- Page 1 SMART-CAL 360 CALIBRATION STATION INSTRUCTION MANUAL READ AND UNDERSTAND INSTRUCTIONS BEFORE USE 851 Transport Drive Phone: 888 473 6748 Email: info@gasleaksensors.com Valparaiso, IN 46383-8432 219 465 2700 Web: www.gasleaksensors.com Fax: 219 465 2701...
-
Page 2: Quick Start Instructions
If the configuration shown does not match your needs, it can be re-configured in the Supervisor Menu (refer to the instruction manual and contact SENSIT Technologies for the password). d. If using positive pressure regulators with ON/OFF knobs, turn them on. -
Page 3: For Your Safety
Only use in areas that are known to be free of combustible gas hazards. WARNING: Only for use in areas that are clean and dry. SMART-CAL 360 Turn all regulators and/or gas valves off when the is not in use. -
Page 4: Table Of Contents
Parts and Accessories ................5 Standard Accessories (Included) ............5 Accessories and Replacement Parts ............ 5 Smart-Cal 360 Product Description and Features ........6 SCAL Data Management Software Product Description ......7 Specifications .................... 8 Installation and Setup ................9 Valve Configuration ................. -
Page 5: Parts And Accessories
PARTS AND ACCESSORIES TANDARD CCESSORIES NCLUDED Instrument Cradle 365-00532 Screw for calibrator base (2) 331-00189 Power adapter 190-00007 Hose Kit 880-00064 Instruction Manual 750-00086 Calibrator protective dust cover 360-00636 SD Card 360-00243 SCAL 360 Data Management Software 500-SC360-01 ESKTOP ERSION USB Cable 360-00637 ETWORK... -
Page 6: Smart-Cal 360 Product Description And Features
SMART-CAL 360 PRODUCT DESCRIPTION AND FEATURES SMART-CAL 360 performs automated bump testing, calibration, and record keeping for Sensit instruments through a touch screen user interface (for instrument compatibility list, refer to the specification page). The calibrator will calibrate all instrument sensors, reset the instrument clock, perform a pump flow block test, allow review of the data on screen, and perform bump tests. -
Page 7: Scal Data Management Software Product Description
SCAL DATA MANAGEMENT SOFTWARE PRODUCT DESCRIPTION Sensit offers data management software that is used to download and manage calibration and bump testing records from any of our calibration stations. This allows for automatic data transfer and notification for compliance reports as well as many other features listed below. -
Page 8: Specifications
SPECIFICATIONS 10.6” x 5.4” x 6.1” Size (station only): (269mm x 137mm x 155mm) 11.0” x 15.2” x 6.1” Size (with instrument cradle): (280mm x 386mm x 155mm) Weight (station only): 4.1 lbs. (1.86 kg) Weight (with instrument cradle): 6.1 lbs. (2.77 kg) 110 –... -
Page 9: Installation And Setup
CONTINUE : If any failures occur during the system check, contact NOTE SENSIT Technologies for assistance. 4. After the start-up process on the station is complete, the main display should be shown. On this display will be the default valve configuration, which covers most standard calibration kits. -
Page 10: Valve Configuration
VALVE CONFIGURATION SMART CAL 360 Seven out of the eight valve inlet connections on the back of the are fully configurable (valve 6 is reserved for fresh air). By default, valves will be setup for the most common configurations: Valve 1: 2.5%V/V Methane / 100ppm CO combo gas Valve 2: Line Gas (for 100% V/V Methane calibration) Valve 3: 25ppm H2S Valve 4: 0.1% V/V (1000ppm) Methane... -
Page 11: Operation And Use
OPERATION AND USE The below instructions for performing a calibration and bump test are generalized to include all NOTE SMART-CAL 360 instruments manufactured by SENSIT that the supports. For more specific and in-depth instruction, check the instruction manual for your specific instrument, or check www.gasleaksensors.com... -
Page 12: Performing A Bump Test
1. Establish communication, transfer data, and automatically set the date and time on the instrument. 2. Flow check. 3. Fresh air purge and Autozero. 4. Bump test. SMART-CAL 360 The status LED light on top of the indicates: ● WHITE – ready ●... -
Page 13: Viewing Logs
VIEWING LOGS SMART-CAL 360 Anytime a calibration or bump test is attempted using the , a record of that attempt is saved on the internal memory (whether the result is a pass or fail). These records can either be viewed directly on the station through the user interface or uploaded to a computer or server and viewed using the Data Management software. -
Page 14: Sd Card Features
OFTWARE PDATES SMART-CAL 360 software can be updated by the user through the SD card slot. The software is loaded onto the card and then updated through the user interface. Contact SENSIT Technologies if you need assistance with this feature. -
Page 15: Supervisor Menu
Menu” should appear at the top of the display. : This menu is password protected. If you do not have the password and need to access this menu, NOTE contact SENSIT Technologies for assistance. RASE Adjustment for date and time of the station. The... -
Page 16: Maintenance And Care
MAINTENANCE AND CARE SMART-CAL 360 To keep the clean, and to protect and extend the life of the touchscreen, it is recommended to keep the provided dust cover on the station when it is not in use. SMART-CAL 360 It is recommended to turn all regulators and/or gas valves off when the is not in use. -
Page 17: Troubleshooting
If communication issues are experienced between the and the instrument, try the following steps. Contact SENSIT Technologies for assistance if issues persist. 1. Ensure that nothing is blocking the space between the IR window on the side of the station and the instrument, such as any tubing, gooseneck, carrying case strap, etc. -
Page 18: Check Gas Supply Errors
If it doesn’t say “line gas”, refer to the valve configuration section in this manual or Contact SENSIT Technologies for assistance. 2. Ensure that the gas supply for the valve that gives the error message is turned on and that gas is flowing (applies to positive pressure regulators only). -
Page 19: Notes
NOTES __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________ __________________________________________________________________________________________... -
Page 20: Eu Waste Electrical And Electronic Equipment (Weee) Directive
Sensit Technologies LLC has labeled its branded electronic products with the WEEE Symbol (figure above) to alert our customers that products bearing this label should not be disposed of in a landfill or with municipal or household waste in the EU.
