DVB-T Transmitter
Quick Installation Guide
Easy HD Expressway!
HV-100E
2
2
2
3
4
5
5
6
7
10
13
16
19
23
23
24
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV-100E and is the answer not in the manual?

Questions and answers

Related Manuals for Hides HV-100E

Summary of Contents for Hides HV-100E

  • Page 1: Table Of Contents

    Easy HD Expressway! HV-100E DVB-T Transmitter Quick Installation Guide PACKAGE CONTENTS BACK PANEL VIEW FRONT PANEL VIEW CONNECT THE VIDEO SOURCE POWER AND RF-OUT SWITCH CHANNEL CONNECT TO A RECEIVER APPENDIX A: CHANNEL FREQUENCY AND BANDWIDTH A.1: CHANNEL FREQUENCY TABLE: 7/8MHZ BANDWIDTH A.2: CHANNEL FREQUENCY TABLE: 6MHZ BANDWIDTH...

  • Page 2: Package Contents

    Back Panel View CVBS video-in and audio-in DTV RF output Ethernet (Coax. or Antenna) DTV RF output HDMI-out HDMI-in USB Configuration Port (Twisted pairs) 12 V DC-in (Loop-thru) (Video & Audio) Front Panel View Cancel Power Video-in Channel Number WWW.HIDES.COM.TW...

  • Page 3: Connect The Video Source

    CVBS-in video signal will be checked only once when system power is on if the video input port is set to “Auto”. You may configure the input port to Composite(CVBS) with Windows or Android tool, so CVBS AV-in port will be checked repeatedly after power on and users may apply CVBS video signal anytime. WWW.HIDES.COM.TW...

  • Page 4: Power And Rf-Out

    Basically, the channel number is consistent to the channel numbering rule of TV/STB receivers. Refer to appendix for the channel frequency mapping. If the channel number is 0, the channel frequency and bandwidth is set by PC/NB configuration tool via USB port. WWW.HIDES.COM.TW...

  • Page 5: Switch Channel

    RF input connector to decrease the RF-in power. Attenuator Trick: A TV splitter can also be used as an attenuator. A 2-way splitter attenuates about 4 dB while a 4-way splitter attenuates about 8 dB. WWW.HIDES.COM.TW...

  • Page 6: Appendix A: Channel Frequency And Bandwidth

    Note: When setting non-standard TV channels for 2/3/4 MHz bandwidth or 1.2G band, it should be configured with PC/NB/Android software. By setting channel number to 0, the bandwidth and frequency can be input manually. Refer to Appendix B & C for further details. WWW.HIDES.COM.TW...

  • Page 7: A.1: Channel Frequency Table: 7/8Mhz Bandwidth

    Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 8 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 9 99(0x99) 99(0x99) 99(0x99) 99(0x99) UHF IV UHF IV UHF IV UHF IV 8 8 8 8 WWW.HIDES.COM.TW...

  • Page 10: A.2: Channel Frequency Table: 6Mhz Bandwidth

    VHF III VHF III VHF III VHF III VHF III VHF III UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 11 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 12 Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) 99(0x99) 99(0x99) UHF IV UHF IV 6 6 6 6 99(0x99) 99(0x99) UHF IV UHF IV WWW.HIDES.COM.TW...

  • Page 13: A.3: Channel Frequency Table: 7Mhz Bandwidth

    Special (UHF hyper band) 452.5 UHF IV (non-broadcast) 473.5 UHF IV (non-broadcast) 480.5 UHF IV (non-broadcast) 487.5 UHF IV (non-broadcast) 494.5 UHF IV (non-broadcast) 501.5 UHF IV (non-broadcast) 508.5 UHF IV (non-broadcast) 515.5 UHF IV (non-broadcast) 522.5 UHF IV 529.5 WWW.HIDES.COM.TW...
  • Page 14 UHF V 704.5 UHF V 711.5 UHF V 718.5 UHF V 725.5 UHF V 732.5 UHF V 739.5 UHF V 746.5 UHF V 753.5 UHF V 760.5 UHF V 767.5 UHF V 774.5 UHF V 781.5 UHF V 788.5 WWW.HIDES.COM.TW...
  • Page 15 Special (UHF hyper band) 459.5 Special (UHF hyper band) 466.5 Special (VHF low band) 170.5 99(0x99) 99(0x99) 99(0x99) 99(0x99) UHF IV IV IV IV 529.5 529.5 529.5 529.5 7 7 7 7 WWW.HIDES.COM.TW...

  • Page 16: A.4: Channel Frequency Table: 8Mhz Bandwidth

    Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) Special (UHF hyper band) UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV UHF IV WWW.HIDES.COM.TW...
  • Page 17 UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V UHF V WWW.HIDES.COM.TW...
  • Page 18 99(0x99) 99(0x99) 99(0x99) 99(0x99) UHF IV UHF IV UHF IV UHF IV 8 8 8 8 WWW.HIDES.COM.TW...

  • Page 19: Appendix B: Configure With Windows Pc/Nb

    CD. If the device driver is installed well, there will be a new Com Port device, shown in Windows Device Manager. The com port assignment may vary depending on the PC configurations. In the following example, COM5 is assigned. WWW.HIDES.COM.TW...
  • Page 20 Select the com port for HV-100. In this example, COM5 should be selected. The button “Auto Detect” can be used to identify the correct com port which is attached to HV-100 if necessary. Then, click on “Open/Close” to connect HV-100. If device is connected successfully, a message box pops up WWW.HIDES.COM.TW...
  • Page 21 Note: If any error message pops up when “Get All Config”, please quit and restart this tool. Right after “Open”, click on “Reset to Default” button to reset all configurations. The “Reset to Default” button is used to reset HV-100 to factory default settings when HV-100 does not work properly due to wrong configurations. WWW.HIDES.COM.TW...
  • Page 22 The new settings will take effect when users click on the corresponding “Set…Config” button. Alternatively, users may click on “Set All Config” button to update all categories of configurations in a single click. The configuration API/protocol SDK for developers is available on request. WWW.HIDES.COM.TW...

  • Page 23: Appendix C: Configure With Android Tablet

    An Android APP tool is under development, which will provide another way to configure HV-100 with handheld devices.) Appendix D: Network Video Streaming Support (TBD, IP video streaming, either IP to DVB-T or HDMI/CVBS to IP video streaming output is still under development, and not available yet.) WWW.HIDES.COM.TW...

  • Page 24: Appendix E: Update Firmware With Sd Card

    Note: the contents of the SD card will be destroyed and rewritten in the following operation. Run “USB Image Tool.exe”, which can be found in the folder “\USB Image Tool” on the CD. All removable storage devices are listed, please select the correct one for SD card. Then click on “Restore” button. WWW.HIDES.COM.TW...
  • Page 25 When the following message box pops up, click “Y” to proceed. Note: When you click on “yes” button, the SD card will be overwritten with the firmware image, and the original contents will be destroyed. E.2 Update Firmware Open the box, locate the SD socket WWW.HIDES.COM.TW...
  • Page 26 3. Both the two LED’s will be on when firmware update in progress. 4. When firmware update is done (it’s about 60 seconds), both the LED’s will be off. 5. Remove the SD card 6. Reset (power off and on) to boot HV-100 with the new firmware. WWW.HIDES.COM.TW...
