HV-100E/HV-200E DVB-T Transmitter
WWW.HIDES.COM.TW
Quick Installation Guide
Easy HD Expressway!
2
2
2
3
4
5
5
6
7
8
11
14
17
20
23
25
25
26
31
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV-100E and is the answer not in the manual?

Questions and answers

Related Manuals for Hides HV-100E

Summary of Contents for Hides HV-100E

  • Page 1: Table Of Contents

    Easy HD Expressway! HV-100E/HV-200E DVB-T Transmitter Quick Installation Guide PACKAGE CONTENTS  BACK PANEL VIEW  FRONT PANEL VIEW  CONNECT THE VIDEO SOURCE  POWER AND RF-OUT  SWITCH CHANNEL  CONNECT TO A RECEIVER  SCAN CHANNEL  APPENDIX A: CHANNEL FREQUENCY AND BANDWIDTH  A.1: CHANNEL FREQUENCY TABLE: 7/8MHZ BANDWIDTH ...

  • Page 2: Package Contents

    CVBS video-in and audio-in DTV RF output Ethernet (Coax. or Antenna) DTV RF output HDMI-out HDMI-in USB Configuration Port (Twisted pairs, (Loop-thru) (Video & Audio) 12 V DC-in for HV-100 only) 1.5A   Front Panel View Cancel WWW.HIDES.COM.TW Power Video-in Channel Number...

  • Page 3: Connect The Video Source

    HDMI display Monitor (Optional) Note: 1. Please refer to HV-100E&100J_SPEC.PDF or HV-200E&200J_SPEC.PDF for the HDMI video resolutions and frame rates supported by HV-100/HV-200. 2. HDMI PCM audio-in supports up to stereo 96KHz, 24bits. If the video source is CVBS AV-in, connect it the RCA AV-in jacks.

  • Page 4: Power And Rf-Out

    Basically, the channel number is consistent to the channel numbering rule of TV/STB receivers. Refer to appendix for the channel frequency mapping. If the channel number is 0, the channel frequency and bandwidth is set by PC/NB configuration tool via USB port. WWW.HIDES.COM.TW...

  • Page 5: Switch Channel

    RF input connector to decrease the RF-in power. Attenuator Trick: A TV splitter can also be used as an attenuator. A 2-way splitter attenuates about 4 dB while a 4-way splitter attenuates about 8 dB. WWW.HIDES.COM.TW...

  • Page 6: Scan Channel

    Easy HD Expressway! Scan Channel You should do channel scan before receiving and watching the transmitted program. WWW.HIDES.COM.TW...

  • Page 7: Appendix A: Channel Frequency And Bandwidth

    Note: When setting non-standard TV channels for 2/3/4 MHz bandwidth or 1.2G band, it should be configured with PC/NB/Android software. By setting channel number to 0, the bandwidth and frequency can be input manually. Refer to Appendix B & C for further details. WWW.HIDES.COM.TW...

  • Page 8: A.1: Channel Frequency Table: 7/8Mhz Bandwidth

    Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 9 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 10 DATV DATV DATV 1265 DATV 1265 DATV 1265 DATV 1280 DATV 1280 DATV 2334 DATV 2350 DATV 2360 DATV 2380 DATV 2385 DATV 2395 DATV 2395 DATV 2395 DATV 2402 DATV 2406 DATV 2420 DATV 2443 99(0x99) UHF IV WWW.HIDES.COM.TW...

  • Page 11: A.2: Channel Frequency Table: 6Mhz Bandwidth

    VHF III VHF III VHF III VHF III VHF III VHF III UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 12 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 13 Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) 99(0x99) UHF IV WWW.HIDES.COM.TW...

  • Page 14: A.3: Channel Frequency Table: 7Mhz Bandwidth

    Special (UHF hyper band) 452.5 UHF IV (non-broadcast) 473.5 UHF IV (non-broadcast) 480.5 UHF IV (non-broadcast) 487.5 UHF IV (non-broadcast) 494.5 UHF IV (non-broadcast) 501.5 UHF IV (non-broadcast) 508.5 UHF IV (non-broadcast) 515.5 UHF IV (non-broadcast) 522.5 UHF IV 529.5 WWW.HIDES.COM.TW...
  • Page 15 UHF V 704.5 UHF V 711.5 UHF V 718.5 UHF V 725.5 UHF V 732.5 UHF V 739.5 UHF V 746.5 UHF V 753.5 UHF V 760.5 UHF V 767.5 UHF V 774.5 UHF V 781.5 UHF V 788.5 WWW.HIDES.COM.TW...
  • Page 16 UHF V 942.5 UHF V 949.5 user defined user defined user defined user defined user defined user defined user defined Special (UHF hyper band) 459.5 Special (UHF hyper band) 466.5 Special (VHF low band) 170.5 99(0x99) UHF IV 529.5 WWW.HIDES.COM.TW...

