LED METAL DETECTOR
A A V I X D E T E C T O R S
Read this manual carefully. Learn how to operate and maintain your product properly to avoid
injury and product damage. You are responsible for operating the product properly & safely.
WARNING:
FOR SAFE OPERATION, READ
OWNER'S MANUAL PRIOR TO USE.
OWNER'S MANUAL
WORK SAFELY WITH TOOLS BY
WEARING SAFETY GLASSES!
9 V
AGT310A
FOR SERVICE OR SUPPORT
PLEASE CALL TOLL FREE:
1-866-591-8921

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGT310A and is the answer not in the manual?

Questions and answers

Related Manuals for AAVIX AGT310A

Summary of Contents for AAVIX AGT310A

  • Page 1 A A V I X D E T E C T O R S OWNER’S MANUAL AGT310A Read this manual carefully. Learn how to operate and maintain your product properly to avoid injury and product damage. You are responsible for operating the product properly & safely.
  • Page 2 FEATURES With your Metal Detector, you can hunt for coins, relics, jewelry, gold, and silver just about anywhere. This metal detector is versatile and easy to use. The detector’s features include: Two Operation Modes: ALL METAL, DISC ALL METAL — lets you search for all kinds of metal with auto ground balance and high sensitivity.

  • Page 3: Assembling The Detector

    PREPARATION ASSEMBLING THE DETECTOR 1. Unscrew the knobs on the search coil and remove the knobs and the connector. Insert the smaller stem and align the holes on the search coil bracket and the stem. Push the connector through the holes, then replace and tighten the knobs.
  • Page 4 4. Tighten the fixing screw properly. 5. Insert the search coil cable plug into the five pin jack on the front control box’s housing. 6. Lengthen or shorten the stem, so when you stand upright with the detector in your hand, the search coil is level with and about 0.4~2inch above the ground.

  • Page 5: Adjusting The Search Coil

    Small head ADJUSTING THE SEARCH COIL Loosen the knobs at the search coil’s end, and then adjust the search coil to the desired angle (The search coil should be parallel with the ground.). Tighten the knobs just enough to keep the search coil from rotating or wobbling. INSTALLING BATTERY You need one 9V alkaline battery to power your detector.

  • Page 6: Using Earphones

    3. Connect the battery with the battery connector taking care of the polarity. Then put the battery into the compartment. 4. Replace the cover. Cautions: Always remove old or weak battery; battery can leak chemicals that can destroy electronic parts. If you do not plan to use the detector for a week or more, remove the battery.

  • Page 7: Functions And Indicators

    After you begin listening, adjust the volume to a comfortable level. Do not listen at extremely high volume levels. Extended high volume listening can lead to permanent hearing loss. Once you set the volume, do not increase it. Over time, your ears adapt to the volume level, so a volume level that does not cause discomfort might still damage your hearing.
  • Page 8 Rotate the control counter clockwise to the end to get ALL METAL mode. All METAL also comes with auto ground balance. It’s used to find not only ferrous metal, but also non-ferrous one (see more details below). b. VOLUME — Rotate the control clockwise to power on the unit.
  • Page 9 Then stop the search coil directly over this point on the ground. Move the search coil straight forward away from you and straight back towards you a couple of times. Meantime slowly rotate the DISC control clockwise away from ALL METAL until the unit does not sound or sounds short tone.

  • Page 10: Care And Maintenance

    necessary, reset the DISC. When searching in trash area, it’s better to set the DISC to 11:00 position, so that the unit can notch most of invaluable metals such as nails and small trashy iron. Move away any metal digging tool when searching. Sensitivity level is generally in contradiction with that of the Discrimination.

  • Page 11: Warranty

    Selective collection of household electric and electronic waste WARRANTY AAVIX product carries a limited one (1) year warranty against defects in workmanship and materials from date of purchase under normal household use. If product is to be used for commercial, industrial or rental use, a 30 days limited warranty will apply.
  • Page 12 commercial use, abuse, neglect, accident, improper maintenance, or alteration. 2. The unit, if it has not been operated and or maintained in accordance with the owner’s manual 3. Normal wear, except as noted below. 4. Routine maintenance items such as clean, tightening. 5.
