Installation instruction SF letters –
Single letters with low-voltage transformers
1., Purchased parts package
letters with cable
connection
2., Fastening of the letters
B
A
C
3., Wiring of letters to converters
B
A
red
black
red
red
black
branch connector filled with conductive gel
Low-voltage
transformers
1., Adjust the drawing
3., Fix the letters
C
red
black
black
~
230 V
incidentals
A
PARALELL CIRCUIT!
Always connect a red wire to the red main, a black
wire to the black main.
Mixing-up the cables DOES NOT cause any damage
in the sign.
B
A
installation drawing
2., Drill the fixing and cable
holes according to the
drawing
C
Advertisement
Table of Contents
Related Manuals for Scan Sign SF Series
Summary of Contents for Scan Sign SF Series
- Page 1 Installation instruction SF letters – Single letters with low-voltage transformers 1., Purchased parts package letters with cable Low-voltage installation drawing incidentals connection transformers 2., Fastening of the letters 2., Drill the fixing and cable 1., Adjust the drawing holes according to the drawing 3., Fix the letters 3., Wiring of letters to converters...
- Page 2 4., Installation of converters and power connection Accurate power supply voltage: 230V Connection should be made by a certified electrician. 230 V 6., Necessarily avoid! Attention! Avoid connecting earth to LED wire! Damages on wire insulation and short circuit cause destruction of LEDs and converters.
