Lmppos LMP-L1 Quick Reference Manual

Barcode Scanner
Quick Reference Guide
Set Defaults
Installation
Refer to the below pictures, connect the scanner based on
different cables:
USB:
USB cable RJ45 connect bottom of scanner, the other
side connect PC.
USB cable
P/S 2
:P/S2 cable RJ45 connect bottom of scanner, the other
side to connect PC and P/S2 port keyboard
P/S2 cable
RS232 cable
RS232:
RS232 cable RJ45 connect bottom of scanner ,the
other side to connect PC.Power connect RS232 cable power
plug.
Typically, after connect data cable and scan on,the scanner is
able to identify the data port type automatically. In extreme
cases,scanner port may need setting manually if the scanner
fails to identify it.
Automatic Identification
(Default)
（PS/2）
How to scan:
When the scanner is scanning,ensure the scan line
crosses every bar and space of the symbol.
Right Wrong
Note：Indicator light flashing and with "beep" sound
that mean scan successfully.
Common Settings
Information inquire
Product info
Scanner Serial No
Suffix Quick Setup
CR（default）
CR+LF
USB
RS232
LF
None
