JL Audio MMR-40 Mounting Instructions

The diagram below shows a typical mounting procedure into a fiberglass panel. Always follow proper safety
procedures. Wear eye-protection at all times with a dust mask and gloves when cutting. A mounting
template is included to aid in measuring and marking the mounting surface before cutting or drilling.
Before drilling or cutting, make sure there is adequate space behind the mounting
surface to fit the MMR-40, including its wire harness.
1. Press along the perforation to remove the center section of the mounting template. (Discard the center
section.) The template can be used to verify there is sufficient flat surface area for mounting and as a guide
for cutting the opening. Tape the template to the mounting location and mark the surface for cutting the
2. Use a jigsaw or rotary tool to cut an opening in the mounting surface. If necessary, use a file or sandpaper
opening and drilling pilot holes.
3. Place the MMR-40 into the opening and check that the mounting holes remain aligned with the pilot hole
to adjust the opening for proper fitment and smooth the edges.
4. Remove the MMR-40 and drill four (4) pilot holes in the mounting surface at the pilot hole marks.
marks taken from the template. If not, adjust and mark new holes as necessary.
5. Peel the adhesive backing from the mounting gasket and affix to the rear of the bezel. Connect all wiring
6. Secure the MMR-40 using the four (4) stainless steel screws. Press the trim ring onto the front of
and place the MMR-40 into the opening.
the MMR-40.
–
Mounting Instructions
MMR-40-MOUNT-062118
