300 LB. CAPACITY 30" x 16" 2-SHELF
STEEL SERVICE TOOL CART
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
*Actual product may vary slightly
42813
02/2017
Advertisement
Table of Contents
Related Manuals for Steel Core 42813
Summary of Contents for Steel Core 42813
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 42813 02/2017 or e-mail customerservice@focus-ontools.com...
- Page 2 Tool Cart Safety Warnings 1. Do not ride or climb on Cart. Keep away from children. 2. Do not exceed 300 lb. capacity, evenly distributed. Be aware of dynamic loading! Sudden load movement may briefly create excess load causing product failure. 3.
- Page 3 Attaching Top Tray Attach Top Tray (1) to the other end of the legs using Bolt (9) twelve Bolt (9), Washers (11) and Lock Nuts (8). (Four Washer (11) holes on one end of the top tray are reserved for attaching the Handle in the next step.) Lock Nut (8) Post (7)
- Page 4 Assembly Instructions (Continued) Attaching Wheels 1. Decide on which end of the Cart to mount the pair of Rigid Wheels (5) and pair of Swivel wheels (3). For example, mounting the Fixed Wheels on the Handle end of the Cart will make a push Cart like those in a grocery store. 2.
- Page 5 Parts List and Assembly Diagram Part Description Q’ty Part Description Q’ty Top Tray Looknut M6 Bottom Tray Bolt M6 x 12 Swivel Wheel Bolt M6 x 16 Handle Washer �6 Rigid Wheel Carriage Bolt Screw M8 x 16 Pipe Plug �32 Washer �8 Post Looknut M8...
- Page 6 Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
