- Page 1 Instruction Manual Compressing and stretching machine SSG 16 SSG 16...
-
Page 2: Table Of Contents
Passing on as well as copying of this document, the use and distribution of its content are prohibited if not explic- itly permitted. Contraventions are liable to compensa- tion. Subject to technical modifications and error. SSG 16 | Version 2.01... -
Page 3: Introduction
Introduction 1.3 Limitation of liability All information and notes in these operating instructions With the purchase of the device of METALLKRAFT you were summarised taking the applicable standards and have made a good choice. rules, the state-of-the-art and our long-term knowledge and experiences into consideration. -
Page 4: Obligations Of The Operating Company
- During the entire lifetime of the machine, the oper- ating company must verify whether the operating manuals prepared by her correspond to the cur- rent status of the regulations, and must adapt these if necessary. SSG 16 | Version 2.01... -
Page 5: Personal Protective Equipment
The version SSG 16 can handle a maximum plate thickness of 1.5 Manufacturer: Certain works may only be performed by specialist per- Proper use also includes compliance with all information sonnel of the manufacturer. -
Page 6: Residual Risks
6.3 Accessories tation damage. If you notice any damage to the device please report this immediately to the carrier or dealer. - Compression jaw SET for SSG 16 for metal Item number: 3776106 5.2 Packaging - Stretching jaw SET for SSG 16 for metal... -
Page 7: Assembly
Hold the two M10 screws for the axle and insert the threaded connection into the opening. Fig. 4: Mount the foot pedal Put some fat on the axle. Fig. 9: Inserting the threaded connection Fig. 5: Greasing the axle SSG 16 | Version 2.01... - Page 8 Insert the axle into the hole at the end of the foot pedal. First insert the corresponding screws for the assembly of the jaws. Fig. 13: Insertion of the axle Fig. 17: Assembly of the jaws SSG 16 | Version 2.01...
-
Page 9: Operation
There are crushing hazards on upper limbs. Fig. 20: Mount the locking pin Place the unused jaws in the appropriate box. Attach the wrench to the stand for mounting on the tripod. Fig. 21: Storage of the cheeks SSG 16 | Version 2.01... -
Page 10: Cleaning, Maintenance And Service/Repair
- The machine components and processing materials must be disposed of us-ing the intended disposal me- Wear safety gloves! thods. Wear Protective clothes! Clean the machine after each use. SSG 16 | Version 2.01... -
Page 11: Spare Parts
11 Spare parts Example The wheel for theCompressing and stretching machine DANGER! SSG 16 must be ordered. The wheel has the number 47 Risk of injury caused by the use of in the spare parts drawing 1. incorrect spare parts! -
Page 12: Spare Parts Drawing
The following drawing are intended to identify the required spare parts in the event of service. If applicable, submit a copy of the parts drawing including the highlighted components to your authorized retailer. Fig. 22: Spare parts drawing SSG 16 SSG 16 | Version 2.01... -
