RL865 Micro-power Multi-protocol
◆
Before you use this product, please read this manual carefully, and properly keep
it for future reference.
◆
As our products continue improving, they may be changed without advanced
notice.
◆
The copyright of this manual belongs to our company. Unauthorized plagiarism or
dissemination will be held legally responsible.
Reader
User Manual
Advertisement
Table of Contents
Related Manuals for Andea Electronics RL865
Summary of Contents for Andea Electronics RL865
- Page 1 RL865 Micro-power Multi-protocol Reader User Manual ◆ Before you use this product, please read this manual carefully, and properly keep it for future reference. ◆ As our products continue improving, they may be changed without advanced notice. ◆ The copyright of this manual belongs to our company. Unauthorized plagiarism or...
- Page 2 Version:V1.0...
-
Page 3: Table Of Contents
User manual Contents Product Overview ................ 1 1.1. Introduction ................1 1.2. Product Features ..............1 1.3. Pictures ..................1 1.4. Main Parameter ................ 2 Hardware Interface Description ........... 2 Description Of Indicator Light ............. 3 Device Connection Instructions ........... 3 4.1. -
Page 4: Product Overview
User manual 1. Product Overview 1.1. Introduction RL865 is a micro-power multi-protocol reader with high sensitivity reading and writing performance and fast anti-collision processing algorithm which supports reading multiple electronic tags of various protocols at the same time. This product is widely used in desktop card issuance, access control, electronic bills, Libraries and other fields. -
Page 5: Main Parameter
Note: ① Product specifications are approximate, please refer to the actual size; ② Due to continuous improvement of our products, technical parameters are subject to change without notice. 2. Hardware Interface Description Figure 2 Product dimension (unit: mm) Guangzhou Andea Electronics Technology Co., Ltd. 2/15 http://www.gzandea.com... -
Page 6: Description Of Indicator Light
4. Device Connection Instructions 4.1. Device Connection Instructions USB cable Figure 4 Connection diagram After the device is connected and powered on normally, open the R-Tool folder of Guangzhou Andea Electronics Technology Co., Ltd. 3/15 http://www.gzandea.com... - Page 7 ② Click the "Search" button to search devices ① Select “USB” for the communication interface ④ Click the start button to enter the device configuration and test interface Figure 6 Connection steps Guangzhou Andea Electronics Technology Co., Ltd. 4/15 http://www.gzandea.com...
-
Page 8: Configuration Description Of Parameters
4.2.1. Communication Interface Figure 8 Configuration interface for communication interface ⚫ Bus Address: between 1-255 ⚫ Baud: baud rate: 9600, 19200, 38400, 57600, 115200, 230400 ⚫ Parity: parity check type: None, Odd, Even Guangzhou Andea Electronics Technology Co., Ltd. 5/15 http://www.gzandea.com... -
Page 9: Buzzer Default Parameters
Note: The device V00.02 and above (including V00.02 version) supports this function (buzzer is required). 4.2.3. RF Parameters Figure 10 Configuration interface for RF parameters ⚫ Basic options 1)Auto close RF when RF is free for specified time：in the host control mode, the Guangzhou Andea Electronics Technology Co., Ltd. 6/15 http://www.gzandea.com... - Page 10 4) ASK modulation depth: 0.5% -60% ⚫ ISO18000p3m3 1)M: Manchester 2,Manchester 4 2) DR:FC/16847khz, FC/32424khz 3) Modulation depth:0.5%-29% ⚫ Receiver Gain: set according to the default value, it is not recommended to modify. Guangzhou Andea Electronics Technology Co., Ltd. 7/15 http://www.gzandea.com...
-
Page 11: Inventory Parameters
2) Session: session 0, session 2. 3) Use dynamic Q:whether to enable dynamic Q value. 4) Min dynamic Q: set the minimum dynamic Q value. 5) Max dynamic Q: set the maximum dynamic Q value. Guangzhou Andea Electronics Technology Co., Ltd. 8/15 http://www.gzandea.com... -
Page 12: System Work Mode
2) Port of data output: Uart1 output, USBHID output, virtual keyboard output, Wiegand 26, Wiegand 34. 3) Scan option ① Output UID: output the tag UID. ② Output block’s data: output the content of the data block (not including the security status byte). Guangzhou Andea Electronics Technology Co., Ltd. 9/15 http://www.gzandea.com... -
Page 13: Testing
4.3.1. Multi-tags Inventory Testing After entering the main interface of R-Tool test software, select "ISO Multi-Tag Test" ,carry out the procedure as shown in the following figure ①, ② and ③ for tags inventory test: Guangzhou Andea Electronics Technology Co., Ltd. 10/15 http://www.gzandea.com... -
Page 14: Single Tag Operation Testing
In the main interface of R-Tool test software, select " Single Tag Test" , carry out the procedure as shown in the following figure ①,②,③,④ and ⑤ for tags test: Figure 14 Single tag operation test steps Guangzhou Andea Electronics Technology Co., Ltd. 11/15 http://www.gzandea.com... - Page 15 3) Write the value in the line (green area) of the data block whose value should be written, and then click [Write Block]; 4) After the operation is completed, click the [Disconnect] button to disconnect the tag connection. Guangzhou Andea Electronics Technology Co., Ltd. 12/15 http://www.gzandea.com...
-
Page 16: Technical Support
User manual 5. Technical Support ➢ Download link for development data and testing https://www.gzandea.com/download.php ➢ Call for equipment debugging and technical support Mobile phone: 138 0251 4535 180 2712 4253 Fixed telephone: 0086-20-32039552 Guangzhou Andea Electronics Technology Co., Ltd. 13/15 http://www.gzandea.com... - Page 17 à une distance minimum de 20 cm entre l’antenne et votre corps. Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre émetteur. Guangzhou Andea Electronics Technology Co., Ltd. 14/15 http://www.gzandea.com...
- Page 18 également afficher une étiquette se référant au module. Le dispositif final doit être étiqueté dans une zone visible avec les éléments suivants : "Contient FCC ID : 2AFI8-RL865" "Contient IC :26251-RL865" Guangzhou Andea Electronics Technology Co., Ltd.