  • Page 17: A.4: Channel Frequency Table: 8Mhz Bandwidth

    Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 18 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 19 99(0x99) UHF IV WWW.HIDES.COM.TW...

  • Page 20: Appendix B: Configure With Windows Pc/Nb

    CD. If the device driver is installed well, there will be a new Com Port device, shown in Windows Device Manager. The com port assignment may vary depending on the PC configurations. In the following example, COM5 is assigned. WWW.HIDES.COM.TW...
  • Page 21 Select the com port for HV-100/HV-200. In this example, COM5 should be selected. The button “Auto Detect” can be used to identify the correct com port which is attached to HV-100/HV-200 if necessary. Then, click on “Open/Close” to connect HV-100/HV-200. If device is connected successfully, a message box WWW.HIDES.COM.TW...
  • Page 22 Note: If any error message pops up when “Get All Config”, please quit and restart this tool. Right after “Open”, click on “Reset to Default” button to reset all configurations. The “Reset to Default” button is used to reset HV-100/HV-200 to factory default settings when HV-100/HV-200 does not work properly due to wrong configurations. WWW.HIDES.COM.TW...

  • Page 23: Configure Data Bit Rate Properly

    When the data rate is not configured well, it will pop up a message box. The transmission data rate (channel capacity) is determined by the modulation parameters, including bandwidth, code rate, constellation, and guard interval. The current modulation data rate is shown and updated dynamically, as shown below. WWW.HIDES.COM.TW...
  • Page 24 Easy HD Expressway! The encoded video data bit rate + audio bit rate should be less than the modulation channel capacity. Refer to the picture below, WWW.HIDES.COM.TW...

  • Page 25: Appendix C: Configure With Android Tablet

    Support RTSP TS or PES Payload Note:TS is recommended for better compatibility Video Streaming Output HDMI/HDSDI video input, RTSP streaming output (Simultaneous DTV RF and IP output support) Refer to HV-10x/HV-20x Network Support for IP streaming and Web Remote Management QIG. WWW.HIDES.COM.TW...

  • Page 26: Appendix E: Update Firmware With Sd Card

    1. You should login Windows in Administrator mode to restore the SD card image.. 2. The contents of the SD card will be destroyed and rewritten in the following operation. Run “USB Image Tool.exe”, which can be found in the folder “\USB Image Tool” on the CD. WWW.HIDES.COM.TW...
  • Page 27 All removable storage devices are listed, please select the correct one for SD card. Note: If the Size of SD card shown is 0 bytes (refer to the picture below), then the SD card may not well supported by the tool. Please change another SD card. Then click on “Restore” button. WWW.HIDES.COM.TW...
  • Page 28 Note: When you click on “yes” button, the SD card will be overwritten with the firmware image, and the original contents will be destroyed. If the SD card is well prepared, you may browse its contents in Windows. A sample is shown below. WWW.HIDES.COM.TW...
  • Page 29 (LED2/LED3 on PCB will be on as well) 4. When firmware update is done (it’s about 30 seconds), all the LED’s will be off. 5. Remove the SD card 6. Reset (power off and on) to boot HV-100/HV-200 with the new firmware. WWW.HIDES.COM.TW...
  • Page 30 Easy HD Expressway! WWW.HIDES.COM.TW...

  • Page 31: Appendix F: Jumper/Led/Connector

    - 0 1 1: UART BOOT MODE - 1 0 0: USB BOOT MODE - 1 1 0: EMAC BOOT MODE J31:LED RF J32: RTC Battery (JP6) LED 1: Power LED 2: GIO58 LED 3: GIO57 (video-in) LED 4: HDMI-in LED 5: RF Enable WWW.HIDES.COM.TW...
  • Page 32 Easy HD Expressway! Appendix G: RF-output filter design WWW.HIDES.COM.TW...
