Cobra SC 200 Quick Start Manual

Button Functions (Recording Stopped):
Enters the settings menu where you can adjust your camera's settings
Takes a snapshot and stores it in the Photo Folder.
Enters the playback menu to review previous recordings and photos.
Begins loop recording.
Button Functions (While Recording):
When pressed the camera saves the current clip from
being overwritten.
Takes a snapshot and stores it in the Photo Folder.
Toggles the microphone on/off. Note that the icon on the button
indicates the action that will be taken when the button is pushed,
not the current setting. The current setting is shown on the status
bar at the top of the screen.
Stops loop recording. While in an Emergency Recording you will
be asked to confirm.
Voice Commands
SC200 will respond to certain voice commands so you can stay focused on the road ahead.
Try the following voice commands.
Say Camera Action
"Front Video On" Front-View camera is displayed on screen
"Rear Video On" Rear-View camera is displayed on screen
(optional accessory camera required)
"Record Video" Toggles recording on/off
"Lock Video" (If currently recording), Camera locks the video and
tags as Favorite
(If not currently recording), Camera begins emergency
recording, locks first video and tags as favorite
"Screen On" Turn Display On
"Screen Off" Turn Display Off
"Take Photo" Takes photo of front and/or rear view and saves to
"Photos" folder
Attaching Additional Flex View Cameras
For Cabin View*
Connect Cabin Camera to the
Video Input Port on the SC 200
For a View of the Road Behind You*
Connect Extension Cable to the Video Input Port
1
on the Dash Cam
2
Connect Extension Cable to the Rear Camera
3
Attach Rear Camera to the Vehicle's Back Window
Warning: Please position the camera on the rear
windshield so it faces out of the vehicle in the orientation shown
*Additional Flex View Cameras sold separately
