Summary of Contents for Actia VCM
- Page 1 Owner Date Nicklas Andersson 2020-09-08 Classification Document number Revision 5610_40037 Title Page VCM User Manual 1(9) User Manual...
-
Page 2: Table Of Contents
Owner Date Nicklas Andersson 2020-09-08 Classification Document number Revision 5610_40037 Title Page VCM User Manual 2(9) Content General ..............................3 Revision history ..........................3 Abbreviations ............................ 3 References ............................3 Introduction ............................... 4 Technical Description ..........................5 Connectors ............................5 3.1.1... -
Page 3: General
Owner Date Nicklas Andersson 2020-09-08 Classification Document number Revision 5610_40037 Title Page VCM User Manual 3(9) General Revision history Revision Author Date Description Nicklas Andersson 2017-08-31 First version Salah Alazawi 2017-10-09 Updated for FCC Salah Alazawi 2019-09-12 Corrected FCC information... -
Page 4: Introduction
CAN*, Ethernet/WLAN and Remotely via available Internet connections. The VCM can also be used as a Wi-Fi hotspot for people inside the vehicle as well as a W-Fi client to connect to available hotspots (for instance, a hotspot provided from a passenger’s laptop or cell phone), and it provides raw GNSS position for use by other ECUs in the vehicle, such as the Navigation system. -
Page 5: Technical Description
Owner Date Nicklas Andersson 2020-09-08 Classification Document number Revision 5610_40037 Title Page VCM User Manual 5(9) Technical Description Connectors Connector No Function DLC Ethernet USB/IHU Ethernet Main Connector WLAN antenna GNSS antenna 3.1.1 DLC Ethernet connector The DLC Ethernet connector is used for Ethernet communication with external diagnostics equipment. -
Page 6: Supported Bands
Owner Date Nicklas Andersson 2020-09-08 Classification Document number Revision 5610_40037 Title Page VCM User Manual 6(9) 3.2.1 Supported bands Technology Bands GLONASS L1 FDMA WLAN The WLAN antenna is connected to the orange Fakra connector. The product supports dual-band 802.11b/g/n at 2.4GHz and 802.11a/n at 5GHz. Supported channels are listed below. -
Page 7: Functional Description
WLAN access point functionality is controlled via IHU Ethernet interface. Data gateway VCM acts as a data gateway for the WLAN access point and other ECUs in the vehicle. It can e.g. provide internet connectivity for the head unit. The data gateway is controlled via the IHU Ethernet interface. -
Page 8: Installation And Maintenance
8(9) Installation and maintenance Installation The VCM is factory fitted in Volvo vehicles. It is not possible to buy this product separately. The product is certified to be used with an external roof mounted antenna. Volvo part number 31346764 Minimum cable length is 2.5m. -
Page 9: Regulatory Certifications
Classification Document number Revision 5610_40037 Title Page VCM User Manual 9(9) Regulatory Certifications USA (FCC) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
