2. introduction

folding design saves space and makes these axle stands ideal for occasional use. Constructed entirely from steel and folds flat for ease of
storage. fitted with locking safety pin. sold in pairs.

3. specificAtion

Model no: .......................................................... As2000f.V2
capacity each: ....................................... 2 tonnes (2,000 kg)
capacity Pair: ......................................... 4 tonnes (4,000 kg)
min Height: ................................................................. 275mm
max Height ................................................................. 365mm

4. operAtion

4.1. familiarise yourself with the product. check that the stands are in good order and condition and that no damaged has been
sustained during transit. Familiarize yourself with the folding mechanism (fig. 1.1) and the extending legs (fig.1.2). Insert the centre
column (fig.1.3) in the centre tube (fig.1.4), adjust to height required and insert the locking pin (fig.1.5). When lowering the center
column, hold the center column firmly before removing the pin. Failure to do so will allow the center column to free fall through the
center tube (fig.1.4) which may be dangerous.
4.2. ensure the maximum load does not exceed 4 tonnes per pair of axle stands, (2 tonnes for each stand).
4.3. refer to vehicle owners hand book for correct jacking procedure. check to ensure that manufacturers recommended jacking points
are in good condition.
4.4. ensure the vehicle brake is on (or in parked mode) and wheels are chocked.
4.5. ensure the stand legs are fully extended and adjust height of stand to correspond with the raised vehicle.
4.6. check that the locking pin is correctly pushed all the way through the centre column and out of the other side, insert safety pin, then
position stands under vehicle at points specified by vehicle manufacturer.
4.7. carefully and slowly lower the load onto stands. ensure the load bearing points sit in the center of the stand saddle and check that
the stands are stable and not leaning. Also ensure that there are no objects or persons that could impede the safe lowering of the
vehicle onto the stands.
4.8. After use, hold the centre column (fig.1.3) firmly when removing the locking pin (fig.1.5). Failure to do so will allow the center column
to fall freely through the main center tube which could be dangerous.
WArning! ensure you follow all instructions carefully. failure to note these warnings may cause damage, serious injury or loss of
‰
life.

5. MAintenAnce

5.1. Before each use check to ensure stands and stand welds are not cracked, and that there are no missing and/or damaged parts.
WArning! Any stand that appears to be damaged in any way must be removed from service immediately.
‰
5.2. ensure the locking pin, folding arms and mechanism are in good order and condition.
5.3. Due to the potential hazards associated with these stands, do not misuse, or make any modification to the stands or components.
5.4. it is the responsibility of the stands owner to ensure the operator has read these instructions, and that the operator is familiar with
the stands use and limitations.

environmental protection

recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
iMportAnt: no liability is accepted for incorrect use of this product.
WArrAnty: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
