE/VACUUM INSTRUCTIONS
®

RANGE AND RESOLUTION CHART

3460
20
–5.000 to 5.000
0.003
–345.0 to 345.0
0.2
–0.3450 to 0.3450
0.001
–351.0 to 351.0
0.2
–138.0 to 138.0
0.1
–12.00 to 12.00
0.01
–259.0 to 259.0
0.2
–10.00 to 10.00
0.01
–0.350 to 0.350
0.001
–80.00 to 80.00
0.05
–34.50 to 34.50
0.02
C
o
x 7 / x 1 / / 5 oz
1 1
4 8 8
F (0-50 C)
o o
3461
30
–15.00 to 15.00 –30.00 to 30.00
0.01
–1034 to 1034 –2068 to 2068
1
–1.034 to 1.034 –2.068 to 2.068
0.001
–1055 to 1055 –2109 to 2109
1
–415.0 to 415.0 –830.0 to 830.0
0.3
–35.00 to 35.00 –69.00 to 69.00
0.02
–776.0 to 776.0 –1551 to 1551
0.5
–31.00 to 31.00 –61.00 to 61.00
0.03
–1.060 to 1.060 –2.110 to 2.110
0.001
–240.0 to 240.0 –480.0 to 480.0
0.2
–103.0 to 103.0 –207.0 to 207.0
0.1
Backlight Feature
Press the
approximately 20 seconds then turns off automatically.

Measurement Modes

The meter can be set to measure pressure in the following
modes: bar, mmHg, ozin
cmH 0 and mbar. Each press of the UNIT button will cycle
2
the meter through each of the measurement modes. An
arrow at the bottom of the LCD will indicate the mode
selected. The meter will default to the mode last selected
before meter was turned off.

Clearing Display to Zero

To clear the display to zero disconnect from all pressure and
press the HOLD button for 3 seconds. "o o o o" will appear
on the LCD and the meter value will be cleared to zero.

Hold Mode

Pressing the HOLD button once will "freeze" the measure-
ment reading. "HOLD" will appear at the upper left of the LCD
indicating the meter is in the hold mode. Press the HOLD
button again to return the meter to pressure measurement
mode.
3462 3463
60 150
–100.0 to 100.0
0.02 0.1
–6895 to 6895
2 4
–6.895 to 6.895
0.002 0.004
–7031 to 7031
2 4
–2768 to 2768
0.5 2
–231.0 to 231.0
0.04 0.2
–5171 to 5171
1 3
–204.00 to 204.00
0.1 1.0
–7.030 to 7.030
0.002 0.004
–1600 to 1600
0.3 1
–690.0 to 690.0
0.2 0.4
button and the backlight illuminates for
2 , kgcm 2 , psi, inH
(Continued on next page )
0, kPa, ftH 0, inHg,
2 2
