26" 4-DRAWER SERVICE CART
Please carefully read and save these instructions before appempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
*Actual product may vary slightly
42815
05/2016
Advertisement
Table of Contents
Related Manuals for Steel Core 42815
Summary of Contents for Steel Core 42815
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 42815 05/2016 or e-mail customerservice@focus-ontools.com...
-
Page 2: Specifications
SPECIFICATIONS Maximum Weight Capacity 580 Lbs. overall; Top Tray: 200 Lbs. 2 Small Drawers: 30 Lbs. each Medium Drawer: 50 Lbs. Bottom Drawer: 70 Lbs. Bottom Tray: 200 Lbs. Overall Dimensions 33-1/2” Long x 17-1/2” Deep x 38-1/4” High Handle 16-1/8”... - Page 3 During assembly dress properly. Do not wear loose clothing or jewelry. Con- tain long hair. Do not overreach. Keep proper footing and balance at all times. Use safety equipment during assembly. Always wear eye protection. Always wear ANSI-approved safety goggles when assembling the Roll Cart. Do not force the product.
- Page 4 Note: Please note the number on the key and store it in a safe place. This number may also be on the lock. It will be needed if extra keys are ordered. ASSEMBLY INSTRUCTIONS Note: For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram on page 6.
-
Page 5: Inspection, Maintenance, And Cleaning
Check the Roll Cart to make certain that it sits evenly and that all hardware is squarely set. Make certain all drawers slide properly, that all locks work, and that Casters roll smoothly and evenly. OPERATING INSTRUCTIONS Set the Roll Cart up in the desired location. Make certain to set both Locking Casters (10) once the Roll Cart is in place. -
Page 6: Parts List And Assembly Diagram
PARTS LIST AND ASSEMBLY DIAGRAM Part Description Q’ty Part Description Q’ty Right Leg Post Ball Type Bolts M8 x 16 Ball Type Bolts M8 x 12 Support Frame Spring Washer Locking Caster Bottom Tray Upper Tray/Drawer Unit Swivel Caster Left Leg Post Bolts M8 x 16 Push Handle customerservice@focus-ontools.com... - Page 7 Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
