RAULAND-BORG CORPORATION
Table of Contents
DISPLAY PHONE DIAGNOSTICS
#73 Hardware I/O Diagnostics .................................................................................. 2
General Procedures ............................................................................................. . 2
System Halting and Voltage Measurements ....................................................... . 6
#74 4 Call-in Sensitivity (RP2) Adjustment .................................................................. 11
#75 LLM Line Link Tests ............................................................................................ 12
Computer Monitor Set-up .......................................................................................... 13
Serial Port Monitor Commands ...... ............................................................................ 14
Other Serial Port Output ............................................................................................ 15
TROUBLESHOOTING AND REPAIR
TCN Find-It Fix-It Procedures
Time Saving Hints and Suggestions ................................................................... . 16
System Won't Run or Locks-up ............................................................................ 16
System Will Not Program ..................................................................................... . 16
Phone Won't Ring ................................................................................................ 17
Time Tones Do Not Work ................................................................................... . 17
All-Page Problem .................................................................................................. 17
Phone Rings-back Upon Hanging-up ................................................................. . 18
System Misdials or Won't Allow Access (Intermittent) ......................................
Talk Path Noisy or Dead (Intermittent) ............................................................. . 18
Crosstalk On Lines ............................................................................................... . 18
Phone Rings When Call Should Go To Attendant ........................................ ..1 ... 19
False Call-ins After All-Call or Time Tone ............................................................ 19
Finding Duplicate Numbers ................................................................................ 20
Ground Resistance Measurement ....................................................................... . 2 1
Loss Measurement ................................................................................................ 21
Lockout (Line, Link, or Receiver) ........................................................................ 22
Statistics ................................................................................................................ 23
Loop Sense Measurement .................................................................................... 24
Line Rebalancing Procedure ................................................................................ 25
Console Interface Adapter (TC4420) .................................................................. 27
LCD Display Problems (General) ........................................................................ 27
Single Link Staff Phone Problems (General) ..................................................... . 28
Speaker Intercom Problems (General) ............................................................... . 28
Interconnect Problems (General) ....................................................................... . 29
QUICK REFERENCE CHART ..............................................................
